Matatakitoyo Torque Tools MIT Operation Manual

Interchangeable head adjustable torque handlem window scale type
Hide thumbs
1
2

Advertisement

Table of Contents

Interchangeable Head Adjustable Torque Handle
Window Scale Type
OPERATION MANUAL
TORQUE
9X12
14X18
Push Button

BEFORE STARTING

1. Study this instruction before use.
2. This torque wrench as calibrated and tested before leaving the factory is certified to meet the current standard specification and has
an accuracy of ±4%.
3. THIS TOOL IS A PRECISION MEASUREMENT AND DESIGNED FOR MANUAL TIGHTENING FASTERNERS ONLY.
DO NOT USE IT AS A NUT BREAKER OR FOR ANY OTHER PURPOSE.
4. Over torque will cause tool damage and personal injury.
5. Do not use this tool near rotating machinery.
6. Disassemble this tool or make any adjustments will result of losing accuracy and void the warranty.
7. Do not continuously apply force after hear click or feel shock.
8. Do not use any format of extension on the handle of the tool. This will not only damage the tool, also affect the accuracy.
9. Do not immerse grease inside ratchet head. It may cause unexpected damage.
10. Use special care at minimum torque setting.
11. Please wear gloves and goggles when working.
WARNING
Insert square drive securely to the fitting or socket.
Main Scale
Tube
Push
Fitting
Do not continuously apply force after hear click or feel shock.
Graduation Scale
Grip
Torque wrench
Supplied in a plastic box.
STOP
CLICK
Models covered
MIT
Lock ring
Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MIT and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Matatakitoyo Torque Tools MIT

Summary of Contents for Matatakitoyo Torque Tools MIT

  • Page 1 Models covered Interchangeable Head Adjustable Torque Handle Window Scale Type OPERATION MANUAL TORQUE 9X12 14X18 Push Button Main Scale Lock ring Graduation Scale Tube Grip BEFORE STARTING 1. Study this instruction before use. 2. This torque wrench as calibrated and tested before leaving the factory is certified to meet the current standard specification and has an accuracy of ±4%.
  • Page 2 HOW TO SET TORQUE VALUE 1. Push down the lock ring to unlocked. For example : ITEM NO. MIT-200N 2. Turn the adjustable handle Clockwise or To set torque to 135 Nm. Red line of main scale reach 135 Nm (See A).
