Summary of Contents for WolfPack HDTV-412
- Page 2 Thank you for purchasing this product. For optimum performance and safety, please read the instructions carefully and keep the manual for future reference. · Important Safety Notice Please read below safety instructions carefully before installation and operation: * Please pay attention to all the warnings and hints on this device. * Do not expose this unit to rain, moisture and liquid.
- Page 3 7. Supports YUV 4:4:4. 8. Support 3D. · Package Contents Matrix Switch unit ×1pcs DC12V2A power User manual ×1pcs adapter ×1pcs Remote Controller ×1pcs Wall-mount kit x2pcs · Installation Requirement 1. HDMI source device (DVD, PS3, Set top box, PC etc) 2.
- Page 4 Back Panel · Remote Controller This remote controller is just used for inputs or outputs switched/selected. · Connections 1. Connection Drawing...
- Page 5 Connect all your HDMI source devices to this product's inputs via HDMI cables. Connect up to the HD display devices on the HDMI outputs via HDMI cables. Power on all source device, this Matrix Switch and display device, then it works. Select/switch inputs and outputs via IR remote , buttons or RS232 command.
- Page 6 change to another source device for a try to see the picture quality. 3) Please use high quality HDMI2.0 standard cable when HDMI 4Kx2K signal input. · Specification Disclaimer The product name and brand name may be registered trademark of related manufacturers.TM and ®...
