- Page 1 Intel® Core™ i7/i5/i3 mobile Processor QM67 Mini ITX Mother Board User’s Manual Rev. 0.0 2011/04/27 1/26...
- Page 2 User’s Manual Copyright All rights reserved. The information contained in this guide has been v alidated and reviewed f or accuracy. No patent liability is assumed with respect to the use of th information contained herein. While every prec aution has been taken in the preparation of this guide, the Manufacturer assumes no responsibility for errors or omissions.
- Page 3 User’s Manual How to Use This Manual This manual is written for the system integr ator, PC technician and knowledgeable PC end user. It describes how to configure your to meet various operating requirements. The user ’s manual is divided int o three c hapters, with each chapter addressing a b asic concept and operation of the server board.
-
Page 4: Table Of Contents
User’s Manual Table of Content CHAPTER 1 ........................5 1. Introduction ......................... 6 1.1 Description ......................6 1.2 Dimensions ......................9 CHAPTER 2 ........................10 2. Hardware Configuration Setting ................11 2.1 Board Layout ..................... 12 2.2 Jumpers & Connectors ..................13 2.3 ... -
Page 5: Chapter 1
ADE-6065 User’s Manual CHAPTER 1 5 / 26... -
Page 6: Introduction
User’s Manual 1. Introduction Description Taking adv antages of Intel energy-ef ficient processing, Mini-ITX motherboard ® adopts 2 Generation Intel® Core™ processor family and Intel QM67 chip set to fit th e high performance computer system applic ations for meeting today’ s demanding p ace and keep complete comp atibility with hardware and software designed. - Page 7 User’s Manual Specifications WADE-8110 ® Intel Sandy Bridge – MB , rPGA.type Intel® Core™ i7-2710QE processors (2.1GHz, 45W) Intel® Core™ i5-2510E processors (2.5GHz, 35W) Intel® Core™ i3-2330E processors (2.2GHz, 35W) Intel® Celeron B810 processors (1.6GHz, 35W) BIOS AMI UEFI BIOS with 64 Mb SPI Flash ROM support AMT7.0 System Chipset Intel QM67 (Cougar Point –...
- Page 8 WADE-8110 User’s Manual Audio 3 x Audio Jacks for Line-out, MIC-input, Line-input PS/2 2 x Mini-DIN 6-pin Keyboard & Mouse Internal I/O SATA 4 x ( 1 x 7 ) SATA connector LVDS 1 x ( 2 x 20 ) 1.25mm pin-header for 24-bit with brightness control 2 x ( 2 x 5 ) 2.54mm pin-header for COM3 &...
-
Page 9: Dimensions
WADE-8110 User’s Manual Dimensions 9 / 26... -
Page 10: Chapter 2
ADE-6065 User’s Manual CHAPTER 2 10 / 26... -
Page 11: Hardware Configuration Setting
WADE-8110 User’s Manual 2. Hardware Configuration Setting This chapter gives the definitions and show s the positions of jumpers, headers and connectors. All of the configuration jumpers on the board are in the proper position. T he default settings shipped from factory are marked with an asterisk ( ). -
Page 12: Board Layout
WADE-8110 User’s Manual 2.1 Board Layout 12 / 26... -
Page 13: Jumpers & Connectors
WADE-8110 User’s Manual 2.2 Jumpers & Connectors JUMPERS FUNCTION REMARK AMT1 PLL Odvr Voltage 1 x 3 header A_ON1 Auto Power On Setting 1 x 3 header JCLR1 Clear CMOS 1 x 3 header JCLR2 Reset & Isolation Bypass 1 x 3 header... -
Page 14: Jumpers & Connectors Setting
WADE-8110 User’s Manual 2.3 Jumpers & Connectors setting 2.3.1 AMT1 PIN No. Description 1 -2 Debug Mode Normal 3 2 1 2.3.2 A_ON1 PIN No. Description Enable Disable 3 2 1 2.3.3 JCLR1 PIN No. Description Clear CMOS Keep CMOS 3 2 1 2.3.4... - Page 15 WADE-8110 User’s Manual 2.3.6 JLCD1 PIN No. Description 1-2 5V 2-3 3.3V 2.3.7 SDOM1 PIN No. Description 3 2 1 2.3.8 CPUFAN1 (Wafer 4*1, 2.54mm, 1-Wall) PIN No. Description FAN speed control FAN speed sense +12V 2.3.9 SYSFAN1 (Wafer 3*1, 2.54mm, 1-Wall) PIN No.
