Table Of Contents - Midea MDK100-CH01B/B05E-EU-C5 Service Manual

Tumble heat pump dryer

Contents

1. Precaution..................................................................................................................................................

2. Factory Pattern Detection ......................................................................................................................... 9

3. Disassembling Ways of Main Parts ......................................................................................................... 10

4. Malfunctions Codes and Explanations ................................................................................................... 20

5. Troubleshooting ...................................................................................................................................... 21

5.1 The dryer breaks down and the control panel can not display

5.2 The drum does not spin while the control panel can display

5.3 The heating system does not work

5.4 The dryer makes abnormal noise when operating

5.5 The dryer gives out abnormal smell when operating

5.6 Dryer's 'Full' LED is lighting

5.7 E32 LED is lighting after the cycle finished

5.8 E33 LED is lighting

5.9 E50 LED is lighting after the cycle finished(only for BLDC model)

5.10 E60 LED is lighting after the cycle finished(only for BLDC model)

5.11 E82 LED is lighting

5.12Heat pump system parts repair

6. Check Point of Electronic Components ....................................................................................................... 31

7. Service Tools ................................................................................................................................................... 32

8. Appendix.......................................................................................................................................................... 33
