• Operating Manual • Warning Information
SPECIFICATIONS
Low Height ........................................................... 6-1/4"
Raised Height ..................................................... 22-3/8"
Length ........................................................................61"
Chassis Width ....................................................... 7-3/4"
Chassis Width w/ Swivel Caster Bracket ......... 18-3/8"
Handle Length .................................................... 45-3/4"
Saddle Diameter .................................................. 5-7/8"
Shipping Weight ................................................338 lbs.
CSETJ1000
• Parts List
Copyright © Professional Tool Products, 2010
1
CSETJ1000
10 Ton
Service Jack
All rights reserved
Rev. 11/03/10
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Cornwell Tools CSETJ1000
Summary of Contents for Cornwell Tools CSETJ1000
- Page 1 Length ................61" Chassis Width ............7-3/4" Chassis Width w/ Swivel Caster Bracket ..18-3/8" Handle Length ............ 45-3/4" Saddle Diameter ..........5-7/8" Shipping Weight ..........338 lbs. CSETJ1000 10 Ton Service Jack Copyright © Professional Tool Products, 2010 All rights reserved CSETJ1000...
- Page 2 CSETJ1000 - 10 TON SERVICE JACK Warning information This is the safety alert symbol. It is used to alert you WARNING: Indicates a hazardous situation WARNING to potential personal injury hazards. Obey all safety which, if not avoided, could result in death messages that follow this symbol to avoid possible or serious injury.
-
Page 3: Operation
CSETJ1000 - 10 TON SERVICE JACK SETUP PLEASE REFER TO THE EXPLODED VIEW DRAWING IN THIS MANUAL IN ORDER TO IDENTIFY PARTS. In order to install the handle assembly item #54 in the handle socket item #32, first align the main handle tube with the largest hole in the handle socket and the lock pin rod with the smaller hole in the handle socket. -
Page 4: Troubleshooting
CSETJ1000 - 10 TON SERVICE JACK PREVENTATIVE MAINTENANCE (Cont.) IMPORTANT: In order to prevent seal damage and jack failure, never use alcohol, hydraulic brake fluid or transmission oil in the jack. Any jack found to be defective as a result of foreign contaminants in the hydraulic system is not eligible for warranty consideration. -
Page 5: Parts Drawing
CSETJ1000 - 10 TON SERVICE JACK PARTS DRAWING RS660954 Power Unit RS660955BL2 CSETJ1000 Rev. 11/03/10... -
Page 6: Parts List
CSETJ1000 - 10 TON SERVICE JACK PARTS LIST Part No. Description Qty. Part No. Description Qty. Frame Cover Washer RS660932BL2 Handle socket RS660903BK Front wheel (incl. #2,3,3a,4,5) RS550511WH Pedal RS660903A Roller bearing set Snap ring Washer Grease fitting RS550535 Bolt Kit (incl. #34,35,36)
