SPLIT TYPE ROOM AIR CONDITION
OPERATION MANUAL
Pleas e rea d thi s operatio n manual befor e usin g th e ai r conditioner .
K eep this operat ion manual for future reference.
ER
AS25S2SJ1FA-3
AS35S2SJ1FA-3
AS50S2SJ1FA-3

Advertisement

loading
Need help?

Need help?

Do you have a question about the AS25S2SJ1FA-3 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Haier AS25S2SJ1FA-3

Summary of Contents for Haier AS25S2SJ1FA-3

  • Page 1 SPLIT TYPE ROOM AIR CONDITION OPERATION MANUAL AS25S2SJ1FA-3 AS35S2SJ1FA-3 AS50S2SJ1FA-3 Pleas e rea d thi s operatio n manual befor e usin g th e ai r conditioner . K eep this operat ion manual for future reference.
  • Page 2 Read the precautions in this manual This appliance is filled with R32. carefull before operating the unit. Keep this manual where the user can easily find it. WARNING: · Do not use means to accelerate the defrosting process or to clean, other than those recom- ·...

  • Page 3: Quiet Function

    Wi-Fi function Quiet function This product can realize remote control, Haier air conditioner has quiet function to operation, management, energy consumption have the machine operate quietl quer y , sleep curve setting and other functions through Wi-Fi to have the users enjoy comfortable temperature quietl y.

  • Page 4: Parts And Functions

    Parts and Functions Indoor Unit Remote controller 1.TURBO/QUIET button 2.I FEEL button 3.MODE button Humidity sensor (internal) 4.AIR STATUS button Air inlet Air quality sensor (internal) 5.TEMP+/- button 6.SWING left/right button Display (internal) MODE I FEEL Front panel 7.ECOSENSOR button SLEEP 8.HEALTH AIRFLOW button Vertical flab (internal)

  • Page 5: Clock Set

    Opertion LOCK/LIGHT/RESET/ Clock set EXTRA FUNCTION Load the battery or press LOCK Button the"reset" button LOCK RESET Used to lock buttons and LCD display. Press “ ” or “ ” to LIGHT Button set correct time LIGHT MODE I FEEL Turn on and off the indoor display.

  • Page 6: Operation

    Opertion AUTO,COOL,HEAT,DRY,FAN Mode Note Operation In AUTO mode, the air conditioner will automatically select Cool or Heat operation according to room AUTO temperature. When FAN is set to AUTO, the air con- ditioner automatically adjusts the fan speed accord- ing to room temperature. Unit start COOL Cooling only...
  • Page 7 Opertion I FEEL Operation Operation Press I FEEL button Press SMART HUMIDITY 1. Only for COOLING, HEATING or button In the mode, the implemented). SMART Humidity thermoregulation range is 16°C-30°C. 2. Place the remote controller within When the fan speed is displayed as the acceptable range of air condi- automatic (default initial state), it is tioner.
  • Page 8 Opertion Comfortable SLEEP Temp. setting Unit stop Before going to bed, you can simply 1 hr Decreases 2 º press the SLEEP button and unit will operate in SLEEP mode and bring you a 1 hr sound sleep. Decreases 2 º...
  • Page 9 Opertion Operation TURBO Operation Press the PURIFY button on the remote control. Press button. For MODE I FEEL MODE I FEEL each press, fan speed changes as SLEEP SLEEP follows: Unit will run at selected fan speed. EXTRA EXTRA FUNCTION ECOSENSOR ECOSENSOR FUNCTION...

  • Page 10: Swing Operation

    Opertion SWING Operation Operation Up and down air flow direction Set health airflow function For each press of the button, air 1.Press the button of HEALTH AIR- flow direction on remote controller FLOW, appears on the display. displays as follows according to Avoid the strong airflow blowing different operation modes: direct to the body.

