Matatakitoyo Torque Tools WMT Operation Manual

Wireless Torque Multiplier
OPERATION MANUAL
TORQUE
BEFORE STARTING
1. Study this instruction before use.
2. Please wear gloves and goggles when working.
3. This tool away from water, always store in a dry place and safe environment.
4. Over torque will cause tool damage and personal injury.
5. Never use additional accessories with this tester that were not included and are not from this
manufacturer, doing so could result in damage to the tester.
6. Always operate tester in a clean and organized work place.
7. This tester should always be kept clean, dry, and free from oil and grease.
8. This tool should be recalibrated a period of 1 years, or 5,000 cycles, whichever occurs first.
To contact with local vendor, an authorized repair center for supporting.
WARNING
SPECIFICATIONS
•Worldwide 2.4 GHz ISM Band
•Directions & Accuracy : C.W. ±1％ / C.C.W. ±1.5％
•Display : 5 Digits LCD
•Temp. Range-OPerating : -5℃~55℃
•Temp. Range-Storage : -20℃~70℃
•Humidity : 0~90％
•RS-232 Data out / Optional
1/2" 3/4" 1" 1-1/2"
•Unit Selection : kg-m, N-m, ft.lb, in.lb
•Operating Mode : Auto Reset & Track (See Page-3 Tolerance Setting)
•Memory : 20 Readings
•Battery (Receiver) : 1.5V UM-3 (AA)x3
•Battery (Transmitter) : 1.5V UM-4 (AAA)x3
•Distance : 20m
1 Years
5,000 Times
Models covered
WMT
(Do not use low-discharge battery)
(Do not use low-discharge battery)
