AXIOMTEK P117-ADL-TRA User Manual

All-in-one 17” sxga tft expandable panel pc
Hide thumbs

Advertisement

Quick Links

Download this manual
P117-ADL-TRA
All-in-One
17" SXGA TFT Expandable
Panel PC
User's Manual

Advertisement

loading
Need help?

Need help?

Do you have a question about the P117-ADL-TRA and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for AXIOMTEK P117-ADL-TRA

Summary of Contents for AXIOMTEK P117-ADL-TRA

  • Page 1 P117-ADL-TRA All-in-One 17” SXGA TFT Expandable Panel PC User’s Manual...

  • Page 2: Disclaimers

    Axiomtek does not make any commitment to update the information in this manual. Axiomtek reserves the right to change or revise this document and/or product at any time without notice. No part of this document may be reproduced, stored in a retrieval system, or transmitted, in any form or by any means, electronic, mechanical, photocopying, recording, among others, without prior written permission from Axiomtek Co., Ltd.

  • Page 3: Safety Precautions

    ◼ When handling boards and components, wear a grounding wrist strap available from most electronic component stores. Trademark Acknowledgments Axiomtek is a trademark of Axiomtek Co., Ltd. ® Windows is a trademark of Microsoft Corporation. ®...

  • Page 4: Table Of Contents

    Table of Contents Disclaimers ..................... ii Safety Precautions ..................iii Section 1 Introduction ..........1 General Description ................2 Specifications ..................3 1.2.1 System Specifications ..................3 1.2.2 Mechanical/Environmental Specifications ............4 Dimensions and Outlines ..............5 I/O Outlets .................... 7 Section 2 Hardware and Installation ......
  • Page 5 Section 3 AMI BIOS Setup Utility ......29 Starting ....................29 Navigation Keys ................29 Main Menu ..................30 Advanced Menu ................. 31 Chipset Menu ..................42 Boot Menu ..................46 Security Menu ..................47 Save & Exit Menu ................48 Section 4 Drivers Installation ......
  • Page 6 This page is intentionally left blank.

  • Page 7: Introduction

    P117-ADL-TRA User’s Manual Section 1 Introduction This section contains general information and detailed specifications of the P117-ADL-TRA, including the following subsections: Figure 1-1 Front View of the P117-ADL-TRA ⚫ General Description ⚫ Specification ⚫ Dimensions ⚫ I/O Outlets ⚫ Package List...

  • Page 8: General Description

    Therefore, the P117-ADL-TRA is especially suitable for most rugged industrial environments. Expandable for PCIe P117-ADL-TRA comes with one PCIe x16 for expansion purpose. User can easily plug in PCIe card as required. Introduction...

  • Page 9: Specifications

    P117-ADL-TRA User’s Manual WLAN Antenna Supported The P117-ADL-TRA supports a WLAN module (optional) antenna for wireless network connectivity. ® High Performance computing: 12 /13th Generation Intel Core™ Processors The P117-ADL-TRA is powered by LGA1700 Socket 12 Generation Intel® Core™ i7/i5/i3, Pentium®...

  • Page 10: 1.2.2 Mechanical/Environmental Specifications

    P117-ADL-TRA User’s Manual ⚫ Expansion ➢ 1 x PCIe x16 slot. Note: Supports dimensions of standard half size PCIE card. (Max. up 167.65mm x 111.15mm x 18.71mm) ➢ 1 x PCI-Express Mini Card USB + SATA signal (USB+PCIe signal by option) ➢...

  • Page 11: Dimensions And Outlines

    P117-ADL-TRA User’s Manual Dimensions and Outlines Diagram 1-1 and 1-2 show the outlines and dimensions of P117-ADL-TRA, respectively. Diagram 1-1 Outlines of the P117-ADL-TRA Cut out dimensions: 399 x 327 mm Introduction...
  • Page 12 P117-ADL-TRA User’s Manual Diagram 1-2 Back outline of the P117-ADL-TRA Introduction...

