- Page 1 OPERATING INSTRUCTIONS Gravity Slicer Bread Slicing Machine Model PANIS 250 Panis-230228-Rev007-UM-en...
-
Page 2: Table Of Contents
CONTENTS CONTENTS ........................... 1 FOREWORD ......................... 2 Introduction ..........................2 Use ............................2 START-UP..........................3 Opening the packaging ......................3 Installation ..........................3 Wiring ............................ 3 Operation ..........................3 OPERATING FUNCTIONS AND SAFETY PRECAUTIONS ..........4 Operating functions ........................ 4 Mechanical safety devices ..................... -
Page 3: Foreword
The machine may only be used in its original condition and with original parts. It is strictly forbidden to dismantle the safety devices. Should any safety devices be damaged, immediately shut down the machine and contact ADE for repair or replacement. Never use the slicing machine to slice frozen products, meat or sausage products with bones, or stone fruits. -
Page 4: Start-Up
START-UP Upon receiving the package box with the slicing machine, visually inspect the box for any damage that may have occurred during transportation. 3.1 Opening the packaging • Open the box and remove the machine. • Check the box contents and verify that they match the information on the packing slip. Packaging materials are recyclable and must never be disposed of with household waste. -
Page 5: Operating Functions And Safety Precautions
OPERATING FUNCTIONS AND SAFETY PRECAUTIONS 4.1 Operating functions The slicing machine is operated using two buttons: a white “I” start button and a black “O” stop button. The machine also has a power lamp that indicates that the blade is rotating. The slicing machine has a safety cutout that is triggered in case of power failure. -
Page 6: Using The Potato Peeling Machine
USING THE POTATO PEELING MACHINE 5.1 Operating the Machine 1) Set the slice thickness adjustment knob (A) to “0” (zero). 2) Using the carriage arm (B), pull the product carriage as close to yourself as possible. 3) Lift the food holder (C) with the aid of the handle (D) provided for this purpose. With the machine switched off, place the product on the carriage and lower the food holder onto the product or behind it. -
Page 7: Maintaining And Servicing The Slicing Machine
MAINTAINING AND SERVICING THE SLICING MACHINE For the sake of hygiene, the slicer must be kept clean at all times. The machine must be cleaned at the end of each day on which it was used and whenever the type of food being sliced is changed. Only use a damp cloth and neutral detergents to clean the machine. -
Page 8: Lubricating
If the product malfunctions within 2 years from the date of purchase (receipt required) due to defects in material and workmanship, ADE will repair or replace the product. The warranty does not cover moving parts such as blades, sharpening devices, product carriages, etc. -
Page 9: Technical Data
10 TECHNICAL DATA Model Panis 250-230 Blade diameter 250 mm Slice thickness 0-27 mm Cutting area 230 x 190 mm Dimensions (approx.) 440 x 610 x 360 mm Power 0.30 kW Net weight (approx.) 21 kg Current type 230 V... -
Page 10: Wiring Diagrams
12 WIRING DIAGRAMS 12.1 Wiring Diagram 12.2 Circuit diagram Panis-230228-Rev007-UM-en... -
Page 11: Exploded Views
13 EXPLODED VIEWS Panis-230228-Rev007-UM-en... -
Page 12: Spare Parts Lists
14 SPARE PARTS LISTS Panis 250-230V DESCRIPTION QUANTITY ARTICLE NUMBER Blade guard H4013-002 Carriage guide spring H4013-014 Slice thickness Switch H4013-019 Capacitor Drive belt H4013-028 Circular blade, serrated lengthwise H4013-001 Circular blade, serrated lengthwise, with Teflon coating H4013-0011 Leftover holder handle... - Page 13 Panis-230228-Rev007-UM-en...
- Page 14 Panis-230228-Rev007-UM-en...
- Page 15 Panis-230228-Rev007-UM-en...
- Page 16 Distributor: Panis-230228-Rev007-UM-en...
