- Page 1 YoLink Smart Lock M2 (Door Knob) YS7607-UC Installa on & User Guide Rev 1.1...
-
Page 2: Table Of Contents
· ·· · ·1 Introduc on ······························································································2 Set Up ····································································································· ·4 · Installa on ·······························································································6 Using the YoLink Smart Lock M2 ·······························································14 Using the YoLink App ···············································································19 Maintenance ······················································································· ···25 · Specifica ons ····················································································· ····27 · Troubleshoo ng ················································································· ·····28 ·... -
Page 3: In The Box
A. In the Box A. Front Module B. Back Module C. Strike Plate D. Back Moun ng Plate E. Dead Latch F. Screws (8) G. Mechanical key (2) -
Page 4: Introduc
YoLink app. Add the smart lock to YoLink app, you can lock or unlock the door and can check the historical unlocked record (including member, method, date and me) though app. When the door is unlocked, no fica ons will be sent to you via the YoLink app (available no fica ons types are: email,... - Page 5 The LED light indicates the current status of the smart lock: light Up Blue Digit keypad backlight Fast Blinking Green Once Door is Unlocked Blinking Green Connec ng to Cloud Fast Blinking Red Once Door is locked Blinking Red Restoring to Factory Default...
-
Page 6: Set
C. Set Up C-1. Set Up - First-Time YoLink Users (Exis ng users proceed to C-2. Add Device, next page) Download the YoLink app through Apple App Store or Google Play Apple iPhone or tablet that is iOS 9.0 Store (Search in the store or use... - Page 7 C-2. Add Device Ta p “ ” b u o n , t h e n s c a n Q R C o d e o n t h e d e v i c e . F o l l o w t h e s t e p s t o a d d t h e d e v i c e Install four AA non-rechargeable ba eries a er installa on.
-
Page 8: Installa
D. Installa on D-1. IMPORTANT SAFETY NOTICE! The back module (part B) needs to be protected from weather DO NOT USE POWER DRILL D-2. These Tools May be Required Phillips Screwdriver AA Ba ery (4, Non-rechargeable) - Page 9 D-3. Get Ready Adjust Latch Backset 60mm(23/8′′) An clockwise rotate to loose the buckle Pull right to extend the length of buckle to 70 millimeters (23/4'' inches) ; push le to s h o r t e n t h e l e n g t h o f b u c k l e t o 6 0 millimeters (23/8'' inches)
- Page 10 D-4. Begin Installa on Install the door latch G e n t l y p u t t h e d o o r l a t c h a c r o s s t h e S c rew a n d fa ste n t h e d e a d l atc h w i t h i n s t a l l a o n h o l e o n t h e d o o r t wo m o u n n g s c rews ( F 3 ) 1.
- Page 11 Install the strike plate Ke e p t h e st r i ke p l a te p o r o n o n t h e d o o r f ra m e a l i g n e d to t h e s p r i n g b o l t Screw and fasten the latch with two moun ng screws (F3)
- Page 12 Mount the Front Module Place the front module on the side of the outdoor Keep drive bar in the ver cal orienta on when front module was installed, insert the drive bar across the cam slot of the dead latch Turn across the connec on cable across the moun ng hole Carefully hold the front module to avoid being dropped down Connec on Cable...
- Page 13 Fasten the Back Moun ng Plate a . P l a c e t h e b a c k m o u n n g p l ate o n t h e s i d e o f t h e i n d o o r. Pa s s t h e d r i ve b a r o f f ro nt m o d u l e t h ro u g h t h e m i d d l e c i rc l e o f t h e b a c k m o u n n g p l ate ;...
- Page 14 Mount & Fasten Back Module a. Connect the connec on cable of the front module and connec on cable of the back module b. Insert and ghten two moun ng screws (F2) to fasten the back module c. Install four new AA non-rechargeable ba eries d.
- Page 15 - Disconnect the wires between front module and back module, reconnect a er several seconds c. Using the YoLink app, test the opera on of the Lock (lock, unlock, etc.) If it is not working properly, double-check or re-do through step 4 to 5, as needed.
-
Page 16: Using The Yolink Smart Lock M2
E. Using the YoLink Smart Lock M2 E-1 Set the Local Password Each YoLink Smart Lock M2 support only one local password. You will need to set the local password physically 1. Local password is default set to: 12345678. For your home security, please set a new local password right now a er installa on 2. - Page 17 5 mes in 5 minutes, you can’t deal with any opera ons with the keypad. You can unlock the door using a mechanical key or through YoLink app 1 Beep = Success 3 Beeps = Try again 10 beeps = Low ba ery alert...
