2 Product Specifications
2.3
Standard Lenses
Focal length
Field of View (FOV)
IFOV (mrad)
Further focal lengths are available on request. Lenses are not removeable.
2.4
Dimensions
Figure 2: TarisIR® mini lens independent dimensions
Figure 3: TarisIR® mini with 13.6 mm, 6.2 mm and 25 mm lens (minimal length depends on focus setting)
© InfraTec GmbH 2024
6.2 mm
(75 × 55)°
1.9
13.6 mm
(32 × 24)°
0.88
25 mm
(17.6 × 13.2)°
0.47
5