  • Page 11: Timer Operation

    Opertion ECO SENSOR Operation TIMER Operation Set Clock correctly before starting Timer operation. You can let unit start or stop ECOSENSOR Press ECO SENSOR button automatically at the following times: Before you wake up in the morning, For each press,changes as follows: get back from outside or after you fall cancel asleep at night.

  • Page 12: On/Off Operation

    ON/OFF Operation: Control Interaction Query lost, and with function of emergency running, air conditioner can run Cloud service Haier Smart AC Service automatically for a while. Remind Router heard once, which means the start of this operation. The application environment...
  • Page 13 Opertion Steri Clean Operation Loading of the battery When the 56ºC Steri-clean function is required, please access in the hOn APP. Remove the battery cover; Introduction to Steri Clean Stage 1 - Self Clean: to remove dirt away. This function freezes the evaporator with moisture in the air, and removes dirt during the melting process.The hydrophilic aluminium coating with smaller Load the batteries as illustrated.

  • Page 14: Self Clean Operation

    Operation SELF-CLEAN Operation Note: Functional description the purpose of this function is to clean the evaporator. 1.This function is invalid in timer / sleep mode. Entry and exit have no airflow, or even cold airflow blowing. If this function is needed, please select in the hOn APP. t I .
  • Page 15 Operation -- Installation and removal of IFD 1.Brief introduction of the mechanism (the figure is the sketch of the parts, please refer to the real object) Right mounting frame Upper bracket slot Upper buckle Lower bracket slot Left mounting frame Lower buckle 2.
  • Page 16 Operation Care and cleaning of IFD dust removal module IFD dust removal module can be used all the time, generally does not need to be replaced, and can be washed. According to the actual conditions of the air 1. After installation of the air conditioner, the installer conditioner, just clean it by yourself or when prompted shall load the IFD dust removal module into the air by the APP.

  • Page 17: Disposal Requirements

    IMPORTANT INFORMATION REGA- EUROPEAN REGULATIONS RDING THE REFRIGERANT USED CONFORMITY FOR THE MODELS Contains fluorinated greenhouse gases Climate:T1 Voltage:230V All the products are in conformity with the following European provision: - 2014/53/EU(RED) 1+2= - 2014/517/EU(F-GAS) This product contains fluorinated greenhouse gases . Do not vent - 2009/125/EC(ENERGY) into the atmosphere.

  • Page 18: Indoor Unit Installation

    Indoor Unit Installation Necessary Tools for Installation Power Source Torque wrench Driver Before inserting power into receptacle, check the voltage without (17mm,22mm,26mm) Nipper fail. Pipe cutter Hacksaw The power supply is the same as the corresponding nameplate. Flaring tool Hole core drill Install an exclusive branch circuit of the power.

  • Page 19: Removing The Wiring Cover

    Ø Ø efrigerant piping by protecting tape. 33.3 [ Other direction piping ] AS25S2SJ1FA-3 116.5 Cut away, with a nipper, the lid for piping according to the piping AS35S2SJ1FA-3 direction and then bend the pipe according to theposition of wall hole.

  • Page 20: Power Source Installation

    Connecting wiring Fa ulty the rm istor; H eat-exchange Fa ulty P C B ; senso r failure AS25S2SJ1FA-3 4G1.0mm AS35S2SJ1FA-3 Fa ulty E E P R O M da ta; Indo or E E P R O M AS50S2SJ1FA-3 Fa ulty E E P R O M ;...

  • Page 21: Maintenance

    Maintenance For Smart Use of The Air Conditioner Remote Controller Indoor Body Setting of proper room Do not block the air inlet temperature or outlet Proper wipe the air conditioner by using a temperature soft and dry cloth.For serious stains, use a neutral detergent diluted with Do not usewater,wipe the controller water.Wring the water out of the...

  • Page 23: Troubleshooting

    30 seconds later, cutting off the power. Are there too much heat sources or too many people in the room during cooling operation? Address:Haier Industrial Park, Haier Road, Hi-Technology Zone, Qingdao City, Shandong Province, P.R. China Contacts: TEL +86-532-8893-7937 Website: www.haierhvac.eu...

