Exibel 39-3075-1 Manual

Bluetooth-speaker
Art.no 39-3075-1/2/3/4/5 Model Annular
Please read the entire instruction manual before using the
product and then save it for future reference. We reserve the
right for any errors in text or images and any necessary changes
made to technical data. In the event of technical problems or
other queries, please contact our Customer Services.
Safety
• Protect your hearing. Listening on high
volume for prolonged periods can lead to
permanent hearing loss. Set the volume to a
low level before using the product.
• Be careful when using the product if it poses
a possible danger to yourself or others
due to your inability to clearly hear your
surroundings.
• Never subject the product to high temperature,
dust, heavy vibration, or impacts.
• Do not place the product in continuous
sunlight or near naked flames.
• Never attempt to tamper with or modify the
product in anyway.
• Never let the battery charge for extended
periods when it is not inuse. Discontinue
charging during thunderstorms.
• Turn off both the product and mobile phone
in areas where you are requested to do so,
such as in hospitals, aircraft or areas where
there is a risk of explosion.
English
Buttons and functions
1
4
2
3
1. [ + ] Press to raise the volume, hold in to change to
the next track
2. [ ] Press to start and pause music playback. Press to
answer or end a call. Press 2 times to reject an incoming call
or move a call from the speaker to the phone.Press 3 times
to disconnect bluetooth. Hold for 2 seconds to turn the
speaker on/off.
3. [ - ] Press to lower the volume, hold in to change to the
previous track.
4. LED indicator
5. [DC 5V] USB-C port for the included charging cable
Charging
Charge the battery for 3 hours before using the speaker for
the first time.
Min. 1 A
1. Connect the included charging cable to the USB-C port and
to a USB-charger or computer.
2. The LED indicator (4) shines red when charging is in progress.
3. The LED indicator turn off once the battery is fully charged.
Operating instructions
On/off button
On − use with a previously paired external device
Hold [ ] for approximately 3 seconds.
Off
Hold [ ] for approximately 3 seconds.
5
On − to use the earphones with a new external device
Follow the instructions in the Bluetooth connection section.
Bluetooth-anslutning
ON
3 s
1. Switch the speaker on by holding [
2. The LED indicator starts flashing blue. The speaker is now
detectable for other Bluetooth devices.
3. Activate Bluetooth on the device to be paired and begin
scanning for the speaker. When the speaker has been found
by the Bluetooth device it will appear as exibel V!BES.
4. Select the speaker from the list. Once a connection has been
established the LED indicator will shine with a fixed blue light.
5. Start playback on your device. Adjust the volume and control
playback from the Bluetooth device or directly on the speaker.
Note!
3 h • The speaker will automatically connect to the device it was
connected to last (provided that Bluetooth mode is activated
on your device).
• If you want to connect another device, follow the same steps
1−5 above.
3 s
Bluetooth
Devices
exibel V!BES
] for 3 seconds.
