SIM CARD (FOR 3G MODELS)

Please, follow bellow procedure to insert SIM card in CCL1Mini embedded modem.
STEP
Locate Control module CCL1Mini. Cellular modem is installed in the same
CCL1Mini board as shown:
6.
SIM card holder is located at the left side cellular modem.
The SIM card and its contacts can be easily damaged by scratches or bending,
7.
so be careful when handling, inserting or removing the card.
Insert the SIM card with the contact surface facing down.
