Portwell WADE-8110 User Manual

Intel core i7/i5/i3 mobile processor qm67 mini itx motherboard
Hide thumbs Also See for WADE-8110:
Table of Contents

Advertisement

Quick Links

Download this manual
All manuals and user guides at all-guides.com
Intel® Core™ i7/i5/i3 mobile Processor
QM67 Mini ITX Mother Board
User's Manual
Rev. 0.0
2011/04/27
1/26

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WADE-8110 and is the answer not in the manual?

Questions and answers

Related Manuals for Portwell WADE-8110

Summary of Contents for Portwell WADE-8110

  • Page 1 All manuals and user guides at all-guides.com Intel® Core™ i7/i5/i3 mobile Processor QM67 Mini ITX Mother Board User’s Manual Rev. 0.0 2011/04/27 1/26...
  • Page 2 All manuals and user guides at all-guides.com User’s Manual Copyright All rights reserved. The information contained in this guide has been v alidated and reviewed f or accuracy. No patent liability is assumed with respect to the use of th information contained herein.
  • Page 3 All manuals and user guides at all-guides.com User’s Manual How to Use This Manual This manual is written for the system integr ator, PC technician and knowledgeable PC end user. It describes how to configure your to meet various operating requirements. The user ’s manual is divided int o three c hapters, with each chapter addressing a b asic concept and operation of the server board.

  • Page 4: Table Of Contents

    All manuals and user guides at all-guides.com User’s Manual Table of Content CHAPTER 1 ........................5   1.  Introduction ......................... 6  1.1  Description ......................6  1.2  Dimensions ......................9  CHAPTER 2 ........................10   2.  Hardware Configuration Setting ................11  2.1 ...

  • Page 5: Chapter 1

    All manuals and user guides at all-guides.com ADE-6065 User’s Manual CHAPTER 1 5 / 26...

  • Page 6: Introduction

    All manuals and user guides at all-guides.com User’s Manual 1. Introduction Description Taking adv antages of Intel energy-ef ficient processing, Mini-ITX motherboard ® adopts 2 Generation Intel® Core™ processor family and Intel QM67 chip set to fit th e high performance computer system applic ations for meeting today’ s demanding p ace and keep complete comp atibility with hardware and software designed.
  • Page 7 All manuals and user guides at all-guides.com User’s Manual Specifications WADE-8110 ® Intel Sandy Bridge – MB , rPGA.type Intel® Core™ i7-2710QE processors (2.1GHz, 45W) Intel® Core™ i5-2510E processors (2.5GHz, 35W) Intel® Core™ i3-2330E processors (2.2GHz, 35W) Intel® Celeron B810 processors (1.6GHz, 35W) BIOS AMI UEFI BIOS with 64 Mb SPI Flash ROM support AMT7.0...
  • Page 8 All manuals and user guides at all-guides.com WADE-8110 User’s Manual Audio 3 x Audio Jacks for Line-out, MIC-input, Line-input PS/2 2 x Mini-DIN 6-pin Keyboard & Mouse Internal I/O SATA 4 x ( 1 x 7 ) SATA connector LVDS 1 x ( 2 x 20 ) 1.25mm pin-header for 24-bit with brightness control...

  • Page 9: Dimensions

    All manuals and user guides at all-guides.com WADE-8110 User’s Manual Dimensions 9 / 26...

  • Page 10: Chapter 2

    All manuals and user guides at all-guides.com ADE-6065 User’s Manual CHAPTER 2 10 / 26...

  • Page 11: Hardware Configuration Setting

    All manuals and user guides at all-guides.com WADE-8110 User’s Manual 2. Hardware Configuration Setting This chapter gives the definitions and show s the positions of jumpers, headers and connectors. All of the configuration jumpers on the board are in the proper position. T he default settings shipped from factory are marked with an asterisk ( ).

  • Page 12: Board Layout

    All manuals and user guides at all-guides.com WADE-8110 User’s Manual 2.1 Board Layout 12 / 26...

  • Page 13: Jumpers & Connectors

    All manuals and user guides at all-guides.com WADE-8110 User’s Manual 2.2 Jumpers & Connectors JUMPERS FUNCTION REMARK AMT1 PLL Odvr Voltage 1 x 3 header Auto Power On Setting 1 x 3 header A_ON1 JCLR1 Clear CMOS 1 x 3 header JCLR2 Reset &...

