- Page 1 Modulus Twin Pole Double Span Table Installation Guide TOOLS REQUIRED: Powered screwdriver. myofficelinkgroup.com...
- Page 2 Modulus 4 Post Pedestal Table INSTALLATION GUIDE COMPONENTS Die Cast Upper Wrist x6 Top Rail x4 Bottom Rail x2 Feet Tube x6 Large Foot x6 150° Collar x4 Cross Collar x2 Bottom T Connector x2 Cross Connector x1 10 T Tube x6 11 Collar Plug x4 12 T Tube &...
- Page 3 Modulus 4 Post Pedestal Table INSTALLATION GUIDE Slide the large foot and T tube connector into the collar, place the 150° gasket on Using 2 T tubes, connect the assembled corner feet to the bottom T connector, top, and fully tighten the 2 M8x16mm bolts into the collar. (Repeat with all 150°...
- Page 4 Modulus 4 Post Pedestal Table INSTALLATION GUIDE Fig C Screw all glides into the base of the large feet, leaving the glides one turn from Place the steel strap onto the upper wrists, with the raised areas of the straps tight (then they can be adjusted easily if the floor is uneven).
- Page 5 Modulus 4 Post Pedestal Table INSTALLATION GUIDE Slide each top rail through the upper wrists, making sure they are located in the Place the top rail caps into the exposed holes on each end of the frame assembly. centre of the frame.
- Page 6 Modulus 4 Post Pedestal Table INSTALLATION GUIDE Optional: For extra strength, the plastic support brackets can be screwed onto the For multi piece work surfaces, use the table top bracket plates, and M5x20mm top rails. screws to join together as one solid piece. This should be done with the work surface sitting on the frame in its final position.
