Yolink YS7617-UC Installation & User Manual page 10

Smart lock(door lever)

Advertisement

Get to Know Your YoLink Smart
D
Lock (Door Lever), Continued
1
2
3
4
5
6
7
8
9
1) Battery Cover
2) Back Plate
3) Back Panel
4) Panel Screw 1
5) Back Handle
6) Panel Mounting Screw 2
7) Panel Screw 3
8) Handle Tower Spring
9) Panel Screw 1
10
11
12
10) Lock Body
11) Lock Body Screw
12) Spindle
13) Assomble Screw Blot 1
14) Assomble Screw Blot 2
15) Door
16) Cable Hole
17) Assomble Screw Blot 1
18) Main Data Cable
19) Front Panel
20) Front Handle
15
16
17
18
13
14
08
