Page Options Dialog Box - Canon imagePROGRAF iPF655 User Manual

Windows Software
Note
• You can input between 0.0 and 100.0(mm) (between 0.00 and 3.94(inch)).
• You can change the numbers by clicking either ▲ button or ▼ button.
Object Frame Style
You can select the object frame style for printing.
The following settings are available for the object frame style.
None
Solid Line
Dotted Line
Dashed Line
Crop Marks
4

Page Options Dialog Box

This dialog box appears when you select Page Options from the File menu. This allows you to configure the roll paper
length, object layout order, and margins of Free Layout.
262
Roll Paper Length
Set the length of one page to print on roll paper.
The following settings are available for roll paper length.
Page Options Dialog Box
> Free Layout >
Setting
You can print with no frame style.
You can print the solid line as the frame style.
You can print the dotted line as the frame style.
You can print the dashed line as the frame style.
You can print with the crop marks.
Details
iPF655
