- Page 1 MAB-T600-B1 Barebone System with RX680H Chipset Quick Reference Guide Ed –20 March 2024 Copyright Notice Copyright © 2024 Avalue Technology Inc., ALL RIGHTS RESERVED. Part No. E2017GAR1A0R...
- Page 2 MAB-T600-B1 Document Amendment History Revision Date Comment March 2024 Avalue Initial Release 2 MAB-T600-B1 Quick Reference Guide...
-
Page 3: Declaration Of Conformity
For detailed information, please always refer to the electronic user's manual. Copyright Notice © 2024 by Avalue Technology Inc. All rights are reserved. No parts of this manual may be copied, modified, or reproduced in any form or by any means for commercial use without the prior written permission of Avalue Technology Inc. - Page 4 ㆍDescription of your software (operating system, version, application software, etc.) ㆍA complete description of the problem ㆍThe exact wording of any error messages To receive the latest version of the user’s manual; please visit our Web site at: www.avalue.com 4 MAB-T600-B1 Quick Reference Guide...
- Page 5 On the other hand, if the new product defect is resulting from incorrect configuration or erroneous use by the user instead of any problem of the hardware itself, the customer will also be requested to pay for relevant handling fees. MAB-T600-B1 Quick Reference Guide...
- Page 6 Lacking detailed statement of fault steps also makes the problem hard to be identified, sometimes resulting in second-time repairs. 6 MAB-T600-B1 Quick Reference Guide...
- Page 7 In case of unexpected factors causing Avalue to be unable to repair/replace a warranted but phased-out product, Avalue will, depending on the availability, upgrade the product (free of charge with continued MAB-T600-B1 Quick Reference Guide...
-
Page 8: Safety Instructions
4. For plug-in equipment, the power outlet socket must be located near the equipment and must be easily accessible. 5. Keep this equipment away from humidity. 6. Put this equipment on a reliable surface during installation. Dropping it or letting it fall may cause damage. 8 MAB-T600-B1 Quick Reference Guide... - Page 9 The equipment has obvious signs of breakage. 13. CAUTION: Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended by the manufacturer. 14. Equipment intended only for use in a RESTRICTED ACCESS AREA. MAB-T600-B1 Quick Reference Guide...
-
Page 10: Explanation Of Graphical Symbols
A NOTE provides additional information intended to avoid Note inconveniences during operation. Direct current. Alternating current Stand-by, Power on FCC Certification CE Certification Follow the national requirements for disposal of equipment. Stacking layer limit This side up 10 MAB-T600-B1 Quick Reference Guide... - Page 11 Quick Reference Guide Fragile Packaging Beware of water damage, moisture-proof Carton recyclable Handle with care Follow operating instructions of consult instructions for use. Storage &Transportation Temperature: -20°C ~ 60°C Storage &Transportation Humidity: 10% ~ 95% High Temperature MAB-T600-B1 Quick Reference Guide 11...
-
Page 12: Disposing Of Your Old Product
EXPLOSION ou une fuite de liquide ou de gaz inflammable. - UNE BATTERIE soumise à une pression d'air extrêmement basse pouvant entraî ner une EXPLOSION ou une fuite de liquide ou de gaz inflammable. 12 MAB-T600-B1 Quick Reference Guide... -
Page 13: Table Of Contents
2.5.17 LAN LED status connector (LAN_LED1) ................37 2.5.18 Chassis intrusion connector (INTRUD1) ................38 2.5.19 8-bit GPIO header (GPIO_HDR1) ..................38 2.5.20 SMBUS/I2C/KMBS connectors (J_SMB1, J_I2C1, J57) ............39 3.BIOS Setup ........................40 3.1 Introduction ......................41 MAB-T600-B1 Quick Reference Guide 13... - Page 14 Chipset ........................... 61 3.6.3.1 System Agent (SA) Configuration ..................62 3.6.3.1.1 Memory Configuration ...................... 62 3.6.3.1.2 Graphics Configuration ..................... 63 3.6.3.1.3 VMD setup menu ......................64 3.6.3.2 PCH-IO Configuration ....................... 64 3.6.3.2.1 PCI Express Configuration ....................65 14 MAB-T600-B1 Quick Reference Guide...
