Dmx Traits - ADJ MEGA TRIPAR PROFILE PLUS User Manual

CHANNEL
4CH 5CH 6CH 9CH
1 1 1 1
2 2 2 2
3 3 3 3
4 4 4 4
5 5
5 6 3
7
8

DMX TRAITS

DMX
FUNCTION
VALUES
10CH
Red, 0% to 100%
1 000 - 255
Green, 0% to 100%
2 000 - 255
Blue, 0% to 100%
3 000 - 255
UV, 0% to 100%
4 000 - 255
Shutter/Strobe
000 - 031 LED Off
032 - 063 LED On
064 - 095 Strobing, slow to fast
5 096 - 127 LED On
128 - 159 Strobe Pulse, slow to fast
160 - 191 LED On
192 - 223 Random Strobe, slow to fast
224 - 255 LED On
Master Dimmer, 0% to 100%
6 000 - 255
Program Selection Mode
000 - 051 Dimming Mode
052 - 102 Color Macro Mode
7
103 - 153 Color Change Mode
154 - 204 Color Fade Mode
205 - 255 Sound Active Mode
Color Macro Mode, see Color Macro Chart section of this
000 - 255
manual
Color Change Programs
000 - 015 Color Change 1
016 - 031 Color Change 2
032 - 047 Color Change 3
048 - 063 Color Change 4
064 - 079 Color Change 5
8
080 - 095 Color Change 6
096 - 111 Color Change 7
112 - 127 Color Change 8
128 - 143 Color Change 9
144 - 159 Color Change 10
160 - 175 Color Change 11
176 - 191 Color Change 12
192 - 207 Color Change 13
CONTINUED ON NEXT PAGE
15
