Congratulations on purchasing RIO-9830. This Quick Start Guide will provide
information needed to get started with RIO-9830. Please also consult the User Manual
for detailed information on the setup and use of RIO-9830.
In addition to this guide, the package includes the following items:
RIO-9830 模組
RIO-9830 User Manual
RIO-9830 Website
ICP DAS Website
Copyright © 2024 ICP DAS Co., Ltd. All Rights Reserved.
Quick Start Guide for
April 2024, Version 1.0.0
E-mail: service@icpdas.com
RIO-9830
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the RIO-9830 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for ICP DAS USA RIO-9830

  • Page 1 April 2024, Version 1.0.0 Congratulations on purchasing RIO-9830. This Quick Start Guide will provide information needed to get started with RIO-9830. Please also consult the User Manual for detailed information on the setup and use of RIO-9830. In addition to this guide, the package includes the following items: RIO-9830 模組...
  • Page 2: Ethernet Port

    Connect PC with the RIO-9830 via the Ethernet port When RIO-9830 dip switch positions 5 and 6 are set to OFF and then powered on, it will enter Normal mode. In this mode, users can customize IP without being restricted by rotary switch.
  • Page 3: Installing The Minios7 Utility

    ---------------------------------------------------------------------------------- Using MiniOS7 Utility to Assign a New IP The MCU (Main Control Unit) of RIO-9830 is an Ethernet device, which comes with a default IP address. Therefore, you must first assign a new IP address to the MCU. The factory default IP settings are as follows:...
  • Page 4 Step 1: Run the MiniOS7 Utility Double-click the MiniOS7 Utility shortcut on your desktop. Step 2: Press “F12” or choose “Search” from the “Connection” menu After pressing F12 or choosing Search from Connection menu, the MiniOS7 Scan dialog will appear, that will display a list of all the MiniOS7 modules on your network. See the status tip, waiting for the search to be done.
  • Page 5 Step 5: Choose “Yes” button After completing the settings, press the Yes button in the Confirm dialog box to exit the procedure. ---------------------------------------------------------------------------------- Reboot the RIO-9830 and finish the IP configuration Copyright © 2024 ICP DAS Co., Ltd. All Rights Reserved. E-mail: service@icpdas.com...
  • Page 6 Use RIO-9830 utility to set the configuration of IOM (I/O module). Execute the RIO-9830 and put the IP address of your RIO-9830 in the IP field and click “Connect” button. Then, the utility will get the hardware information and the original configuration from RIO-9830.
  • Page 7 After downloading the configuration into the RIO-9830, you can click “Save” button to save these parameters into an ini file. Or use “Load” button to load the configuration from an ini file. This is useful when you have several RIO-9830 which need to be configured as the same one.