  • Page 13: I/O Outlets

    Figure 1-2,1-3 and Table 1-1,1-2 illustrate I/O locations and their functions of the P117-ADL-TRA. Figure 1-2 Front View of the P117-ADL-TRA Table 1-1 Functions of the front panel of the P117-ADL-TRA Function 1 x Power status LED 1 x SATA status LED...
  • Page 14 P117-ADL-TRA User’s Manual Figure 1-3 Side View of the P117-ADL-TRA Table 1-2 Functions of the I/O Outlets of the P117-ADL-TRA Function AC Socket for power input 1 x VGA 2 x USB 3.2 Gen1 1 x RS-232 2 x LAN...

  • Page 15: Hardware And Installation

    P117-ADL-TRA User’s Manual Section 2 Hardware and Installation The P117-ADL-TRA provides rich I/O ports and flexible expansion options to meet different demands. The Section explains how to install the hardware. ⚫ Packing List ⚫ System Layout ⚫ SSD Installation ⚫...

  • Page 16: Packing List

    P117-ADL-TRA User’s Manual Packing List The package bundled with the P117-ADL-TRA should contain the following items: ⚫ P117-ADL-TRA x 1 ⚫ Panel mount kit x 10 ⚫ Wall mount (optional) ⚫ Power cord x 1 System Layout Please follow the steps below to open the P117-ADL-TRA unit.

  • Page 17: Ssd Installation

    P117-ADL-TRA User’s Manual SSD Installation The P117-ADL-TRA provides a convenient SSD bracket for users to install one 2.5” SATA SSD. Please follow the steps: Step 1 Refer section 2.1 to open the back cover. Step 2 Unscrew four screws to take off the SSD bracket.
  • Page 18 P117-ADL-TRA User’s Manual Step 4 Fix the SSD bracket onto the main base. Step 5 Plug the power and SATA cables to connectors. Installation completes. Hardware and Installation...

  • Page 19: Dram Installation

    P117-ADL-TRA User’s Manual DRAM Installation The P117-ADL-TRA provides one 260-pin DDR4 SO-DIMM socket that supports system memory up to 32GB. Please follow the steps below to install the memory modules: Step 1 Refer to section 2.1 to open the back cover and find the DIMM socket on the mainboard (MANO560).

  • Page 20: Pcie Mini-Card Module Installation (Optional)

    P117-ADL-TRA User’s Manual PCIe Mini-Card module Installation (optional) The P117-ADL-TRA supports PCIe Mini-Card module to establish wireless connection. When installing the wireless LAN module, refer to the following instructions and illustration: Step 1 Refer to section 2.1 to open the back cover and locate PCIe Mini-Card slot.
  • Page 21 P117-ADL-TRA User’s Manual Step 4 Lift the rubber stopper from the top of back cover. Step 5 Install the antenna on the antenna connector. Hardware and Installation...

  • Page 22: Add-On Card Installation

    P117-ADL-TRA User’s Manual Add-on Card Installation The P117-ADL-TRA provides one PCIe x16 slot for expansion. The system can accommodate half-size riser cards. To install the riser card, refer to the following figure and instructions below: Step 1 Refer section 2.1 to open the back cover and unscrew the three screw to remove the fixing bracket.

  • Page 23: Mountings: Panel / Wall / Desktop / Vesa

    2.7.1 VESA-ARM / Wall-mount / Desktop-mount The P117-ADL-TRA can be installed by way of VESA mount which is in the dimensions of 100x100 mm. Simply fix four screws to fasten the kit from the back cover, , as shown in the picture below.

  • Page 24: 2.7.2 Panel-Mount Kit Assembly

    P117-ADL-TRA User’s Manual 2.7.2 Panel-mount Kit Assembly The P117-ADL-TRA is designed for panel mount. To mount the P117-ADL-TRA, the standard set of mounting kit (10pcs included in the system packaging) is needed. Hardware and Installation...

  • Page 25: Jumper Settings

    Diagram 2-1 Definitions of Pin Settings Before applying power to the P117-ADL-TRA series, please make sure the jumpers are in default positions which are defined as follows: NOTE: In case that default jumper setting needs to be changed, please make any change under the power-off condition.

  • Page 26: Clear Cmos (Jp3)

    P117-ADL-TRA User’s Manual 2.9.2 Clear CMOS (JP3) This jumper allows you to clear the Real Time Clock (RTC) RAM in CMOS. You can clear the CMOS memory of date, time, and system setup parameters by erasing the CMOS RTC RAM data.

