Multi-functional box computer with 12th gen intel processor

Advertisement

Quick Links

User Manual
UBX-210K
Multi-Functional Box Computer
with 12th Gen Intel Processor

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the UBX-210K and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Advantech UBX-210K

  • Page 1 User Manual UBX-210K Multi-Functional Box Computer with 12th Gen Intel Processor...
  • Page 2 The documentation and the software included with this product are copyrighted 2024 by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right to improve the products described in this manual at any time without notice. No part of this manual may be reproduced, copied, translated, or transmitted in any form or by any means without the prior written permission of Advantech Co., Ltd.
  • Page 3 Product Warranty (2 years) Advantech warrants the original purchaser that all of its products will be free from defects in materials and workmanship for two years from the date of purchase. This warranty does not apply to any products that have been repaired or altered by persons other than repair personnel authorized by Advantech, or products that have been subject to misuse, abuse, accident, or improper installation.
  • Page 4 Technical Support and Assistance Visit the Advantech website at http://support.advantech.com to obtain the latest product information. Contact your distributor, sales representative, or Advantech's customer service center for technical support if you need additional assistance. Please have the following information ready before calling: –...
  • Page 5 70 dB (A). The equipment should only be installed in a restricted access area. DISCLAIMER: These instructions are provided according to IEC 704-1 specifi- cations. Advantech disclaims all responsibility for the accuracy of any state- ments contained herein. UBX-210K User Manual...
  • Page 6 Delta/ADP-180WB BE; 60 W adapter: Delta/ADP-60KD BE) suitable for use at TMA 60°C (140°F) min., and the output is rated 24 VDC, 2.5 A min., ES1. If you need further assistance, contact Advantech for additional informa- tion. Consignes de sécurité...
  • Page 7 L'équipement ne doit être installé que dans une zone d'accès restreint. AVERTISSEMENT: Cet ensemble d'instructions est donné conformément à la norme CEI 704-1. Advantech décline toute responsabilité quant à l'exactitude des déclarations contenues dans ce. Ce modèle est destiné à être alimenté par une alimentation certifiée UL (180W adaptateur: Delta/ADP-180WB BE;...
  • Page 8 UBX-210K-UN100 in TW UBX-210K Core i3 N305, 3PUSB, 3Powered COM barebone, UBX-210K-UN200 Made in TW UBX-210K-UN101 UBX-210K ADL-N N97, 8USB, 4COM barebone, Made in TW UBX-210K-UN201 UBX-210K Core i3 N305, 8USB, 4COM barebone, Made in TW UBX-210K User Manual viii...
  • Page 9: Table Of Contents

    Introduction ....................8 UBX-210K I/O Connectors ................ 8 Figure 2.1 UBX-210K Front View ..........8 Figure 2.2 UBX-210K w/ I/O Type A Rear View ......8 Figure 2.3 UBX-210K w/ I/O Type B Rear View ......9 Hardware Installation ................9 2.3.1...
  • Page 10 UBX-210K User Manual...
  • Page 11: Chapter 1 General Information

    Chapter General Information This chapter provides basic information regarding UBX-210K  Introduction  Specifications  Dimensions...
  • Page 12: Introduction

    12th Gen Intel High Performance Processors The UBX-210K is equipped with an Intel N97 or Core i3 N305 processor and built-in Iris graphic chip. It provides powerful computing performance and superior video quality on retail applications.
  • Page 13: Mechanical Specifications

    1 x 24 V/12 V RJ-12 function: connect to cash register drawer. (Default: 24V, via jumper setting; 24V/0.5A or 12V/1A) – I/O Type B: 4 x USB 2.0 Type A 3 x COM (RS232) 1.2.2 Mechanical Specifications 1.2.3 System Dimensions: UBX-210K with I/O Type A:  Unit: mm UBX-210K User Manual...
  • Page 14: Weight

    UBX-210K with I/O Type B:  Unit: mm 1.2.4 Weight 2.3 kg 1.3 Power Requirements 1.3.1 System Power Power Input: DC in 24 V(configured with I/O type A);  DC in 19V or 24V (configured with I/O type B). 1.3.2 RTC Battery Lithium: 3 V/220 mAh ...
  • Page 15: Environmental Specifications

    The system is equipped with a memory and two M.2 SSD: 30G acceleration  Reference IEC60068-2-27:2008, half sine, 11 ms pulse duration  1.4.5 Safety Certification UL, CB, CCC, BSMI  1.4.6 EMC Certification CE, FCC, CCC, BSMI, EN 62368, RED  UBX-210K User Manual...
  • Page 16 UBX-210K User Manual...
  • Page 17: Chapter 2 Hardware Installation

    Chapter Hardware Installation...
  • Page 18: Introduction

    2.1 Introduction The following sections introduce I/Os of the UBX-210K and demonstrate the memory, storage and Wi-Fi module installation. 2.2 UBX-210K I/O Connectors Figure 2.1 UBX-210K Front View Figure 2.2 UBX-210K w/ I/O Type A Rear View UBX-210K User Manual...
  • Page 19: Hardware Installation

    Figure 2.3 UBX-210K w/ I/O Type B Rear View 2.3 Hardware Installation 2.3.1 Memory, M.2 SSD, and WiFi Module Installation Follow these steps to install the memory and M.2 SSD for the UBX-210K. Remove the 8 screws from the bottom cover. UBX-210K User Manual...
  • Page 20 Once you remove the four screws, you'll find a DDR5 memory slot, two SSD slots, and a Wi-Fi module slot on the PCB. To install the memory, insert the DDR5 memory into the memory slot, and then apply the thermal pads onto the DDR5 memory. UBX-210K User Manual...
  • Page 21: Jumper Setting For Powered Com And Rj12 Cash Drawer Connector

    Then, proceed to attach the Wi-Fi module and connect the two antenna cables. Securely screw the cables to establish the connection. 2.3.2 Jumper Setting for Powered COM and RJ12 Cash Drawer Connector +5 V +12 V COM Header 1-2 (default) +12 V +24 V RJ12 Header 2-3 (default) UBX-210K User Manual...
  • Page 22: Wall Mount Kit Installation

    2.3.3 Wall Mount Kit Installation Secure the wall mount kit to the bottom cover of the UBX-210K using four M3 x 5L mm screws provided in the package. Figure 2.4 Wall Mount Kit Installation Step 1 Figure 2.5 Wall Mount Kit Installation Step 2 Choose the correct screws to securely attach the wall mount kit to the wall.
  • Page 23 No part of this publication may be reproduced in any form or by any means, such as electronically, by photocopying, recording, or otherwise, without prior written permission from the publisher. All brand and product names are trademarks or registered trademarks of their respective companies. © Advantech Co., Ltd. 2024...
