Dreadbox NYX Owner's Manual page 9

MIDI/AUDIO INTERFACE:
OUT: Master Output of NYX. It can also be connected to
headphones.
IN 1: Mono input to the Filter 2. If the synth is not
triggered, the sound will not pass through.
IN 2
IN 2: Mono input to the Filter 1. If the synth is not
triggered, the sound will not pass through.
OUT IN 1 mIDI
MIDI: Midi input. Use only the type-A dedicated Midi
adapter included in the box.
2.10 Eurorack
In order to use the Nyx Reissue in a eurorack case, do the following:
A. Unscrew the 4 corner bolts, which keep the module attached to the case
B. Remove the module from the case. Afterwards, unscrew the 2 bolts that connect the small PCB
to the USB adapter and detach them.
C. Plug the provided ribbon cable and connect it to the power bus board of a eurorack case whilst
it is OFF.
