- Page 1 POWERMILL™ CLIMBER ASSEMBLY INSTRUCTIONS M051-00K98-0002 REV CA...
- Page 2 Operation Manuals and other Product Information available at https://www.lftechsupport.com/web/document-library/documents عقوملا ىلع ةحاتم زاهجلا نع ىرخأ تامولعمو ليغشتلا ةلدأhttps://www.lftechsupport.com/web/document-library/documents 操作マニュアルおよびその他の製品情報については、 https://www.lftechsupport.com/web/document-library/documents をご覧く ださい。 如需操作手册和其他产品信息，请登录：https://www.lftechsupport.com/web/document-library/documents 操作手冊和其他產品資訊請見https://www.lftechsupport.com/web/document-library/documents 작동 설명서 및 기타 제품 정보는 https://www.lftechsupport.com/web/document-library/documents 에서 찾을 수 있습니다. Trobareu el manual de funcionament i altra informació de producte a https://www.lftechsupport.com/web/document-library/documents Mae Llawlyfrau Gweithredu a Gwybodaeth Arall am Beiriannau ar gael yn https://www.lftechsupport.com/web/document-library/ documents Die Betriebsanleitung und andere Produktinformationen erhalten Sie unter https://www.lftechsupport.com/web/document-library/...
- Page 3 SAC: 0800 773 8282 option 2 Email:sales@lifefitnessjapan.com Service Email: Telephone: +55 (11) 3095 5200 option 2 kundendienst@lifefitness.com Hong Kong Service Email: Sales/Marketing Email: Life Fitness Asia Pacific LTD suportebr@lifefitness.com vertrieb@lifefitness.com 32/F, Global Trade Square Sales/Marketing Email: 21 Wong Chuk Hang Road vendasbr@lifefitness.com Spain...
-
Page 4: Table Of Contents
5. Specifications © 2019 Life Fitness, A division of Brunswick Corporation. All Rights Reserved. Life Fitness is a registered trademark of Brunswick Corporation. Discover, FitPower, Heart Rate+, LFconnect, Lifepulse, Lifescape, MaxBlox, PowerMill, SureStepSystem, Swipe and Workout Landscape are trademarks of Brunswick Corporation. -
Page 5: Important Safety Instructions
To disconnect, turn power OFF on the ON/OFF switch, then remove plug from electrical outlet. Never operate a Life Fitness product if it has a damaged power cord or electrical plug, or it has been dropped, ƒ... - Page 6 Therefore, the user cannot see if anyone or any thing approaches from the rear. For these reasons this unit is designed for use only in a controlled setting. The PowerMill Climber is not designed for use in the home and should not be used in an environment where children or animals might have access.
-
Page 7: Powermill Set-Up
PowerMill Set-Up Electrical Power Requirements The Life Fitness PowerMill with the Integrity, Discover SE, and Discover SI consoles require an AC power supply accord- ing to the electrical configurations listed in the chart below. Supply Voltage Frequency (Hz) Rated Current (Amps) - Page 8 The location must have a miniminum ceiling height of 9 ft. (2.7 m). Allow at least 3 ft. 1 ft. 1 ft. (1 m) behind the Life Fitness PowerMill Climber and 1 ft. ( 0.3 m ) on each side. Grasp (0.3 m) (0.3 m) the handlebars and use the step assists to mount the PowerMill.
-
Page 9: Service And Technical Data
Preventive Maintenance Tips Life Fitness products are backed by the engineering excellence and reliability of Life Fitness and are one of the most rug- ged and trouble-free pieces of exercise equipment on the market today. Commercial Life Fitness equipment are among the most popular of aerobic trainers in health clubs, colleges and military facilities worldwide. - Page 10 Preventive Maintenance Schedule Item Weekly Monthly Quarterly Biannually Comments Console Overlays Clean Inspect Cup Holder Clean Inspect Console Mounting Bolts Inspect Frames Clean Inspect Plastic Covers Clean Inspect Clean / Lifepulse Sensors Inspect Inspect / Leg Levelers Adjust Side Hand Rails Clean Inspect Steps...
