- Page 1 Rover Range (50-ROMBC-0919) Assembly Instructions...
-
Page 2: Components List
Rover Range (50-ROMBC-0919) Components List ITEM DESCRIPTION Top Panel Left Side Panel Right Side Panel Back Panel Moveable Shelf Immovable Panel Bottom 20 x 3x14mm 38 x 6x35mm 38 x 8x30mm 20 x 5/8” 15 x Threaded 4 x 4x22mm 24 x 3.5x30mm Screw Cam Bolt... - Page 3 Rover Range (50-ROMBC-0919) Assembly Instructions STEP 1: STEP 2: Preparation for Top panel A, Bottom panel G, Left side panel X, Right side 1. Install the aluminum piece and A, G panel together with bolts B2 as illustrated above. panel Z, Back panel D, Immovable panel F 1.
- Page 4 Rover Range (50-ROMBC-0919) Assembly Instructions STEP 3: STEP 4: Panel X/Z assembly Panel A/G assembly 1. Insert cam bolts C1 and dowel pins D1 into panels X, Z into cams on panel F and tighten 1. Insert cam bolts C1 and dowel pins D1 into panels A, G into cams on panel X, Z and in a clockwise direction as illustrated above.
- Page 5 Rover Range (50-ROMBC-0919) Assembly Instructions STEP 5: STEP 6: Panel D assembly Panel V assembly 1. Insert cam bolts C1 and dowel pins D1 on panel D into cams on panel X, Z, A, G, F and 1. Insert cam bolts C1 and dowel pins D1 on panel V into cams on panel X, Z, A, G, F and tighten in clockwise direction as illustrated above.
- Page 6 Rover Range (50-ROMBC-0919) Assembly Instructions STEP 7: STEP 8: 1. Install the aluminum piece and X, Z, A, G panel together with screw S1 as illustrated above. 2. Install the aluminum piece and X, Zpanel together with screw S2 as illustrated Panel A/G assembly above.
- Page 7 Rover Range (50-ROMBC-0919) Assembly Instructions STEP 9: STEP 10: 1. Insert fix bolt B1 on panel A, X, Z into cam on eva and tighten in clockwise direction as 1. Install castors T1 and T2 using screws B3. illustrated above. Rover Range Assembly Instructions...
- Page 8 Rover Range (50-ROMBC-0919) Assembly Instructions STEP 11: Complete: Moveable shelf E assembly Remove all QC and panel labels and wipe clean using a damp cloth and general household cleaner. 1. Insert threaded dowel pins P1 into panels X, D and Z as illustrated above. 2.