  • Page 14: Jumpers & Connectors Setting

    All manuals and user guides at all-guides.com WADE-8110 User’s Manual 2.3 Jumpers & Connectors setting 2.3.1 AMT1 PIN No. Description 1 -2 Debug Mode Normal 3 2 1 2.3.2 A_ON1 PIN No. Description Enable Disable 3 2 1 2.3.3 JCLR1 PIN No.
  • Page 15 All manuals and user guides at all-guides.com WADE-8110 User’s Manual 2.3.6 JLCD1 PIN No. Description 1-2 5V 2-3 3.3V 2.3.7 SDOM1 PIN No. Description 3 2 1 2.3.8 CPUFAN1 (Wafer 4*1, 2.54mm, 1-Wall) PIN No. Description FAN speed control FAN speed sense +12V 2.3.9...
  • Page 16 All manuals and user guides at all-guides.com WADE-8110 User’s Manual 2.3.10 PANEL1 (Pin Header, 5*2 2.54mm, pin10 empty) PIN No. Description PIN No. Description HD LED+ Power LED+ HD LED- Power LED- 5 GND Power Button 7 Re set Button 9 NC 2.3.11...
  • Page 17 All manuals and user guides at all-guides.com WADE-8110 User’s Manual 2.3.13 COM3, COM4 (BOX HEADER, 5*2, 2.54mm,LF) PIN No. Description PIN No. Description 1 COM portA DCD# COM portA DSR# 3 COM portA RXD# COM portA RTS# 5 COM portA TXD#...
  • Page 18 All manuals and user guides at all-guides.com WADE-8110 User’s Manual 2.3.16 SATA_PWR1 ~ 4 (Wafer, 4*1 2.0mm) PIN No. Description 1 +12V 2 GND 3 GND 4 VCC5 2.3.17 DC_IN1 (Power connector, 2*2) PIN No. Description PIN No. Description 1 GN...

  • Page 19: Chapter 3

    All manuals and user guides at all-guides.com WADE-8110 User’s Manual CHAPTER 3 19 / 26...

  • Page 20: System Installation

    SO-DIMM DDR3 has 204-pin and two notches which match the onboard SO-DIM M socket. Refer to WADE-8110 for memory specific details. Handle your new memory module carefully ; do not flex or bend it. Always grasp the module by its edges.

  • Page 21: Installations The Motherboard

    All manuals and user guides at all-guides.com WADE-8110 User’s Manual NOTE: For maintaining system stability, do not change any of memory parameters in BIOS setup to upgrade your system performance without acquiring technical information. Installations the motherboard To install the board into standard chassis or proprietary environment, you need to perform...

  • Page 22: Appendix

    All manuals and user guides at all-guides.com WADE-8110 User’s Manual Appendix 22 / 26...

  • Page 23: Appendix A: Wdt Programming Guide

    All manuals and user guides at all-guides.com WADE-8110 User’s Manual Appendix A: WDT Programming Guide Watch Dog Timer Time resolution 1 minute or 1 second, maximum 65535 minutes or 65535 seconds Output to KRST# when expired Base Address Two PNP I/O port addresses used for Watch Dog Timer accessing...
  • Page 24 All manuals and user guides at all-guides.com WADE-8110 User’s Manual WDT Control Timer Configuration Register Register Location: LDN=07h Index=72h Attribute: Read/Write Size: 8bit Bit Description WDT Time-out Value Select 1 1 : Second 0 : Minute WDT Output through KRST (Pulse) Enable (WOKE)
  • Page 25 All manuals and user guides at all-guides.com WADE-8110 User’s Manual WDT Control Timer Time-Out Value (MSB) Register Register Location: LDN=07h Index=74h Attribute: Read/Write Size: 8bit Bit Description WDT Time-out Value 15-8 (WTV) Code Example : #define WDT_IDX 0x2E #define WDT_DAT 0x2F // 1.
  • Page 26 All manuals and user guides at all-guides.com WADE-8110 User’s Manual outportb(WDT_DAT, 0x00); outportb(WDT_IDX, 0x71); // Watch dog control register outportb(WDT_DAT, 0x00); outportb(WDT_IDX, 0x72); // Watch dog timer configuration register outportb(WDT_DAT, 0x00); // 5. Leave MB PNP mode outportb(WDT_IDX, 0x02); // Exit outportb(WDT_DAT, 0x02);...
