This is a LifTing Device OnLY. DO nOT MOve Or DOLLY The
vehicLe WhiLe On The Jack. iMMeDiaTeLY afTer LifTing
sUPPOrT The vehicLe WiTh aPPrOPriaTe Means.
DO nOT OverLOaD. OverLOaDing can caUse DaMage TO Or
faiLUre Of The Jack.
LifT OnLY On areas Of The vehicLe as sPecifieD bY The
vehicLe ManUfacTUrer.
cenTer LOaD On saDDLe PriOr TO LifTing. Off-cenTer
LOaDs MaY caUse DaMage TO Jack, LOss Of LOaD, PrOPerTY
DaMage, PersOnaL Or faTaL inJUrY.
This Jack is DesigneD fOr Use OnLY On harD LeveL
sUrfaces caPabLe Of sUsTaining The LOaD. Use On OTher
Than harD LeveL sUrfaces can resULT in Jack insTabiLiTY
anD POssibLe LOss Of LOaD.
nO aLTeraTiOns TO The Jack shaLL be MaDe.
reaD, sTUDY anD UnDersTanD The OPeraTing ManUaL
PackeD WiTh This Jack befOre OPeraTing.
faiLUre TO heeD These Warnings MaY resULT in LOss Of
LOaD, DaMage TO Jack, anD/Or faiLUre resULTing in
PrOPerTY DaMage, PersOnaL Or faTaL inJUrY.
CSE-SJ300 SPECIFICATIONS
Capacity . . . . . . . . . . . . . . . . . . . . . . . . . . 3 Ton
Low Height . . . . . . . . . . . . . . . . . . . . . . .3-3/4"
Raised Height . . . . . . . . . . . . . . . . . . . .9-3/4"
Length . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28"
Chassis Width . . . . . . . . . . . . . . . . . . . . . . . 5"
Saddle Diameter . . . . . . . . . . . . . . . . . . .4-3/4"
Shipping Weight . . . . . . . . . . . . . . . . . 08 Lbs.
FOR YOUR SAFETY AND TO PREVENT INJURY:
CSE-SJ300
Use jack for
lifting purposes
ONLY.
Always support
vehicle with
jack stands.
Meets or exceeds ASME PALD-1997
standards for performance & safety.
Copyright © Professional Tool Products, 2005. All rights reserved.
ThiS operaTing
manual conTainS
imporTanT SafeTy
informaTion.
read carefully
and underSTand
all informaTion
before operaTing
ThiS Tool.
Save ThiS manual
for fuTure uSe.
CSE-SJ300
3 Ton
Service Jack
Rev. 07/24/07
