Exibel Basanite 100 Manual

Bluetooth-speaker
Art.no 39-2675 Model Basanite 100
Please read the entire instruction manual before using the
product and then save it for future reference. We reserve the
right for any errors in text or images and any necessary changes
made to technical data. In the event of technical problems or
other queries, please contact our Customer Services.
Safety
• Protect your hearing. Listening on high
volume for prolonged periods can lead to
permanent hearing loss. Set the volume to a
low level before using the product.
• Be careful when using the product if it poses
a possible danger to yourself or others
due to your inability to clearly hear your
surroundings.
• Never subject the product to high temperature,
dust, heavy vibration, or impacts.
• Do not place the product in continuous
sunlight or near naked flames.
• Never attempt to tamper with or modify the
product in anyway.
• Never let the battery charge for extended
periods when it is not inuse. Discontinue
charging during thunderstorms.
• Turn off both the product and mobile phone
in areas where you are requested to do so,
such as in hospitals, aircraft or areas where
there is a risk of explosion.
English
Buttons and functions
1 2 3 4
6
10 8
9
1. [ M ] Press to switch between different modes.
2. [ ] Press to switch between different light modes.
Press and hold for 2 sec. to turn the light off.
3. [ - ] Press to lower the volume, hold in to change to
the previous track.
4. [ + ] Press to raise the volume, hold in to change to
the next track.
5. [ ] Hold to turn the speaker on/off. Press to start and
pause music playback.
6. Micro SD card slot
7. Battery charge status indicator
8. [DC 5V] USB-C port for the included charging cable
9. USB memory slot
10. AUX/3,5 mm input
Charging
Charge the battery for 5 hours before using the speaker for
the first time.
Min. 1A
1. Connect the included charging cable to the USB-C port and
to a USB-charger wit a minimun of 1A.
2. The battery status indicator (7) shines red when charging is
5
in progress.
3. The battery status indicator turns off once the battery is
fully charged.
Operating instructions
On/off button
On − use with a previously paired external device
Hold [ ] for approximately
2 seconds. The speaker will
automatically connect
7
Off
Hold [ ] for approximately 2 seconds.
On − to use the earphones with a new external device
Follow the instructions in the Bluetooth connection section.
MODE
The speaker can play music from four different sources:
- Bluetooth (starts automatically)
- AUX/3.5 mm (requires that a 3,5 mm cable is connected)
- USB memory stick (requires that there are mp3 songs
on the stick and starts automatically when the stick is
inserted).
- Micro-SD card (requires that there are mp3 songs on the
card and starts automatically when the card is inserted).
Press [ M ] to switch between the different sources as
shown below.
4-5 h
USB SD CARD
1× 1× 1×
Requires Requires
USB memory micro-SD card
2 s
AUX
Requires
3.5 mm cable
