Cornwell Tools CSEBJ20T Operating Manual

20 ton air/hydraulic bottle jack

Advertisement

Quick Links

OPERATING MANUAL

SPECIFICATIONS

Capacity . . . . . . . . . . . . . . . . . . . . . .20 Tons at 110 psig
Low Height . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-5/16"
Raised Height . . . . . . . . . . . . . . . . . . . . . . . . . . . 19-7/8"
Extension Screw Travel . . . . . . . . . . . . . . . . . . . . 3-1/4"
Ram Travel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-5/16"
Flow Rate, No Load . . . . . . . . . . . . . . . . . . . . 8-1/2 CFM
Saddle Diameter . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3/4"
Base . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-3/8" x 8-3/4"
Shipping Weight . . . . . . . . . . . . . . . . . . . . . . . . 34 .7 Lbs .
CSEBJ20T
Manufactured to comply with the
ASME PASE-2019 Safety Standard
Copyright © Professional Tool Products, 2021
1
CSEBJ20T
20 Ton Air/Hydraulic
Bottle Jack
All rights reserved
1/26/2021

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CSEBJ20T and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Cornwell Tools CSEBJ20T

  • Page 1 CSEBJ20T 20 Ton Air/Hydraulic Bottle Jack OPERATING MANUAL WARNING INFORMATION PARTS LIST Manufactured to comply with the • • ASME PASE-2019 Safety Standard SPECIFICATIONS Capacity . . . . . . . . . . . . . . . . . . . . . .20 Tons at 110 psig Low Height .
  • Page 2 CSEBJ20T 20 Ton Air/Hydraulic Bottle Jack WARNING INFORMATION This is the safety alert symbol . It is used to alert you WARNING: Indicates a hazardous situation WARNING to potential personal injury hazards . Obey all safety which, if not avoided, could result in death messages that follow this symbol to avoid possible or serious injury .
  • Page 3 CSEBJ20T 20 Ton Air/Hydraulic Bottle Jack SETUP WARNING Failure to follow these Setup Instructions may result in serious injury or death, and/or property damage . 1. Refer to the exploded view drawing on page 6 to identify jack components. 2. Assemble the pump handle sections together to make one complete handle. One end of the handle has a cut out that will fit over the cross pin in the release valve in the base of the jack.
  • Page 4 CSEBJ20T 20 Ton Air/Hydraulic Bottle Jack PREVENTATIVE MAINTENANCE Failure to follow these Preventative Maintenance instructions may result in serious injury or death, WARNING and/or property damage . 1. Always store the jack in a well protected area where it will not be exposed to inclement weather, corrosive vapors, abrasive dust, or any other harmful elements.
  • Page 5 CSEBJ20T 20 Ton Air/Hydraulic Bottle Jack WARRANTY COVERAGE Cornwell Quality Tools Company (“Cornwell”) warrants against defects on this product for a period of TWO (2) YEARS from the date of original retail purchase. Subject to the conditions and limitations set forth below, Cornwell will, at its option, either repair or replace any part of the product(s) that proves defective by reason of improper workmanship or materials.
  • Page 6 CSEBJ20T 20 Ton Air/Hydraulic Bottle Jack PARTS LIST Item Item Item Part No. Description Qty. Part No. Description Qty. Part No. Description Qty. Base Reservoir RS2300B30 Piston Ball Filler Plug Seal Ring Nylon Ring Cotton Pin RS2320B04BL Release Valve RS2320B18BL Top Nut...