- Page 16 WADE-8110 User’s Manual 2.3.10 PANEL1 (Pin Header, 5*2 2.54mm, pin10 empty) PIN No. Description PIN No. Description HD LED+ Power LED+ HD LED- Power LED- 5 GND Power Button 7 Re set Button 9 NC 2.3.11 USB1, USB2 (Pin Header, 5*2 2.54mm, pin9 empty) PIN No.
- Page 17 WADE-8110 User’s Manual 2.3.13 COM3, COM4 (BOX HEADER, 5*2, 2.54mm,LF) PIN No. Description PIN No. Description 1 COM portA DCD# COM portA DSR# 3 COM portA RXD# COM portA RTS# 5 COM portA TXD# COM portA CTS# 7 COM portA DTR#...
- Page 18 WADE-8110 User’s Manual 2.3.16 SATA_PWR1 ~ 4 (Wafer, 4*1 2.0mm) PIN No. Description 1 +12V 2 GND 3 GND 4 VCC5 2.3.17 DC_IN1 (Power connector, 2*2) PIN No. Description PIN No. Description 1 GN DCIN (19V ~24V) 2 GN DCIN (19V ~24V) 2.3.18...
-
Page 19: Chapter 3
WADE-8110 User’s Manual CHAPTER 3 19 / 26... -
Page 20: System Installation
SO-DIMM DDR3 has 204-pin and two notches which match the onboard SO-DIM M socket. Refer to WADE-8110 for memory specific details. Handle your new memory module carefully ; do not flex or bend it. Always grasp the module by its edges. -
Page 21: Installations The Motherboard
WADE-8110 User’s Manual NOTE: For maintaining system stability, do not change any of memory parameters in BIOS setup to upgrade your system performance without acquiring technical information. Installations the motherboard To install the board into standard chassis or proprietary environment, you need to perform... -
Page 22: Appendix
WADE-8110 User’s Manual Appendix 22 / 26... -
Page 23: Appendix A: Wdt Programming Guide
WADE-8110 User’s Manual Appendix A: WDT Programming Guide Watch Dog Timer Time resolution 1 minute or 1 second, maximum 65535 minutes or 65535 seconds Output to KRST# when expired Base Address Two PNP I/O port addresses used for Watch Dog Timer accessing... - Page 24 WADE-8110 User’s Manual WDT Control Timer Configuration Register Register Location: LDN=07h Index=72h Attribute: Read/Write Size: 8bit Bit Description WDT Time-out Value Select 1 1 : Second 0 : Minute WDT Output through KRST (Pulse) Enable (WOKE) 1 : Enable 0 : Disable...
- Page 25 WADE-8110 User’s Manual WDT Control Timer Time-Out Value (MSB) Register Register Location: LDN=07h Index=74h Attribute: Read/Write Size: 8bit Bit Description WDT Time-out Value 15-8 (WTV) Code Example : #define WDT_IDX 0x2E #define WDT_DAT 0x2F // 1. Enter MB PNP mode outportb(WDT_IDX, 0x87);...
- Page 26 WADE-8110 User’s Manual outportb(WDT_DAT, 0x00); outportb(WDT_IDX, 0x71); // Watch dog control register outportb(WDT_DAT, 0x00); outportb(WDT_IDX, 0x72); // Watch dog timer configuration register outportb(WDT_DAT, 0x00); // 5. Leave MB PNP mode outportb(WDT_IDX, 0x02); // Exit outportb(WDT_DAT, 0x02); 26 / 26...
