• Operating Manual • Warning Information • Parts List
SPECIFICATIONS
Capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3 .5 Ton
Low Height . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 .5"
Raised Height . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20 .25"
Length . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29 .75"
Chassis Width . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14 .2"
Saddle Diameter . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 .7"
Shipping Weight . . . . . . . . . . . . . . . . . . . . . . . 105 .6 Lbs .
CSEFJ350BK -BL, -NG, -RD, -RG
3-1/2 Ton Floor Jack
Copyright © Professional Tool Products, 2015,
All rights reserved
CSEFJ350BK, -BL, -NG, -RD, -RG
12/08/15
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Cornwell Tools CSEFJ350BK-BL
Summary of Contents for Cornwell Tools CSEFJ350BK-BL
- Page 1 • Operating Manual • Warning Information • Parts List SPECIFICATIONS Capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3 .5 Ton Low Height .
- Page 2 WARNING INFORMATION This is the safety alert symbol . It is used to alert you WARNING: Indicates a hazardous situation WARNING to potential personal injury hazards . Obey all safety which, if not avoided, could result in death messages that follow this symbol to avoid possible or serious injury .
- Page 3 CSEFJ350BK, -Bl, -NG, -RD, - RG 3-1/2 TON FlOOR JACK OWNER/USER RESPONSIBIlITy The owner and/or user must have an understanding of the manufacturer’s operating instructions and warnings before using this jack. Personnel involved in the use and operation of equipment shall be careful, competent, trained, and qualified in the safe operation of the equipment and its proper use when servicing motor vehicles and their components.
- Page 4 PROPER STORAGE It is recommended that the jack be stored in a dry location with all wheels touching the ground on a relatively level surface. TROUBlESHOOTING Important: Service jacks are self-contained devices used for lifting, but not sustaining, a partial vehicular load. In accordance with ASME-PALD Load Sustaining Test: “A load not less than the rated capacity…shall not lower more than 1/8" (3.18mm) in the first minute, nor a total of .1875" (4.76mm) in 10 minutes.” Lowering within this range is considered normal operation and is NOT a warrantable defect.
- Page 5 CSEFJ350BK, -Bl, -NG, -RD, - RG 3-1/2 TON FlOOR JACK PARTS +18643045659 Item Part Item Part Description Qty. Description Qty. RS35T01 Star Clip RS35017 Saddle RS35T02 Washer (M20) RS35018 Saddle Screw RS35B03 Front Wheel RS35020C Rubber Saddle Pad RS35B10 Rear Caster Assy. RS35T19 Return Spring RS35T08...
- Page 6 CSEFJ350BK, -Bl, -NG, -RD, - RG 3-1/2 TON FlOOR JACK HyDRAUlIC JACK MAINTENANCE GUIDE IMPORTANT: Service jacks are designed for lifting purposes only; always support raised load with jack stands. REGUlAR MAINTENANCE • MONTHLY or as necessary (depending on usage) 1. Using a grease gun, add grease to grease fitting in the lift arm pivot shaft. (Use a multi-purpose NLGI type grease only.) 2.
