Exibel Basanite 500 Quick Start Manual

Bluetooth-speaker
Art.no 39-2673 Model Basanite 500
Please read the entire instruction manual before using the
product and then save it for future reference. We reserve the
right for any errors in text or images and any necessary changes
made to technical data. In the event of technical problems or
other queries, please contact our Customer Services.
Safety
• Protect your hearing. Listening on high
volume for prolonged periods can lead to
permanent hearing loss. Set the volume to a
low level before using the product.
• Be careful when using the product if it poses
a possible danger to yourself or others
due to your inability to clearly hear your
surroundings.
• Never subject the product to high
temperature, dust, heavy vibration, impacts,
humidity or moisture.
• Keep the product away from water or other
liquids.
• Do not place the product in continuous
sunlight or near naked flames.
• Never attempt to tamper with or modify the
product in anyway.
• Never let the battery charge for extended
periods when it is not inuse. Discontinue
charging during thunderstorms.
• Turn off both the product and mobile phone
in areas where you are requested to do so,
such as in hospitals, aircraft or areas where
there is a risk of explosion.
English
Buttons and functions
1
3
4 5 6
9
1. [ - ] Press to lower the volume
2. [ + ] Press to raise the volume
3. [ MODE/MENU ] Hold to switch between different modes.
Press to flip through the menu.
4. [ LED ] Press to switch between different light modes.
Press and hold for 2 sec. to turn the light off.
5. [ I ◄ ◄ ] Press to change to the previous track
6. [ ►II ] Press to start and pause music playback
7. [ ► ► I ] Press to change to the next track
8. [ ] Hold to turn the speaker on or off.
9. Display
10. Battery charge status indicator
11
12 13
11. AUX/3,5 mm input
12. USB memory slot
13. Micro SD card slot
14. Microphone input
15. [DC 5V] USB-C port for the included charging cable
Charging
Charge the battery for 5 hours before using the speaker for
2
the first time.
Min. 2A
1. Connect the included charging cable to the USB-C port and
8
7 to a USB-charger wit a minimun of 2A.
2. The battery indicator bars (9) will increase and decrease while
charging is in progress.
3. When the battery is fully charged the battery indicator will
show 4 solid bars.
10
Operating instructions
On/off button
On − use with a previously paired external device
Hold [ ] for approximately 2 seconds.
The speaker will automatically connect
Off
Hold [ ] for approximately 2 seconds.
On − to use the earphones with a new external device
Follow the instructions in the Bluetooth connection section.
14
MODE
15
The speaker can play music from four different sources:
- Bluetooth (starts automatically)
- AUX/3.5 mm
- USB memory stick (requires that there are mp3 songs
on the stick and starts automatically when the stick is
inserted).
- Micro-SD card (requires that there are mp3 songs on the
card and starts automatically when the card is inserted).
4- 5 h
2 s
