Opertion

SWING Operation

COOL/DRY/FAN:
MODE I FEEL
SLEEP
HEAT:
AUTO:
EXTRA
HEALTH
FUNCTION
AIRFLOW ECOSENSOR
TIME TIME CONFIRM
ON
OFF
CANCEL
Initial state
LOCK LIGHT RESET
2.
Left and right air flow direction
For each press of the button, air flow direction on remote control-
ler displays as follows
Initial state
NOTE:
1. When humidity is high, condensate water might occur at air
outlet if all vertical louvers are adjusted to left or right.
2. It is not advisable to keep horizontal flap at downward posi-
tion for a long time in COOL or DRY mode, otherwise, con-
densate water might occur.
3. As cold air flows downward in COOL mode, adjusting air
flow horizontally will be much more helpful for a better air cir-
culation.
1.
Up and down air flow direction
For each press of the button, air
flow direction on remote controller
displays as follows according to
different operation modes:
MODE I FEEL
SLEEP
HEALTH
EXTRA
AIRFLOW FUNCTION
ECOSENSOR
CONFIRM
TIME TIME
ON
OFF CANCEL
LOCK LIGHT RESET
Attention:
1.Do not direct the flap by hand. Otherwise, the grille will run incor-
rectly. If the grille does not run correctly, stop for a minute and then
start, and adjust by using the remote controller.
2. 2.Remote controller can memorize each operation status. Wh
starting it next time, just press ON/OFF button and unit will run in
previous status.
NOTE:
1. After setting the health airflow function, the position grille is
fixed.
2. In heating, it is better to select the
3. In cooling, it is better to select the
4. In cooling and dry, using the air conditioner for a long time
under the high air humidity, condensate water may occur at
the grille.
5. Select the appropriate fan direction according to the actual
conditions.
7
Operation
Set health airflow function
1.Press the button of HEALTH AIR-
FLOW, appears on the display.
Avoid the strong airflow blowing
direct to the body.
2.Press the button of HEALTH AIR-
FLOW again, appears on the
display.Avoid the strong airflow blow-
ing direct to the body.
Cancel health airflow function
HEALTH
AIRFLOW
Press the button of HEALTH AIR-
FLOW again, the unit will go on
working under the condition before
the setting of health airflow function.
mode.
mode.
