WolfPack HDTVFIX800E User Manual

4k2k 8x8 hdmi matrix switcher with edid management
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
USER MANUAL
Fixed
4K2K 8x8 HDMI Matrix Switcher with EDID management
HDTVFIX800E
Version: V22.06
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HDTVFIX800E and is the answer not in the manual?

Questions and answers

Related Manuals for WolfPack HDTVFIX800E

Summary of Contents for WolfPack HDTVFIX800E

  • Page 1 USER MANUAL Fixed 4K2K 8x8 HDMI Matrix Switcher with EDID management HDTVFIX800E Version: V22.06...

  • Page 2: Safety Reminder

    Safety Reminder To protect the device and operating personnel from electrostatic discharge, you need to check and ensure that the device is grounding well before the device is powered on. Please observe the following when you install, use, maintain this equipment. Make sure the device ground connection.

  • Page 4: Warnings Of Fcc

    Warnings of FCC This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.

  • Page 5: Table Of Contents

    Contents Warnings of FCC ............................1 1. Product Introduction ........................3 2. Features ............................3 3. Specification ..........................3 4. Connection Diagram ........................4 5. Packing ............................4 6. Panel description ........................... 4 7. Matrix Switcher control ........................ 5 Remote Control ..........................5 APP control ............................

  • Page 6: Product Introduction

    1. Product Introduction This is a new fixed 4K2K HDMI matrix switcher with 8 HDMI inputs and 8 HDMI outputs, the resolution can up to 4K30Hz and all ports are HDCP compliant. With the friendly user control methods by IR remote control, 2-Press push buttons with background blue light, WEB GUI, APP and RS232/UDP commands, this matrix switcher can work with the Blu-Ray Players, Set-Top boxes, Home Theater, and game consoles etc HDMI input sources to route to the HDMI displays, it has been widely used in different audio visual applications.

  • Page 7: Connection Diagram

    4. Connection Diagram 5. Packing Name Unit HDMI Matrix Switcher Pcs. DC 12V2A power adapter Remote Control Rack ear 6. Panel description Front panel ① LCD screen: for the switching, EDID, IP etc information display. ② INPUT: 8 HDMI input buttons ③...

  • Page 8: Matrix Switcher Control

    UP: for upward controlling, or when press input and press UP to all outputs EDID: Press it to enter EDID set mode. SAVE: Press to save the switching status. Down:for upward controlling ENTER: Press to confirm to save the setting. RECALL: Press it to recall the presets/scenes.

  • Page 9: App Control

    Press the input from number “1~8”, then press the output from number“1~9”, can press the outputs continually. Eg. Switch input 1 to output 1, 2, 3: INPUT 1 OUTPUT 1, 2, 3 Switch any inputs to all outputs: Press input from number “1~8”, then press “UP” or “ALL” button. SAVE: for the preset cave.
  • Page 10 Click Submit to login after typing the correct user name and password, and it will turn to the home interface for the sources Switch, Scene Recall/Save: Users can change input, output and Scenes names here, up to 8 characters. Users also can do the settings for the “Setup” tap...

  • Page 11: Web Gui Browser Control

    Users can change the default user name and password from the “Account” Tap: WEB GUI browser Control Users also can use the WEB browser to control the matrix switcher, users can have the matrix switcher connected with the PC with the LAN cable directly or have the matrix switcher connected the same network switch.
  • Page 12 Caption tab is from users to change then input, output, scene names, also can setup the control other devices commands here. EDID setting tab for users to select or setup the EDID for the specific inputs Setup interface for users to do the IP address, COM baud rate and buzzer settings:...

  • Page 13: The 3Rd Party Control Command

    Account interface for users to change the login user name and password: The 3 Party Control command IP address: 192.168.1.80 (default IP) Protocol: TCP(5000), UDP(4000) RS232 Baud rate: 9600, N, 8, 1 Use RS232 direct cable Commands Functional description Example Yall.

  • Page 14: Common Problem Shooting

    8. Common Problem Shooting Serial port operation is out of order, can not control to switch? The serial port is damaged or not started Solution: Make sure the port uses direct serial port line, check the connection of PC software serial port.
