EAGLE
EAGLE EYE™ 9
Installation Guide
*988-13183-002*
Gimbal mounting
1
Recommended pilot holes
Soft/hard materials Ø 3.8 — 4.8 mm (3/16")
Always wear appropriate
⚠WARNING:
eyewear, ear protection, and dust mask
when drilling, cutting, or sanding. Remember
to check the reverse side of all surfaces
whenever drilling or cutting.
7 & 9
®
In the box
A
C
A Eagle
7, Eagle
9, or Eagle Eye™ 9 display unit
®
®
B SplitShot™, TripleShot, or Eagle Eye™ skimmer transducer
C Gimbal kit
D Power cable kit
E Cable lock collars
F Documentation pack
Note:
¼
The Eagle Eye™ 9 and Eagle Eye™ transducer are
exclusively compatible.
2
3
B
D
E
F
