Interchangeable Head Adjustable Torque Handle
Window Scale Type
OPERATION MANUAL
TORQUE
9X12
14X18
Push Button
BEFORE STARTING
1. Study this instruction before use.
2. This torque wrench is calibrated and tested before leaving the factory, it is certified to meet the current standard specification and has
an accuracy of ±4%.
3. THIS TOOL IS A PRECISION MEASUREMENT AND DESIGNED FOR MANUAL TIGHTENING FASTENERS ONLY.
DO NOT USE IT AS A NUT BREAKER OR FOR ANY OTHER PURPOSE.
4. Do not over torquing the fastener, or it will cause tool's damage and serious injury.
5. Do not use this tool near rotating machinery.
6. Disassemble this tool or make any adjustments will result in the loss of accuracy and invalidating the warranty.
7. Do not continuously apply force after hearing the clicking sound or feel shock.
8. Do not use any kind of extension on the handle of the tool. This will not only damage the tool, also affect the accuracy.
9. Do not immerse grease inside ratchet head. It may cause unexpected damage.
10. Use special care at minimum torque setting.
11. Please wear gloves and goggles when working.
WARNING
Choose a qualified accessory.
Insert square drive securely to the accessory.
Push Button
Tube
※Accessories are not included.
Push
Accessory
Tube
Main Scale
Graduation Scale
Grip
Torque handle
Supplied in a plastic box.
STOP
CLICK
Do not continuously apply force after hearing the clicking sound
or feel shock.
Models covered
MIT
Grip
Lock Ring
Manual
Advertisement
Table of Contents
Related Manuals for Matatakitoyo Torque Tools MIT-15N
Summary of Contents for Matatakitoyo Torque Tools MIT-15N
- Page 1 Models covered Interchangeable Head Adjustable Torque Handle Window Scale Type OPERATION MANUAL TORQUE 9X12 14X18 Push Button Tube Grip Push Button Main Scale Lock Ring Graduation Scale Tube Grip BEFORE STARTING 1. Study this instruction before use. 2. This torque wrench is calibrated and tested before leaving the factory, it is certified to meet the current standard specification and has an accuracy of ±4%.
- Page 2 9807 Solution : 5 × 135.6 = 678 cN . m SPECIFICATION Metric Accuracy : ± 4% ITEM NO. Range ITEM NO. Range ØD ØD MIT-15N 9x12 3-15 Nm 0.4 Nm 23.9 16.7 20.7 0.22 MIT-150i 9x12 30-150 in.lb 20 in.lb 23.9...