- Page 15 3.6.4.2.1 Key Management......................77 3.6.5 Boot……… ..........................78 3.6.6 Save & Exit ..........................80 3.6.6.1 AMI FW update interface ....................81 3.6.7 MEBx ............................. 82 4. Maintenance & Troubleshooting................. 83 5. Product Application ..................... 89 MAB-T600-B1 Quick Reference Guide 15...
-
Page 16: Getting Started
MAB-T600-B1 1. Getting Started Safety Precautions 1.1 Packing List Before installation, please ensure all the items listed in the following table are included in the package. Item Description Q’ty MAB-T600-B1 Barebone system Power cord 16 MAB-T600-B1 Quick Reference Guide... - Page 17 Step 3: Carefully cut the tape sealing the box. Only cut deep enough to break the tape. Step 4: Open the inside box. Step 5: Lift the box PC out of the boxes. Step 6: Remove the peripheral parts box from the main box. MAB-T600-B1 Quick Reference Guide 17...
-
Page 18: System Specifications
1 x Power Button (with LED indicator) Rear I/O 6 x USB 3.2 Gen 2x1 Ports USB Port 1 x USB 3.2 Gen 2x2 Type-C 4 x DP++ Audio Line-out, Mic-in LAN Port 2 x RJ-45 Onboard I/O 18 MAB-T600-B1 Quick Reference Guide... - Page 19 Sine Vibration test (Non-operation) 1 Test Acceleration : 2G 2 Test frequency : 5~500 Hz 3 Sweep：1 Oct/ per one minute. (logarithmic) 4 Test Axis : X,Y and Z axis 5 Test time :30 min. each axis MAB-T600-B1 Quick Reference Guide 19...
- Page 20 1 One corner , three edges, six faces 2 ISTA 2A, IEC-60068-2-32 Test:Ed IP Rating IPX1 Grade Protection Software Support OS Information Windows 10, Windows 11, Linux Note: Specifications are subject to change without notice. 20 MAB-T600-B1 Quick Reference Guide...
-
Page 21: System Overview
6 x USB3.2 connector USB Type-C USB Type-C connector suggest using shielded LAN cables to 2 x RJ-45 Ethernet increase stability. 4 x DP connector LINE OUT Line-out audio jack MIC IN Mic-in audio jack Power Power switch MAB-T600-B1 Quick Reference Guide 21... -
Page 22: System Dimensions
MAB-T600-B1 1.4 System Dimensions (Unit: mm) 22 MAB-T600-B1 Quick Reference Guide... -
Page 23: Operating Principle
- Turn ON the system. - Press the power ON/OFF icon firmly to turn power ON/OFF. - The power ON/OFF LED will turn blue to indicate power is on. - Check with the Icon behavior for power status. MAB-T600-B1 Quick Reference Guide 23... -
Page 24: Hardware Configuration
MAB-T600-B1 2 Hardware Configuration For advanced information, please refer to: 1- RX680R included in this manual. Note: If you need more information, please visit our website: www.avalue.com 24 MAB-T600-B1 Quick Reference Guide... -
Page 25: Powering On The System
Then, plug the power cord plug into the socket of the power source. Finally, turn on the power switch. The supported power input voltages is 100V-240V. Power Button Power Switch MAB-T600-B1 Quick Reference Guide 25... -
Page 26: Rx680R Overviews
MAB-T600-B1 2.3 RX680R Overviews 26 MAB-T600-B1 Quick Reference Guide... -
Page 27: Rx680R Jumpers & Connectors List
ATX Power Connector PWR Conn 2x12P ATX12V 12V ATX Power Connector PWR Conn 2x4P COM1~COM6 Serial Port Connectors WAFER 2x5P, 2.00mm SATA1~4 SATA Connectors Male Connectors (RED) USB2_HR1~4 Front USB 2.0 Headers BOX header 2x5P, 2.54mm MAB-T600-B1 Quick Reference Guide 27... - Page 28 GPIO 8 bits Connector WAFER 2x6P, 2.00mm J_I2C1 I2C Connector WAFER 1x4P, 2.00mm J_SMB1 SMBUS Connector WAFER 1x5P, 2.00mm SPI_HDR1 SPI Header 2x4 header, 2.54mm eSPI Header 2x5 header, 2.00mm KBMS Header WAFER 1x 6P, 2.54mm 28 MAB-T600-B1 Quick Reference Guide...