  • Page 27: Connectors

    P117-ADL-TRA User’s Manual Connectors Please refer to below connector table to get their pin assignments Table 2-6 A Summary of Connectors External connectors Sections COM1 and COM2 D-Sub Connector 2.9.1 SATA 3.0 Connector 2.9.2 USB 3.2 GEN1 Stack Port 2.9.3 LAN and USB 2.0 Connectors...

  • Page 28: Com1 And Com2 D-Sub Connector (Cn1)

    P117-ADL-TRA User’s Manual 2.9.1 COM1 and COM2 D-Sub Connector (CN1) The CN1 is a double 9-pin D-Sub connector for COM1 and COM2 serial port interfaces on the rear I/O. Only COM1 supports RS-232/422/485 mode. The pin assignments of RS-232/422/485 are listed in table below.

  • Page 29: Sata 3.0 Connectors (Cn7)

    P117-ADL-TRA User’s Manual 2.9.2 SATA 3.0 Connectors (CN7) This connector supports the thin Serial ATA cable for primary internal storage device.. Signal 2.9.3 USB 3.2 GEN1 Stack Port (CN10) The motherboard comes with one stacked Universal Serial Bus (compliant with USB 3.2 GEN1) connector on the rear I/O for installing USB peripherals such as a keyboard, mouse, scanner, etc.

  • Page 30: Lan And Usb 2.0 Connectors (Cn11 And Cn19)

    P117-ADL-TRA User’s Manual 2.9.4 LAN and USB 2.0 Connectors (CN11 and CN19) The motherboard supports two Ethernet ports (CN11, CN19): two RJ45 connectors with CN11: Intel® i225-V controller support 10/100/1000/2500Mbps. CN19: Intel® i219-V controller support 10/100/1000 Mbps. The Universal Serial Bus (compliant with USB 2.0) connectors on the rear I/O are for installing USB peripherals such as keyboard, mouse, scanner, etc.

  • Page 31: Pci-Express Mini Card Connector (Cn21)

    P117-ADL-TRA User’s Manual 2.9.5 PCI-Express Mini Card Connector (CN21) The CN21 complies with PCI-Express Mini Card Spec. V1.2. Signal Signal WAKE# +3.3VAUX +1.5V CLKREQ# UIM_PWR/NC UIM_DAT/NC REFCLK- UIM_CLK/NC REFCLK+ UIM_REST/NC UIM_VPP/NC PERST# SATA_RP(PCIE_RX_D-) +3.3VAUX SATA_RN(PCIE_RX_D+) +1.5V SMB_CLK SATA_TN(PCIE_TX_D-) SMB_DATA SATA_TP(PCIE_TX_D+)

  • Page 32: Key E Socket (Cn22)

    P117-ADL-TRA User’s Manual 2.9.6 M.2 Key E Socket (CN22) The motherboard comes with one M.2 Key E socket (PCIe & USB2.0), The CN22 supports CNVi module. Signal Signal +3.3V_SBY USB_D+ +3.3V_SBY USB_D- M.2_BT_PCMCLK CNVI_WGR_DATA1_D- M.2_BT_PCMRST CNVI_WGR_DATA1_D+ M.2_BT_PCMIN M.2_BT_PCMOUT CNVI_WGR_DATA0_D- CNVI_WGR_DATA0_D+...

  • Page 33: Displayport1.3 Connector (Cn32)

    P117-ADL-TRA User’s Manual 2.9.7 DisplayPort1.3 Connector (CN32) The motherboard comes with DisplayPort interface on the rear I/O. Signal DP_TX0_+ DP_TX0_- DP_TX1_+ DP_TX1_- DP_TX2_+ DP_TX2_- DP_TX3_+ DP_TX3_- DP_AUX+ DP_AUX- DP_HPD +3.3V 2.9.8 HDMI1.4 Connector (CN33) The HDMI (High-Definition Multimedia Interface) is a compact digital interface which can transmit high-definition video and high-resolution audio over a single cable.