- Page 18 E-3 Lock the Door 1. Make sure you have at least one method to unlock the door before you locking it 2. Make sure the spring bolt enter into the hole of strike plate when locking the door, to avoid the door frame of being damaged if it tried to lock while ajar.
- Page 19 E-4 Doorbell There will be an alert no fica on sends to your YoLink account to no ce you there is a someone pressing down the doorbell key...
- Page 20 E-5 Replacing the Ba eries Open the ba ery cover and Observing polarity, insert Close the ba ery cover remove the old ba eries four new AA ba eries Do not mix old and new ba eries 4 x AA...
-
Page 21: Using The Yolink App
1. Locked or unlocked status indicates the real- me status of the smart lock, but not the door 2. You can use a YS7704-UC YoLink Door Tap to unlock the door Sensor (sold separately) to help monitoring the real- me status of the door... - Page 22 Current Ba ery Level - Shown red if replacement is required l. Firmware Version “#### ready now ” indicates a new update is available (refer to page m. Remove Device From Current Account - Tap to delete the device from your YoLink account...
- Page 23 F-3. Manage User Password (Available For Host Account Only) c. Add a new user password se ngs c-1 Edit password; c-2 Edit name; c-3 Edit the valid me for the new user password; a. Tap “Manage User ” c-4 Tap to save the se ngs icon to go to the “Users Management ”...
- Page 24 F-4. Obtain Visitor Password (Available For Both Host and Member Account) a. c. a. a. 1. Visitor password will be invalid once used to unlock the door 2. Visitor password is 24-hours valid 3. Only the latest one visitor password is saved and valid 4.
- Page 25 F-5. Automa on (Set Up Rules For “If This Then Do That”) Go to the “Smart” screen, tap “Automa on” YoLink Smart Lock M2 can be set as a trigger, and “Unlock” is the only trigger op on b. Add an automa on b-1 Edit name;...
- Page 26 YoLink Smart Lock M2?” -- “ The YoLink Smart Lock M2 is locked” 4. The YoLink Smart Lock M2 may be used as a trigger or input for custom applets (IFTTT.com) 5. For addi onal informa on specific to the pla orm, refer to the associated app.
-
Page 27: Maintenance
G. Maintenance G-1. Firmware Update To ensure our customers have the best user experience, we highly recommend you update to the newest version firmware when an update is available In “Firmware”, if a new version is listed as available (#### ready now), click it to start the firmware update process Yo u m a y u s e y o u r d e v i c e d u r i n g t h e u p d a t e a s i t i s p e r f o r m e d i n t h e b a c k g r o u n d... - Page 28 Removes access network informa on; Local password resets to 12345678). A er the factory reset, your device will remain in your Yolink account Hold the “S” or “C ” bu on for 20-25 seconds un l there is 2 beeps, then release. The “...
-
Page 29: Specifica Ons
H. Specifica ons 30 user passwords; 1 local password; 1 one- me visitor password Password: Input Voltage: 6V DC (4 - AA non-rechargeable ba ery) Alert Voltage: 5.42V DC ≤1.4A (working), ≤ 80uA (standby) Device Current Draw: Environment: Temperature: 32°F-122°F (0°C-50°C) working Humidity: 10%-90% non-condensing... -
Page 30: Troubleshoo
- If the lock beeps 2 mes and locks successfully, it has at least 1 password stored in its memory and is opera ng correctly c. It shows the lock is offline on YoLink App: - If hub is offline. Reconnect your hub to the Internet and press the “S” bu on of smart lock once - If hub is powered off. -
Page 31: Warning
J. Warning Please install, operate and maintain the YoLink Smart Lock M2 only as outlined in this manual. Improper use may damage the unit and/or void the warranty Use only new, name brand, alkaline non-rechargeable AA ba eries Do not use rechargeable ba eries... - Page 32 Do not install or use this device where it will be subjected to physical impacts and/or strong vibra on. Physical damage is not covered by the warranty Please contact Customer Ser vice before a emp ng to repair, disassemble or modify the device, any of which can void the warranty and permanently damage the device...
- Page 33 FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protec on against harmful interference in a residen al installa on. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instruc ons, may cause harmful interference to radio communica ons.
- Page 34 Note: The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifica ons to this equipment. Such modifica ons could void the user’s authority to operate the equipment. FCC RF Radia on Exposure Statement This equipment complies with FCC RF radia on exposure limits set forth for an uncontrolled environment.
- Page 35 Warranty will be provided by Milocks If you are unable to get your YoLink Smart Lock M2 working, please contact us during business hours US Live Tech Support: 1-800-355-0157 M-F 9am - 5pm PST MiProducts Corp. La Puente, CA 91746 1-800-355-0157 MADE IN TAIWAN...
