CCL-WBM-SMART-RCBO-16A
6.3
CABLE INSERTION
There are three possibilities to insert the electric wires or electric pipe:
a) Cable insertion from above.
b) Cable insertion from behind.
c) Cable insertion from below.
In all cases it is required to install a cable gland to ensure properly installation.
Cable insertion from above
Cable insertion from behind
Cable insertion from below
Protect the contactor and all possible electronic
devices inside the unit before breaking the cable
insertions.
INSTALLATION MANUAL
11
© CIRCONTROL
www.circontrol.com