  • Page 25: Instalacija Unutarnje Jedinice

    Me utim, ove dvije se funkcije ne mogu koristiti istovremeno. Funkcija tišine Funkcija Wi-Fi Haier klima ure aj ima funkciju tišine kako bi stroj Ovaj proizvod mo e ostvariti daljinski nadzor, rad, radio tiho. upravljanje, upit potrošnje energije, postavku mirovanja i druge funkcije putem Wi-Fi -a kako bi korisnici u ivali u ugodnoj temperaturi na miru.

  • Page 26: Dijelovi I Funkcije

    Dijelovi i funkcije Unutarnji ure aj 1. TURBO/QUIET dugme 2. I FEEL dugme Senzor vlage (unutarnji) Ulaz za zrak 3. MODE dugme Senzor kvaliteta zraka (unutarnji) 4. AIR STATUS dugme 5. TEMP+/- dugme Prikaz (interni) 6. SWING lijevo/desno dugme MODE I FEEL 7.
  • Page 27 LOCK/LIGHT/RESET/EXTRA Podešavanje Clock (sata) FUNCTION Koristi za isklju i prikaza LCD. LOCK RESET zaslona.Pritisnite indika- Svakim pritiskom torsku tipku 10 puta unutar LIGHT MODE I FEEL manje. Ako tipku SLEEP MODE I FEEL SLEEP prikaz temperature okoline pritisnite EXTRA HEALTH AIRFLOW ECOSENSOR FUNCTION...
  • Page 28 DRY i FAN AUTO peraturi. COOL brzini. MODE tora ovisno o sobnoj temperaturi. MODE I FEEL Pritisnite tipku TEMP SLEEP Svaki put kad se pritisne EXTRA HEALTH Svaki put kad se pritisne FUNCTION AIRFLOW ECOSENSOR TIME TIME CONFIRM CANCEL LOCK LIGHT RESET smanjuje 1°C.
  • Page 29 Pritisnite dugme Pritisnite tipku U modu PAMETNA VLA NOST, raspon termoregulacije je 16 ° C-30 ° C. Kada je brzina ventilatora prikazana kao automatska (zadano po etno stanje), to je pametan na in rada i klima ure aj automatski regulira i kontrolira relativnu vla nost zraka unutarnjeg okru enja unutar 40% -55%.
  • Page 30 Udoban SLEEP temperatura Smanjuje se za 2°C jednostavno pritisnuti tipku SLEEP i 1 sat 1 sat Smanjuje se za 2°C 3 sat 3 sat Pritisnite tipku SLEEP. SLEEP 1°C Raste SLEEP HEAT MODE I FEEL SLEEP kako vam ne bi bilo prehladno dok spa- HEALTH EXTRA FUNCTION...
  • Page 31 tipku PURIFY na daljinskom Pritisnite upravlja u MODE I FEEL MODE I FEEL SLEEP SLEEP EXTRA HEALTH EXTRA HEALTH FUNCTION ECOSENSOR AIRFLOW FUNCTION AIRFLOW ECOSENSOR CONFIRM TIME TIME TIME TIME CONFIRM CANCEL CANCEL LOCK LIGHT RESET LOCK LIGHT RESET Funkcija pro iš avanja: * IFD filter: U na inu hla enja / grijanja / ventilatora, ako pritisnete dugme PRO ISTITI na daljinskom upravlja u, filtar za uklanjanje prašine e...
  • Page 32 dolje HEALTH strujanja zraka AIRFLOW Za svaki pritisak tipke smjer protoka zraka na dal- zuje se kako je prikazano direktno prema tijelu. se pojavljuje na zaslonu. COOL/DRY/FAN: zraka direktno prema tijelu. MODE I FEEL MODE I FEEL HEALTH HEAT: AIRFLOW SLEEP strujanja zraka SLEEP...
  • Page 33 ECOSENSOR SOR. Svakim pritiskom TIMER .Daljinski TIME treptati. MODE I FEEL MODE I FEEL SLEEP SLEEP TIME HEALTH EXTRA HEALTH EXTRA Svaki put kada pritisnete AIRFLOW FUNCTION AIRFLOW FUNCTION ECOSENSOR ECOSENSOR CONFIRM TIME TIME CONFIRM TIME TIME CANCEL CANCEL LOCK LIGHT RESET LOCK...
  • Page 34 Kontrola Interakcija Upit Usluga u Haier smart oblaku Usluga Podsjetnik IOS sustav TIMER tava 4ºC AUTO COOL Android sustav 4ºC AUTO HEAT sustava 16ºC...