  • Page 34: Vga Connector (Cn34)

    P117-ADL-TRA User’s Manual 2.9.9 VGA Connector (CN34) The CN34 is a high rise 15-pin D-Sub connector which is commonly used for VGA display. This VGA interface configuration can be configured via software utility. Signal Signal Green Blue DDC DATA Horizontal Sync...

  • Page 35: Ami Bios Setup Utility

    P117-ADL-TRA User’s Manual Section 3 AMI BIOS Setup Utility The AMI UEFI BIOS provides users with a built-in setup program to modify basic system configuration. All configured parameters are stored in a flash chip to save the setup information whenever the power is turned off. This Section provides users with detailed description about how to set up basic system configuration through the AMI BIOS setup utility.

  • Page 36: Main Menu

    P117-ADL-TRA User’s Manual Main Menu When you first enter the setup utility, you will enter the Main setup screen. You can always return to the Main setup screen by selecting the Main tab. System Time/Date can be set up as described below.

  • Page 37: Advanced Menu

    P117-ADL-TRA User’s Manual Advanced Menu The Advanced menu also allows users to set configuration of the CPU and other system devices. You can select any of the items in the left frame of the screen to go to the sub menus: ►...
  • Page 38 P117-ADL-TRA User’s Manual ⚫ CPU Configuration This screen shows CPU information. Intel (VMX) Virtualization Technology Enable or disable Intel Virtualization Technology. When enabled, a VMM (Virtual Machine Mode) can utilize the additional hardware capabilities. It allows a platform to run multiple operating systems and applications independently, hence enabling a single computer system to work as several virtual systems.
  • Page 39 P117-ADL-TRA User’s Manual ⚫ SATA Configuration During system boot up, BIOS automatically detects the presence of SATA devices. In the SATA Configuration menu, you can see all currently installed SATA device(s). SATA Controller(s) Enable or disable the SATA Controller feature.
  • Page 40 P117-ADL-TRA User’s Manual ⚫ Trusted Computing This screen provides function for specifying the TPM settings. TPM Device Selection Select TPM device: ® PTT: Intel built-in TPM. Enables PTT in SkuMgr. dTPM: External extended Infineon’s TPM. Disables PTT in SkuMgr. Security Device Support Enable or disable BIOS support for security device.
  • Page 41 P117-ADL-TRA User’s Manual ⚫ ACPI Settings ACPI Sleep State When the suspend button is pressed, the ACPI (Advanced Configuration and Power Interface) sleep state is S3 (Suspend to RAM). Restore AC Power Loss Decide the state of system when power is re-applied after a power failure.
  • Page 42 P117-ADL-TRA User’s Manual ⚫ F81966 Super IO Configuration You can use this screen to select options for the Super IO Configuration and change the value of the selected option. A description of the selected item appears on the right side of the screen.
  • Page 43 P117-ADL-TRA User’s Manual ⚫ Hardware Monitor This screen monitors hardware health status. This screen displays the temperature of system and CPU, cooling fans speed in RPM and system voltages (VCCIO, CPU SA, +5V and +12V). AMI BIOS Setup Utility...
  • Page 44 P117-ADL-TRA User’s Manual ⚫ Smart Fan Mode Configuration This screen allows you to configure Smart Fan mode. You can use Smart Fan function to control CN60. Smart Fan Function Enable or disable Smart Fan. Fan 1 Smart Fan Control Select Smart Fan operating mode. Auto RPM Mode: The fan speed is controlled automatically according to temperature and RPM.
  • Page 45 P117-ADL-TRA User’s Manual ⚫ USB Configuration USB Devices Display all detected USB devices AMI BIOS Setup Utility...
  • Page 46 P117-ADL-TRA User’s Manual ⚫ Network Stack Configuration Network Stack Enable or disable UEFI Network Stack. IPv4/IPv6 PXE Support Enable or disable IPv4 PXE boot support. If disabled, IPv4/IPv6 PXE boot support will not be available. IPv4/IPv6 HTTP Support Enable or disable IPv4/IPv6 HTTP boot support. If disabled, IPv4/IPv6 HTTP boot support will not be available.
  • Page 47 P117-ADL-TRA User’s Manual ⚫ NVMe Configuration AMI BIOS Setup Utility...

