Nidek Medical RT-6100 Quick Reference Manual

＜Distance/Near＞
Toggles between the distance vision test
near vision test .
NEAR
＜Side menu＞
Displays the side menu.
＜Sub windows 1&2 (right/left) ＞
・Displays the previously set data.
・Displays the data set before the previous setting.
＜Program message area＞
Displays the refraction procedure.
＜Current data area＞
Displays the data of the lens currently in place.
＜Chart display＞
Displays the currently presented chart.
＜Auxiliary function selection＞
Availability depends on charts.
Changes the contrast.
Displays charts in inverted black and white.
Presents charts in night use brightness.
Turns the glare lamp on or off.
Changes the horizontal line letters randomly.
= +
＜Numeric entry＞
, Changes the selected value.
＜Data entry＞
Displays the import data select screen for
AR or LM data.
＜Program advance＞
・ Starts a refraction program.
Advances to the next test while
・
a program is running.
+ Returns to the previous test.
・
RT-6100
and
FAR
Input Input
Shift
＜Shift function＞
Pressing a button or turning the
dial while holding
functions or increments.
Quick Reference Guide
R R BIN BIN L
Output
R L
＜Window Open/Close＞
, Covers or uncovers the
measuring window (right/left).
＜Dial＞
Changes the selected value.
changes
＜Dial button＞
Changes the mode to SPH, CYL,
AXIS, or VA.
＜Measurement mode＞
Selects the mode for data entry and measurement.
＜Day/Night＞
Toggles between the day vision test
night vision test .
＜Auxiliary lens selection＞
R R L L Displays the auxiliary lens select window (right/left).
＜Chart selection＞
Select the chart to be presented.
＜Program selection＞
Displays the program select window.
＜Favorites registration＞
Displays icons for charts added as favorites.
＜Help button＞
Displays the explanation for the presented chart.
＜Patient's eye selection＞
Selects the right eye, binocular eyes, or left eye.
＜Output＞
Exports or prints data.
+ Clears data.
＜Cross cylinder switching＞
, Places the cross cylinder lens and enters
AXIS or CYL mode.
This button is used to flip the cross cylinder lens
in AXIS or CYL mode.
＜VA chart masking＞
Isolates a vertical column. Pressing the button
, again isolates its left or right column.
, Isolates a horizontal row.
Pressing the button again isolates its upper or
lower row.
Isolates a horizontal row.
Isolates a single letter.
and