-
Page 29: Rx680R Jumpers & Connectors Settings
Quick Reference Guide 2.5 RX680R Jumpers & Connectors settings 2.5.1 Clear CMOS (CMOS1) Normal* Clear CMOS * Default 2.5.2 AT/ATX Mode Select (AT1) ATX mode * AT mode * Default MAB-T600-B1 Quick Reference Guide 29... -
Page 30: Com Power Setting (J56,J45~J48,J25)
MAB-T600-B1 2.5.3 COM POWER SETTING (J56,J45~J48,J25) Ring* +12V * Default 2.5.4 LVDS Panel Power Select (PANEL_SEL1) +12V +5V* * Default 30 MAB-T600-B1 Quick Reference Guide... -
Page 31: Lvds Blacklight Voltage Selection (Bklvol1)
Quick Reference Guide 2.5.5 LVDS Blacklight Voltage Selection (BKLVOL1) +3V * * Default 2.5.6 CPU and System fan connectors (CPU_FAN1, SYS_FAN1, SYS_FAN2) SYS_FAN1 4.FAN CTRL SYS_FAN2 3.FAN_TACH 2.+12V 1.GND CPU_FAN1 MAB-T600-B1 Quick Reference Guide 31... -
Page 32: System Panel (Fio_Panel1)
MAB-T600-B1 2.5.7 System Panel (FIO_PANEL1) 1.HDD LED+ 2.PWR LED+ 3.HDD LED- 4.PWR LED- 5.GND 6.PWR_BTN 7.RST 8.GND 9.NA 10.KEY 2.5.8 ATX power connectors (ATX24P_1 & ATX12V) ATX12V ATX24P_1 32 MAB-T600-B1 Quick Reference Guide... -
Page 33: Serial Port Connectors (Com1~6)
Quick Reference Guide 2.5.9 Serial Port connectors (COM1~6) 9.IRxPWRxJMP 8.NCTS 7.NRTS 6.NDSR 5.GND 4.NDTR 3.NTX 2.NRX 1.NDCD 2.5.10 Serial ATA connectors (SATA1~4) MAB-T600-B1 Quick Reference Guide 33... -
Page 34: Usb Connectors (Usb2_Hr1, Usb2_Hr2, Usb2_Hr3, Usb2_Hr4)
1.+5V USB 2.5.12 USB3.2 connector (USB3_HR1) 10.NC 19.+5V USB 9.USB2 D+ 18.USB3 RX- 8.USB2 D- 17.USB3 RX+ 7.GND 16.GND 6.USB3_TX+ 15.USB3 TX- 5.USB3_TX- 14.USB3 TX+ 4.GND 13.GND 3.USB3_RX+ 12.USB2 D- 2.USB3_RX- 11.USB2 D+ 1.+5V USB 34 MAB-T600-B1 Quick Reference Guide... -
Page 35: Front Audio Connector (Fio_Aud1)
Quick Reference Guide 2.5.13 Front Audio connector (FIO_AUD1) 1.MIC2_L 2.GND 3.MIC2_R 4.FP_HDADET 5.LINE2_R 6.MIC2_JD 7.FR-IO-SENSE 8.KEY 9.LINE2_L 10.LINE2_JD 2.5.14 Amplifier connector (SPK1) 1.ROUT- 2.ROUT+ 3.LOUT- 4.LOUT+ MAB-T600-B1 Quick Reference Guide 35... -
Page 36: Lvds Connector (Lvds1)
36.LS0_CLK_D- 33.LS1_CLK_D+ 34.LS0_CLK_D+ 31.GND 32.GND 29.LS1_L3_D- 30.LS1_L2_D- 27.LS1_L3_D+ 28.LS1_L2_D+ 25.GND 26.GND 23.LS1_L1_D- 24.LS1_L0_D- 21.LS1_L1_D+ 22.LS1_L0_D+ 19.GND 20.GND 17.LS0_L3_D- 18.LS0_L2_D- 15.LS0_L3_D+ 16.LS0_L2_D+ 13.GND 14.GND 11.LS0_L1_D- 12.LS0_L0_D- 9.LS0_L1_D+ 10.LS0_L0_D+ 7.CABLE_ID1 8.GND 5.LS_SCL 6.LS_SDA 3.+3V 4.+5V(PANEL_PWR) 1.+3V 2.+5V(PANEL_PWR) 36 MAB-T600-B1 Quick Reference Guide... -
Page 37: Lvds Backlight Connector (Bklt1)
2.5.16 LVDS Backlight connector (BKLT1) 1.+12V_BL 2.GND 3.BKLT_EN 4.BKLT_PWM 5.+5V_BL 2.5.17 LAN LED status connector (LAN_LED1) 1. 1G_LAN1_LED 2. 1G_LAN2_LED 3. GND 4. GND 5. 2.5G_LAN1_LED 6. 2.5G_LAN2_LED 7. GND 8. GND 9. LAN1_ACT 10. LAN2_ACT MAB-T600-B1 Quick Reference Guide 37... -
Page 38: Chassis Intrusion Connector (Intrud1)
2.5.18 Chassis intrusion connector (INTRUD1) 1.PCH_INTRUDER# 2.GND 2.5.19 8-bit GPIO header (GPIO_HDR1) 1. AP_GPIO1 2. AP_GPIO5 3. AP_GPIO2 4. AP_GPIO6 5. AP_GPIO3 6. AP_GPIO7 7. AP_GPIO4 8. AP_GPIO8 9. SMB_CLK 10. SMB_DATA 11.GND 12. +3V_DUAL 38 MAB-T600-B1 Quick Reference Guide... -
Page 39: Smbus/I2C/Kmbs Connectors (J_Smb1, J_I2C1, J57)
