Installation, Continued
G
8. Install Front panel
a. Insert the square spindle from the outside of
the door into the square hole of the lock
body (as picture shows to install).
b. The dot side faces the outside of the door.
c. Take the main cable above through hole to
Back panel, put dot side of square spindle
into front panel, and make front panel close
to the door surface.
