- Page 1 627 Amersale Drive Naperville, IL 60563 Phone: (800) 323-5664 Fax: (630) 897-0573 sales@belson.com Model # PTST8 Instructions Sheet RECYCLED PLASTIC STEP THROUGH PICNIC TABLES www.belson.com...
- Page 2 BEFORE ASSEMBLY, PLEASE MAKE SURE ALL COMPONENTS ARE INCLUDED. FP - FASTENER PACK ( 1 ) - ONE FASTENER PACK A - TABLE TOP ( 1 ) - ONE TABLE TOP G - SEAT SUPPORT ( 6 ) - SIX SEAT SUPPORTS D - SEAT ( 2 ) TWO SEATS H - LEG CROSS BLOCK...
- Page 3 BEFORE ASSEMBLY, PLEASE MAKE SURE ALL FASTENERS ARE INCLUDED. 12 - 3/8” X 5“ HEX HEAD BOLT 12 - 3/8” X 4“ HEX HEAD LAG BOLT 12 - 3/8” NYLON LOCK NUT 36 - 3/8” FLAT WASHER 24 - #12 X 3” FLAT HEAD PHILLIPS SCREW ALSO NEEDED FOR THIS ASSEMBLY WILL BE THE FOLLOWING MATERIALS: 1 - #3 PHILLIPS DRIVE BIT 2 - 9/16”...
- Page 4 3/8” FLAT WASHER LEG CROSS BLOCK 3/8” X 4” HEX HEAD LAG BOLT STEP #1: WHILE LEGS ARE PLACED IN THE PROPER CONFIGURATION PLACE A LEG CROSS BLOCK BETWEEN THE TWO LEGS AND ALIGN THE HOLES, INSERT ( 1 ) - ONE 3/8” X 4” HEX HEAD WITH ( 1 ) - ONE 3/8” FLAT WASHER PER HOLE.
- Page 5 3/8” NYLON LOCK NUT 3/8” FLAT WASHER 3/8” X 5” HEX HEAD BOLT 3/8” FLAT WASHER STEP #2: WHILE THE TABLE TOP IS UPSIDE-DOWN, FASTEN THE LEGS TO THE UNDER TOP SUPPORTS BEING SURE THAT THE COUNTER BORES ARE POINTING TOWARD THE CENTER OF THE TABLE AS SHOWN ABOVE. USE ( 1 ) ONE 3/8”...
- Page 6 #12 X 3” FLAT HEAD PHILLIPS SCREW STEP #3: WHILE THE TABLE TOP IS UPSIDE-DOWN POSITION ALIGN THE HOLES ON THE SEAT SUPPORTS WITH THE PRE DRILLED HOLES IN THE LEG AND SCREW A #12 X 3” PHILLIPS HEAD SCREW TIGHT. NOTE: DO NOT TIGHTEN BOLTS COMPLETELY.
- Page 7 NOTE: BE SURE TO TIGHTEN ALL LOOSE BOLTS AFTER THIS STEP IS COMPLETE. STEP # 4: FLIP THE TABLE UPRIGHT ONTO THE LEGS. PLEASE TAKE CAUTION WHILE FLIPPING THE TABLE. AT THIS POINT IN ASSEMBLY THE TABLE WEIGHS APPROXIMATELY 260 POUNDS. #12 X 3”...