2.5.20 SMBUS/I2C/KMBS connectors (J_SMB1, J_I2C1, J57) 1. +3V_DUAL 2. I2C1_SCL 3. I2C1_SDA 4. GND 1. SMB_CLK 2. SMB_DATA 3. SMB_ALERT 4. GND 5. +3.3V 1. KCLK 2. KDAT 3. MDAT 4. GND 5. +5V_DUAL 6. MCLK MAB-T600-B1 Quick Reference Guide 39... -
Page 40: Bios Setup
MAB-T600-B1 3.BIOS Setup 40 MAB-T600-B1 Quick Reference Guide... -
Page 41: Introduction
If you do not press the keys at the correct time and the system does not boot, an error message will be displayed and you will again be asked to. Press F1 to Continue, DEL to enter SETUP MAB-T600-B1 Quick Reference Guide 41... -
Page 42: Using Setup
Note: Some of the navigation keys differ from one screen to another. • To Display a Sub Menu Use the arrow keys to move the cursor to the sub menu you want. Then press <Enter>. A “➢” pointer marks all sub menus. 42 MAB-T600-B1 Quick Reference Guide... -
Page 43: Getting Help
BIOS Vendor and your systems manufacturer to provide the absolute maximum performance and reliability. Even a seemingly small change to the chipset setup has the potential for causing you to use the override. MAB-T600-B1 Quick Reference Guide 43... -
Page 44: Bios Setup
Note: The BIOS setup screens shown in this chapter are for reference purposes only, and may not exactly match what you see on your screen. Visit the Avalue website (www.avalue.com) to download the latest product and BIOS information. 44 MAB-T600-B1 Quick Reference Guide... -
Page 45: Advanced Menu
3.6.2.1 CPU Configuration ⚫ Intel Trusted Execution Technology [Disabled] Enables utilization of additional hardware capabilities provided by Intel ® Trusted Execution Technology. Changes require a full power cycle to take effect Configuration options: [Disabled] [Enabled] MAB-T600-B1 Quick Reference Guide 45... -
Page 46: Power & Performance
AMT BIOS Features [Enabled] When disabled AMT BIOS Features are no longer supported and user is no longer able to access MEBx Setup. Note: This option does not disable Manageability Features in FW options: [Disabled] [Enabled] 46 MAB-T600-B1 Quick Reference Guide... -
Page 47: Tpm Config
Configuration options: [Enable] [Disable] ⚫ Pending operation [None] Schedule an Operation for the Security Device. NOTE: Your Computer will reboot during restart in order to change State of Security Device Configuration options: [None] [TPM Clear] MAB-T600-B1 Quick Reference Guide 47... -
Page 48: Acpi Settings
Configuration options: [Disabled] [Enabled] ⚫ ACPI Sleep State [S3 (Suspend to RAM)] Select the highest ACPI sleep state the system will enter the SUSPEND button is pressed. Configuration options: [Suspend Disabled] [S3 (suspend to RAM)] 48 MAB-T600-B1 Quick Reference Guide... -
Page 49: Nct6126D Super Io Configuration
Enable or Disable serial Port (COM) Configuration options: [Disabled] [Enabled] ⚫ Change Setting [Auto] Select an optimal settings for super IO device Configuration options: [Auto] [IO=3F8h; IRQ4] [IO=3F8h; IRQ3,4,5,6,7,9,10,11,12] [IO=2F8h; IRQ3,4,5,6,7,9,10,11,12] [IO=3E8h; IRQ3,4,5,6,7,9,10,11,12] [IO=2E8h; IRQ3,4,5,6,7,9,10,11,12] MAB-T600-B1 Quick Reference Guide 49... -
Page 50: Serial Port 2 Configuration
