INSTALLATION
RCI 8310IQ / 8320IQ
INTELLIMAG ® ELECTROMAGNETIC LOCKS
Pre-Installation Instructions
1.
This product must be installed according to all applicable
building and life safety codes.
2.
Due to the variety of mounting configurations available with
this product, a survey and assessment of the physical area in
which the product will be installed must be performed.
3.
The door frame must be inspected and deemed structurally
sound prior to installation of the electromagnetic lock. The
structural integrity of the mounting surfaces must be strong
enough to meet or exceed the holding force of the product.
4.
The product must be protected from potential damage due to
intruders or tampering.
5.
The product should be installed in a location that will not
hinder or create a potential safety hazard to authorized
personnel accessing the protected area.
6.
Because electromagnetic locks are used in a variety of
applications and different door frame configurations, an
experienced installer with knowledge of this product must
make a determination of the optimal mounting method for this
specific application.
7.
The components, hardware, installation instructions and
mounting template included with this product are intended for
use on outswinging doors.
1.
Mount the electromagnetic lock to the door frame as outlined
on the installation template included with the product.
NOTE: During installation of the armature plate to the door it is
essential that the armature plate remains movable. The armature
plate must be allowed to pivot on the center-mounting bolt to
allow proper alignment with the magnet surface. If the plate is not
aligned with the magnet surface, the lock may lose holding force
or not lock at all.
The head of the armature mounting bolt ships with a rubber
washer affixed to it. This washer should project slightly beyond
the surface of the armature plate. This is to allow the washer
to expand when power is removed and break the air vacuum
between the plate and the magnet surface. If this washer is
removed or trimmed the lock will appear to have some holding
force even when power is removed.
IS8310-IQ
PLEASE DELIVER ALL INSTALLATION INSTRUCTIONS TO
THE END-USER UPON COMPLETION OF THE INSTALLATION.
Installation Instructions
© 2019 dormakaba Canada Inc
www.dormakaba.us • Phone: 1.800.265.6630 • Fax: 1.800.482.9795 • E-mail: sales_RCI@dormakaba.com
8.
Do not install this product on the exterior of buildings.
9.
Do not use as a doorstop. This will void warranty.
10. Separate accessories must be used in the following
applications:
• Inswinging doors
• Narrow head jamb situations or center-hung doors
• Wherever there is insufficient space on the door
frame header to mount the lock
• Glass or Herculite doors that don't have a door frame
• Hollow metal or wood frames where the door
stop is not thick enough to allow the product to
be installed
• Wherever an obstruction in the door prevents
installation of the armature plate at a proper height
• Doors that do not permit the armature plate to
be mounted low enough to meet the magnet
surface
Refer to the page 5 & 6 Product Accessories Guide for
further information. Accessories may impact holding force.
11. Installation of this product should be done by an
experienced installer with knowledge of this product.
NOTE: It is highly recommended that thread locking
compound be applied to all screws during installation to
reduce chance of screws loosening over extended time.
For added safety, thread locking compound has been provided
for the armature plate bolt and the four captive electromagnetic
lock mounting screws.
WARNING: Improper installation, maintenance, inspection
or usage of the product or any related accessories or parts
may cause the electromagnetic lock, armature plate and
associated hardware to disengage and fall, causing serious
bodily injury and property damage. dormakaba Canada Inc.
and/or dormakaba USA Inc. will not be liable to the installer,
purchaser, end user or anyone else for damage or injury
to person or property due to improper installation, care,
storage, handling, maintenance, inspection, abuse, misuse
or act of God or nature involving this product or any related
accessories or parts.
2.
Route the power supply connecting wire through the door
frame and into the wire access hole in the top of the magnet
housing. Connecting wire should be of sufficient gauge for
the lock being installed and the distance being run.
PCN18040
R08-19GR-1