  • Page 35: Umetanje Baterije

    Umetanje baterije samo aplikacija hOn. Uvod u Steri Clean zraka.
  • Page 36 Upotreba Funkcionalni opis NAPOMENA: svrha ove funkcije je Ulazak i izlazak: 4. V pokrenite nakon 10 sekundi.
  • Page 37 Rad - Ugradnja i uklanjanje IFD 1. Kratki uvod mehanizma (slika je skica dijelova; pogledajte stvarni objekt) Desni okvir za ugradnju Lijevi okvir za ugradnju 2. Ugradite filtarski element zaglaviti). Ugradite drugi filtarski element u desni okvir u skladu s radnim koracima ;...
  • Page 38 1. Nakon ugradnje klima ure aja, instalater e ubaciti IFD modul za IFD modul za uklanjanje prašine mo e se koristiti cijelo vrijeme, uklanjanje prašine u klima ure aj. op enito se ne treba zamijeniti i mo e se prati. Prema stvarnim uvjetima 2.
  • Page 39 UKLADN OST MO ODELA S PROPIS SIMA A NA BAVIJES POTREB LJENOM ASHLADN EDIJU Klima: T1 Napon: 230V Svi p proizvodi su sukl adni s odredbam ma sljede ih prop pisa EU: - 2014/53/EU(RED) - 2014/517/EU(F-GAS) - 2009/125/EC(ENERGY) - 2010/30/EU(ENERGY) 1+2= - 2006/1907/EC(REACH) proizvod sadr fluorirani s...
  • Page 40 Ugradnja unutarnje jedinice Alati potrebni za ugradnju Izvor napajanja Odvija Moment klju (17mm, 22mm, 26mm) Prije nego priklju ite ure aj, obvezno morate provjeriti napon Sjeka a kliješta Reza cijevi Izvor elektri ne energije mora odgovarati onome koji je naveden na Pila za eljezo Alat za širenje (pertlanje) cijevi natpisnoj plo ici...
  • Page 41 Ugradnja unutarnje jedinice 1. Umetnite crijevo za odvod u kanal od termoizolacijskih materijala unutarnje Postavljanje monta ne plo e i odre ivanje mjesta za bušenje jedinice. zida 2. Umetnite unutarnji/vanjski elektri ni kabel iz stra nje strane unutarnje Kada se prvo pri vrš uje mont a plo a jedinice, i izvucite ga van prema prednjoj strani i zatim ih spojite.
  • Page 42 Neispravan osjetnik termistor; Neispravna PCB mo i funkcionirati ispravno i mo e do i do ošte enja. unutarnje temperature Vodi i za spajanje Neispravan osjetnik izmjenjiva a AS25S2SJ1FA-3 Neispravni EEPROM podaci; 4G1.0mm Greška unutarnjeg AS35S2SJ1FA-3 Neispravan EEPROM; EEPROM-a Neispravan PCB;...
  • Page 43 automatski spustiti i zatvoriti...
  • Page 45 Adresa:Haier Industrial Park, Haier Road, Hi-Technology Zone, Qingdao City, Shandong Province, P.R. China Kontakt informacije: TEL +86-532-8893-7937 Web stranica: www.haierhvac.eu...