Enable or Disable serial Port (COM) Configuration options: [Disabled] [Enabled] ⚫ Change Setting [Auto] Select an optimal settings for super IO device Configuration options: [Auto] [IO=3E8h; IRQ7] [IO=3E8h; IRQ3,4,5,6,7,9,10,11,12] [IO=2E8h; IRQ3,4,5,6,7,9,10,11,12] [IO=220h; IRQ3,4,5,6,7,9,10,11,12] [IO=228h; IRQ3,4,5,6,7,9,10,11,12] 50 MAB-T600-B1 Quick Reference Guide... -
Page 51: Serial Port 4 Configuration
Serial Port [Enabled] Enable or Disable serial Port (COM) Configuration options: [Disabled] [Enabled] ⚫ Change Setting [Auto] Select an optimal settings for super IO device Configuration options: [Auto][IO=220h; IRQ10][IO=3E8h; IRQ3,4,5,6,7,9,10,11,12] [IO=2E8h; IRQ3,4,5,6,7,9,10,11,12] [IO=220h; IRQ3,4,5,6,7,9,10,11,12] [IO=228h; IRQ3,4,5,6,7,9,10,11,12] MAB-T600-B1 Quick Reference Guide 51... -
Page 52: Serial Port 6 Configuration
Serial Port [Enabled] Enable or Disable serial Port (COM) Configuration options: [Disabled] [Enabled] ⚫ Change Setting [Auto] Select an optimal settings for super IO device Configuration options: [Auto][IO=378h; IRQ5][IO=378h; IRQ5,6,7,9,10,11,12] [IO=378h; IRQ5,6,7,9,10,11,12] [IO=278h; IRQ5,6,7,9,10,11,12] [IO=3BCh; IRQ5,6,7,9,10,11,12] 52 MAB-T600-B1 Quick Reference Guide... -
Page 53: Hardware Monitor
Configuration options: [STD Printer Mode SPP Mode] [EPP-1.9 and SPP Mode] [EPP-1.7 and SPP Mode ECP Mode] [ECP and EPP 1.9 Mode] [ECP and EPP 1.7 Mode] 3.6.2.6 Hardware monitor Display Hardware monitor information 3.6.2.6.1 Smart FAN MAB-T600-B1 Quick Reference Guide 53... -
Page 54: Front Fan Setting
The value of Fan Duty/RPM 2 when temperature is T2 Configuration options: By Fan Duty ⚫ FD / RPM 3 [178] The value of Fan Duty/RPM 3 when temperature is T3 Configuration options: By Fan Duty 54 MAB-T600-B1 Quick Reference Guide... -
Page 55: Cpu Fan Setting
The value of Fan Duty/RPM 1 when temperature is T1 Configuration options: By Fan Duty ⚫ FD / RPM 2 [127] The value of Fan Duty/RPM 2 when temperature is T2 Configuration options: By Fan Duty MAB-T600-B1 Quick Reference Guide 55... -
Page 56: Rear Fan Setting
Configuration options: By temperature ⚫ Temperature 4 [70] The value of temperature 4 Configuration options: By temperature ⚫ FD / RPM 1 [76] The value of Fan Duty/RPM 1 when temperature is T1 Configuration options: By Fan Duty 56 MAB-T600-B1 Quick Reference Guide... -
Page 57: S5 Rtc Wake Settings
Wake system from S5 [Disabled] Enable or disable System wake on alarm event. Select FixedTime, system will wake on the hr::min::sec specified. Select DynamicTime. System will wake on the current time+Increase minute(s). Configuration options: [Disabled] [Fixed Time] [Dynamic Time] MAB-T600-B1 Quick Reference Guide 57... -
Page 58: Ami Graphic Output Protocol Policy
[1366x768 18bit Single Channel] [1366x768 24bit Single Channel] [1440x900 24bit Single Channel] [1440x1050 24bit Single Channel] [1600x900 24bit Single Channel] [1680x1050 24bit Single Channel] [1600x1200 24bit Single Channel] [1920x1080 24bit Single Channel] [1920x1200 24bit Single Channel] 58 MAB-T600-B1 Quick Reference Guide... -
Page 59: Usb Configuration
Configuration options: [10 sec] [20 sec] [[30 sec] [40 sec] ⚫ Device reset time-out [20 sec] USB mass storage device Start Unit command time-out. Configuration options: [10 sec] [20 sec] [[30 sec] [40 sec] ⚫ Device power-up delay [Auto] MAB-T600-B1 Quick Reference Guide 59... -
