3 Technical Description
3
Technical Description
3.1
Components Overview
The TarisIR® mini comes with a 6-pin system Hirose connector and a RJ45 Ethernet jack.
3
2 1
1 Lens
2 Focus lock ring
3 Metal housing
3.2
Scope of Delivery
Component image
© InfraTec GmbH 2024
4 RJ45 ethernet jack with 2 screw holes
5 6-pin system connector (Hirose)
Designation
TarisIR® mini camera
Including lens
Focus adjustment ring
(Not necessary for every lens, see "Adjusting the focus")
RJ45 Ethernet cable
Standard length: 3m, others on request
5
4
6
