Matatakitoyo Torque Tools NOLT 5 SET Operation Manual

Interchangeable Head Adjustable Torque Handle
Multi Pre-Set Type
OPERATION MANUAL
TORQUE
9X12 14X18
Open Ended Head
Size of the opening & Color
BEFORE STARTING
1. Study this instruction before use.
2. This torque wrench is calibrated and tested before leaving the factory, it is certified to meet the current standard specification and has
an accuracy of ±4%.
3. THIS TOOL IS A PRECISION MEASUREMENT AND DESIGNED FOR MANUAL TIGHTENING FASTERNERS ONLY.
DO NOT USE IT AS A NUT BREAKER OR FOR ANY OTHER PURPOSE.
4. Do not over torquing the fastener, or it will cause tool's damage and serious injury.
5. Do not use this tool near rotating machinery.
6. Disassemble this tool or make any adjustments will result in the loss of accuracy and invalidating the warranty.
7. Do not continuously apply force after hearing the clicking sound or feel shock.
8. Do not use any kind of extension on the handle of the tool. This will not only damage the tool, also affect the accuracy.
9. Use special care at minimum torque setting.
10. Please wear gloves and goggles when working.
WARNING
HOW TO USE
Insert open ended head securely to the Torque Wrench.
STOP
CLICK
Do not continuously apply force after hearing the clicking
sound or feel shock.
Push Button Main Scale
Yellow
Tube Black
Push
Open ended head
The wrench and nut should be
placed parallel to each other.
Models covered
NOLT
5 SET
Handle Grip
White
Red Hand Force
CONTENTS
Open Ended Head : 17, 22, 26, 29mm
Supplied in a
plastic box.
Torque wrench
Manual