Page 60: Network Stack Configuration
Enable/Disable Ipv4 PXE Boot Support. If disabled IPV4 PXE boot support will not be available. Configuration options: [Disabled] [Enabled] ⚫ IPv6 PXE Support [Disabled] Enable/Disable Ipv6 PXE Boot Support. If disabled IPV6 PXE boot support will not be available. Configuration options: [Disabled] [Enabled] 60 MAB-T600-B1 Quick Reference Guide... -
Page 61: Nvme Configuration
Quick Reference Guide 3.6.2.11 NVMe Configuration 3.6.3 Chipset MAB-T600-B1 Quick Reference Guide 61... -
Page 62: System Agent (Sa) Configuration
MAB-T600-B1 3.6.3.1 System Agent (SA) Configuration ⚫ VT-d [Enabled] VT-d capability Configuration options: [Disabled] [Enabled] 3.6.3.1.1 Memory Configuration 62 MAB-T600-B1 Quick Reference Guide... -
Page 63: Graphics Configuration
Configuration options: [64M] [32M/F7] [36M] [40M] [44M] [48M] [52M] [56M] [60M] ⚫ DVMT Total Gfx Mem [256M] Select DVMT5.0 Total Graphic Memory size used by the Internal Graphics Device. Configuration options: [128M] [256M] [MAX] MAB-T600-B1 Quick Reference Guide 63... -
Page 64: Vmd Setup Menu
Configuration options: [Enabled] [Disabled] ⚫ LVDS Board I225 LAN2 Controller [Enabled] Enable or disable onboard I225 LAN 2. Configuration options: [Enabled] [Disabled] ⚫ Wake On Lan from LAN Device [Enabled] Enable or disable WOL from I225 LAN Device. 64 MAB-T600-B1 Quick Reference Guide... -
Page 65: Pci Express Configuration
Configuration options: [S0 State] [S5 State] [Last State] ⚫ GPIO Group Control [Disabled] GPIO Header Control Enable/Disable. Configuration options: [Disabled] [Enabled] ⚫ Chassis Intrusion [Disabled] Configure Chassis Intrusion. Configuration options: [Disabled] [Enabled] [Reset] 3.6.3.2.1 PCI Express Configuration MAB-T600-B1 Quick Reference Guide 65... -
Page 66: Pci Express M.2 E
DISABLE - Disables ASPM Configuration options: [Disabled] [L1] [Auto] ⚫ L1 Substates [L1.1 & L1.2] PCI Express L1 Substates settings. Configuration options: [Disabled] [L1.1] [L1.1 & L1.2] ⚫ PCIe Speed [Auto] Configure PCIe Speed Configuration options: [Auto][Gen1][Gen2][Gen3] 66 MAB-T600-B1 Quick Reference Guide... -
Page 67: Pci Express M.2 M
Configuration options: [Disabled] [L1] [Auto] ⚫ L1 Substates [L1.1 & L1.2] PCI Express L1 Substates settings. Configuration options: [Disabled] [L1.1] [L1.1 & L1.2] ⚫ PCIe Speed [Auto] Configure PCIe Speed Configuration options: [Auto] [Gen1] [Gen2] [Gen3] MAB-T600-B1 Quick Reference Guide 67... -
Page 68: Pci Express X4 Open End
DISABLE - Disables ASPM Configuration options: [Disabled] [L1] [Auto] ⚫ L1 Substates [L1.1 & L1.2] PCI Express L1 Substates settings. Configuration options: [Disabled] [L1.1] [L1.1 & L1.2] ⚫ PCIe Speed [Auto] Configure PCIe Speed Configuration options: [Auto][Gen1][Gen2][Gen3] 68 MAB-T600-B1 Quick Reference Guide... -
Page 69: Pci Express X4 Slot3
DISABLE - Disables ASPM Configuration options: [Disabled] [L1] [Auto] ⚫ L1 Substates [L1.1 & L1.2] PCI Express L1 Substates settings. Configuration options: [Disabled] [L1.1] [L1.1 & L1.2] ⚫ PCIe Speed [Auto] Configure PCIe Speed Configuration options: [Auto][Gen1][Gen2][Gen3] MAB-T600-B1 Quick Reference Guide 69... -