  • Page 48: Chipset Menu

    P117-ADL-TRA User’s Manual Chipset Menu The Chipset menu allows users to change the advanced chipset settings. You can select any of the items in the left frame of the screen to go to the sub menus: ► System Agent (SA) Configuration ►...
  • Page 49 P117-ADL-TRA User’s Manual ⚫ PCH-IO Configuration This screen allows you to set PCH parameters. AMI BIOS Setup Utility...
  • Page 50 P117-ADL-TRA User’s Manual HD Audio Control detection of the HD Audio device. Disabled: HDA will be unconditionally disabled. Enabled: HDA will be unconditionally enabled. Auto: HDA will be enabled if present, disabled otherwise. ErP Control When ErP is enabled, system meets ErP requirement.
  • Page 51 P117-ADL-TRA User’s Manual ⚫ Onboard Device Onboard LAN 1/2 Enable or disable onboard LAN 1/2. AMI BIOS Setup Utility...

  • Page 52: Boot Menu

    P117-ADL-TRA User’s Manual Boot Menu The Boot menu allows users to change boot options of the system. ⚫ Setup Prompt Timeout Number of seconds to wait for setup activation key. 65535(0xFFFF) means indefinite waiting. ⚫ Full Screen Logo Display. Enable or disable full screen logo display feature.

  • Page 53: Security Menu

    P117-ADL-TRA User’s Manual Security Menu The Security menu allows users to change the security settings for the system. ⚫ Administrator Password Set administrator password. ⚫ User Password Set user password. AMI BIOS Setup Utility...

  • Page 54: Save & Exit Menu

    P117-ADL-TRA User’s Manual Save & Exit Menu The Save & Exit menu allows users to load your system configuration with optimal or fail-safe default values. ⚫ Discard Changes and Exit Exit system setup without saving any changes. ⚫ Save Changes and Reset Reset the system after saving the changes.
  • Page 55 P117-ADL-TRA User’s Manual This page is intentionally left blank. AMI BIOS Setup Utility...

  • Page 56: Drivers Installation

    Section 4 Drivers Installation Operating System P117-ADL-TRA is compatible with operating systems Windows 11 and Windows 11 IoT Enterprise. To facilitate the installation of system drivers, please carefully read the instructions in this section before any of such installation. 4.1.1 Driver download Please download the P117-ADL-TRA driver from Axiomtek’s official website...

  • Page 57: Touch Screen

    P117-ADL-TRA User’s Manual Touch Screen The P117-ADL-TRA adopts a projected capacitive multi-touch screen of which specifications are listed below. The touch driver will be installed automatically to allow the user to operate the touch panel using two-finger touch functions on the Windows 11 and Windows11 IoT Enterprise environments.

  • Page 58: Appendix Atpm Bitlocker Settings

    P117-ADL-TRA User’s Manual APPENDIX A TPM BitLocker SETTINGS 1. Setup BitLocker Drive Encryption main storage. Press <Win + R> and type “Control Panel”, then select BitLocker Drive Encryption. TPM Settings...
  • Page 59 P117-ADL-TRA User’s Manual 2. Insert an external storage device, for example USB Storage. Back up BitLocker recovery key in a new file and save it to the USB Storage. TPM Setting...
  • Page 60 P117-ADL-TRA User’s Manual 3. Please follow the steps below to encrypt your storage device: TPM Settings...
  • Page 61 P117-ADL-TRA User’s Manual Now, the system prompts that the operating system drive encryption is in progress, and the encryption progress is checked. TPM Setting...
  • Page 62 P117-ADL-TRA User’s Manual Select and click the icon in the lower right corner to complete the encryption. TPM Settings...
  • Page 63 P117-ADL-TRA User’s Manual 4. Confirm the completion of encryption. TPM Setting...
  • Page 64 P117-ADL-TRA User’s Manual 5. Disable TPM function in BIOS Setup Utility. 6. When the system is powered on and you see the following screen, it means the TPM module function is working fine. Note that BitLocker cannot be executed if your system does not have TPM function.
  • Page 65 P117-ADL-TRA User’s Manual NOTE: System with no TPM function support is as below: TPM information is not found in Device Manager. When trying to turn on Bitlocker, the following error message shows up. TPM Setting...
