Cornwell Tools CSESJ350A Operating Manual

3-1/2 ton service jack;
Hide thumbs
1
2
3
4
5
6

Advertisement

Table of Contents

OPERATING MANUAL
SPECIFICATIONS
Capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3 .5 Ton
Low Height . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 .5"
Raised Height . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20 .25"
Length . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29 .75"
Chassis Width . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14 .2"
Saddle Diameter . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 .7"
Shipping Weight . . . . . . . . . . . . . . . . . . . . . . . 105 .6 Lbs .
CSESJ350A / CSESJ350ANG
WARNING INFORMATION
•
CSESJ350ANG (NEON GREEN)
PARTS LIST
Manufactured to comply with the
•
ASME PASE Safety Standard
Copyright © Professional Tool Products, 2020
1
CSESJ350A (BLUE) /
3-1/2 Ton Service Jack
All rights reserved
11/10/2020

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CSESJ350A and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Cornwell Tools CSESJ350A

Summary of Contents for Cornwell Tools CSESJ350A

  • Page 1 CSESJ350A (BLUE) / CSESJ350ANG (NEON GREEN) 3-1/2 Ton Service Jack OPERATING MANUAL WARNING INFORMATION PARTS LIST Manufactured to comply with the • • ASME PASE Safety Standard SPECIFICATIONS Capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3 .5 Ton Low Height .

  • Page 2: Warning Information

    CSESJ350A (BLUE) / CSESJ350ANG (NEON GREEN) 3-1/2 Ton Service Jack WARNING INFORMATION This is the safety alert symbol . It is used to alert you WARNING: Indicates a hazardous situation WARNING to potential personal injury hazards . Obey all safety...

  • Page 3: Operation

    CSESJ350A (BLUE) / CSESJ350ANG (NEON GREEN) 3-1/2 Ton Service Jack INSPECTION Visual inspection should be made before each use of the jack, checking for leaking hydraulic fluid and damaged, loose or missing parts. Each jack must be inspected by a manufacturer’s repair facility immediately, if subjected to an abnormal load or shock. Any jack which appears to be damaged in any way, is found to be badly worn, or operates abnormally MUST BE REMOVED FROM SERVICE until necessary repairs are made by a manufacturer’s authorized repair facility.

  • Page 4: Proper Storage

    CSESJ350A (BLUE) / CSESJ350ANG (NEON GREEN) 3-1/2 Ton Service Jack IMPORTANT: In order to prevent seal damage and jack failure, never use alcohol, hydraulic brake fluid or transmission oil in the jack. Use Chevron Hydraulic Oil AW ISO 32 or its equivalent Unocal Unax AW 150.

  • Page 5: Regular Maintenance

    CSESJ350A (BLUE) / CSESJ350ANG (NEON GREEN) 3-1/2 Ton Service Jack HYDRAULIC JACK MAINTENANCE GUIDE IMPORTANT: Service jacks are designed for lifting purposes only; always support raised load with jack stands. REGULAR MAINTENANCE • MONTHLY or as necessary (depending on usage) 1.

  • Page 6: Parts List

    RS35019C Rubber Saddle Pad RS35T15BK Handle Lever "A" - Black RS35T19 Return Spring RS35009C Handle Bumper RS35THB Handle Button RS35T13 Set Screw - Handle RSCSESJ350ALK Product Label Kit - CSESJ350A RSCSESJ350ANGLK Product Label Kit - CSESJ350ANG CSESJ350A / CSESJ350ANG 11/10/2020...

This manual is also suitable for:

Csesj350ang
