3 Technical Description
© InfraTec GmbH 2024
Power supply
AC wide range power supply (100 ... 240) for the supply of power to the
GigE camera (12 V DC).
Via a primary adapter, the power supply can be used either for EU or US
mains wall sockets (both adapters are included by default).
Other primary adapters on request.
Breakout box (optional)
The breakout cable extends the single 6-pin system connector with
proprietary pinout of the GigE camera to standard connectors. This way,
all functions of the GigE system connector can be connected using
standard equipment. The following extension connectors are provided:
Power supply: 6-pin Hirose socket (same as on the camera)

Control interface: D-Sub 9 socket with standard UART/RS232 pinout

I/O ports: 2x BNC sockets

Power over Ethernet (PoE) Configuration (optional)
This powering option consists of an Ethernet cable and a power injector.
This option replaces the regular power supply.