Page 70: Pci Express X4 Slot4
DISABLE - Disables ASPM Configuration options: [Disabled] [L1] [Auto] ⚫ L1 Substates [L1.1 & L1.2] PCI Express L1 Substates settings. Configuration options: [Disabled] [L1.1] [L1.1 & L1.2] ⚫ PCIe Speed [Auto] Configure PCIe Speed Configuration options: [Auto][Gen1][Gen2][Gen3] 70 MAB-T600-B1 Quick Reference Guide... -
Page 71: E Cnvi Configuration
Wi-Fi Core [Enabled] This is an option intended to Enable/Disable Wi-Fi Core in CNVi Configuration options: [Disabled] [Enabled] ⚫ BT Core [Enabled] This is an option intended to Enable/Disable BT Core in CNVi Configuration options: [Enabled] [Disabled] MAB-T600-B1 Quick Reference Guide 71... -
Page 72: Sata Configuration
Configuration options: [Disabled] [Enabled] ⚫ Rear IO USB3 Gen1 Power [Enabled] Enable/Disable Upper/Lower USB ports of HDMI Rack. Configuration options: [Disabled] [Enabled] ⚫ Rear IO LAN2 USB3 Gen2 Power [Enabled] Enable/Disable Upper/Lower USB ports of i211 RJ45 Rack. 72 MAB-T600-B1 Quick Reference Guide... -
Page 73: Hd Audio Configuration
Configuration options: [Disabled] [Enabled] 3.6.3.2.4 HD Audio Configuration ⚫ HD Audio [Enabled] Control Detection of HD-Audio device. Disabled = HDA will be unconditionally disabled Enabled = HDA will be unconditionally enabled Configuration options: [Enabled] [Disabled] MAB-T600-B1 Quick Reference Guide 73... -
Page 74: Security
Set Administrator Password ⚫ User Password Set User Password ⚫ HDD Security drive Press Enter when selected to go into the associated Sub-Menu. ⚫ SSD Security drive Press Enter when selected to go into the associated Sub-Menu. 74 MAB-T600-B1 Quick Reference Guide... -
Page 75: Hdd Security
Disk Passwords ***.Discard or Save changes option in setup does not have any impact on HDD when password is set or removed. If the 'Set HDD User Password' option is hidden, do power cycle to enable the option again. MAB-T600-B1 Quick Reference Guide 75... -
Page 76: Security Boot
Configuration options: [Enabled] [Disabled] ⚫ Secure Boot Mode [Custom] Secure Boot mode options:Standard or Custom. In Custom mode, Secure Boot Policy variables can be configured by a physically present user without full authentication Configuration options: [Standard] [Custom] 76 MAB-T600-B1 Quick Reference Guide... -
Page 77: Key Management
Quick Reference Guide 3.6.4.2.1 Key Management ⚫ Factory Key Provision [Disabled] Install factory default Secure Boot keys after the platform reset and while the System is in Setup mode Configuration options: [Enabled] [Disabled] MAB-T600-B1 Quick Reference Guide 77... -
Page 78: Boot
Sets the system boot order. Configuration options: [USB Floppy] [CD/DVD] [USB CD/DVD] [Hard Disk] [USB Key] [USB Hard Disk] [NVME] [Network] [UEFI AP] [Disabled] ⚫ Boot Option #3 [USB CD/DVD] Sets the system boot order. 78 MAB-T600-B1 Quick Reference Guide... - Page 79 Key] [USB Hard Disk] [NVME] [Network] [UEFI AP] [Disabled] ⚫ Boot Option #8 [UEFI AP] Sets the system boot order. Configuration options: [USB Floppy] [CD/DVD] [USB CD/DVD] [Hard Disk] [USB Key] [USB Hard Disk] [NVME] [Network] [UEFI AP] [Disabled] MAB-T600-B1 Quick Reference Guide 79...
