Micro Wash RGBW
Introduction
Unpacking:
Thank you for purchasing the Micro Wash RGBW by
American DJ
. Every Micro Wash RGBW has been thoroughly tested
®
and has been shipped in perfect operating condition. Carefully check
the shipping carton for damage that may have occurred during ship-
ping. If the carton appears to be damaged, carefully inspect your fix-
ture for any damage and be sure all accessories necessary to operate
the unit has arrived intact. In the case damage has been found or parts
are missing, please contact our toll free customer support number for
further instructions. Do not return this unit to your dealer without first
contacting customer support.
Introduction:
The American DJ
Micro Wash RGBW is part of a
®
continuing pursuit to create high quality intelligent lighting. The Micro
Wash RGBW is a DMX intelligent, high powered LED par can. This fix-
ture can be used in a stand alone mode or connected in a Master/Slave
configuration. The unit can also be controlled via DMX controller. This
unit has five operating modes: Sound Active mode, Macro mode, Auto
mode, RGB mode, and DMX control mode.
Customer Support:
American DJ provides a customer support line,
to provide set up help and to answer any question should you encoun-
ter problems during your set up or initial operation. You may also visit
us on the web at www.American DJ.com for any comments or sugges-
tions. Service Hours are Monday through Friday 8:00 a.m. to 4:30 p.m.
Pacific Standard Time.
Warning!
To prevent or reduce the risk of electrical shock or fire, do
not expose this unit to rain or moisture.
Caution!
There are no user serviceable parts inside this unit. Do not
attempt any repairs yourself, doing so will void your manufactures war-
User Instructions
ranty. In the unlikely event your unit may require service please contact
American DJ.
PLEASE recycle the shipping carton when ever possible.
Rev. 3/11