-
Page 80: Save & Exit
Save Changes and Reset Reset the system after saving the changes. ⚫ Discard Changes and Reset Reset system setup without saving any changes. ⚫ Restore Defaults Restore/Load default values for all the setup option. ⚫ AMIFWUpdate Launches AMIFWUpdate. 80 MAB-T600-B1 Quick Reference Guide... -
Page 81: Ami Fw Update Interface
Quick Reference Guide 3.6.6.1 AMI FW update interface Update ROM file via the AMI Firmware Update interface, Click “AMIFWupdate” on BIOS setup menu’s “Save and Exit” page and following below steps to update the BIOS. MAB-T600-B1 Quick Reference Guide 81... -
Page 82: Mebx
MAB-T600-B1 3.6.7 MEBx ⚫ Intel® ME Password MEBx Login. 82 MAB-T600-B1 Quick Reference Guide... -
Page 83: Maintenance & Troubleshooting
System Maintenance Introduction If the components of the product fail they must be replaced. Please contact the system reseller or vendor to purchase the replacement parts. Please follow the safety precautions outlined in the sections that follow MAB-T600-B1 Quick Reference Guide 83... -
Page 84: General Safety Precautions
This equipment is not suitable for use in locations where children are likely to be present. DO NOT: ⚫ Drop the device against a hard surface. ⚫ In a site where the ambient temperature exceeds the rated temperature. 84 MAB-T600-B1 Quick Reference Guide... -
Page 85: Anti - Static Precautions
This reduces the possibility of ESD damage. ⚫ Only handle the edges of the electrical component. When handling the electrical component, hold the electrical component by its edges. Please ensure the following safety precautions are adhered to at all times. MAB-T600-B1 Quick Reference Guide 85... -
Page 86: Maintenance And Cleaning
Never drop any objects or liquids through the openings of the device. ⚫ Be cautious of any possible allergic reactions to solvents or chemicals used when cleaning the device. ⚫ Avoid eating, drinking and smoking within vicinity of the device. 86 MAB-T600-B1 Quick Reference Guide... -
Page 87: Cleaning Tools
Cotton swabs: Cotton swaps moistened with rubbing alcohol or water are excellent tools for wiping hard to reach areas. ⚫ Foam swabs: Whenever possible, it is best to use lint free swabs such as foam swabs for cleaning. MAB-T600-B1 Quick Reference Guide 87... -
Page 88: Basic Troubleshooting
No Console Input Devices are found Flash update is failed Typically for development use. The beep code is generated when platform cannot be reset because reset protocol is not available. Platform PCI resource requirements cannot be met 88 MAB-T600-B1 Quick Reference Guide... -
Page 89: Product Application
Avalue technical support team, or Avalue customer service representatives for further information. Feel free to inquire about this supplementary resource to enhance your understanding of the Watchdog Timer and Digital I/O (DIO) Application for optimal utilization of your box PC. MAB-T600-B1 Quick Reference Guide 89...