- Page 11 Preventive Maintenance Schedule Continued..Belt Inspection - Brake and Drive belts The Powermill has two belts. A brake belt and a drive belt Item Description Brake belt Drive belt Inspect belts for cracking or wear Figure 1. Belt Cracking If cracks appear 2 cm or less apart, then 80% of the belt life is gone and the belt should be replaced Figure 2.
-
Page 12: Assembly
Assembly Component List and Hardware Identify the following components after unpacking your PowerMill: Description Quantity Step Assist, Left Step Assist, Right M8 X 35MM Socket Head Cap Screw, Black Zinc (step assist, 6) (handlebar, 4) Rear Upright, Left Rear Upright, Right Plastic Grommet (top cover) M10 X 20MM Hex Head Cap Screw, Clear Zinc... - Page 13 Description Quantity Console (Integrity, Discover SE, Discover SI or Explore) #8-18 X 10 Phillips Pan Head Screw, Black Zinc (Integrity Console Only) #6 -16 X 6 Phillips Pan Head Tapping Screw Clear Zinc (Discover and Explore) M5 X 14MM Pan Head Screw (Discover and Explore) Middle Shroud, Console (Discover and Explore) Console Cover (Discover and Explore) Access Panel, Left...
- Page 14 M8 X 35MM Socket Head Cap Screw, Black Zinc (#3) Plastic Grommet (#6) M10 X 20MM Hex Head Cap Screw, Clear Zinc (#7) M8 X 16 MM Hex Button Head Cap Screw (#36) M8 X 18MM Hex Washer Head Screw, Clear Zinc (#10) #8-18 X 10 Phillips Pan Head Screw, Black Zinc (#28) M4 X 16MM Phillips Pan Head Screw, Black Zinc (#12) M5 X 14MM Pan Head Screw (#30)
- Page 15 18 - 20 ft. lbs. (24.4 - 27.1 Nm)
- Page 16 28- 32 ft. lbs. (38 - 43.3 Nm) 18 - 20 ft. lbs. (24.4 - 27.1 Nm) Integrity Console Upright Shown...
- Page 18 User User 16 - 18 ft. lbs. (21.7 - 24.4 Nm) 18 - 20 ft. lbs. (24.4 - 27.1 Nm)
- Page 19 TIGHTEN HANDLEBAR, UPRIGHT, and MONOCOLUMN BOLTS (20 BOLTS)
- Page 21 Rear View User User...
- Page 23 Remote Switches Ground Ground Wires Wire COAX Remote Switches Attachable TV Power MCB Communication CAT5e Lifepulse C-SAFE Lifepulse Extension (#39) 24V DC C-SAFE Extension (#40) Cable Discover Explore Integrity Integrity with Attachable TV MCB Communication Connects to #41 Connects to #37 Lifepulse (2) Connects to #41 Connects to #39...
- Page 24 13 a Remote Switch Up/Down Interface PCB to Console (#38) Ground spade on this cable connects to grounding spade attached to upright. Connect Grounding Cable on Upright to Ground Spade on Circuit Board (#37) Motor Controller to Interface PCB Remote Switch (also plugs into cable coming up through upright) Go/Stop Attachable TV Connector...
- Page 25 13 b Discover SE CAT 5e Ethernet 24VDC Power Coax, RG6, (#41) Base Ground Wire Discover SI CAT 5e Ethernet 24VDC Power (#41) Ground Wire...
- Page 26 13 c Lifepulse / Switches Ethernet Communication / Chassis Power Ground...
- Page 27 Integrity Console Explore and Discover Console...
- Page 28 MAKE SURE ALL HARDWARE IS TIGHT! MAKE SURE ALL LEVELERS ARE DOWN!
-
Page 30: Specifications
Specifications 5.1 Life Fitness PowerMill Designed use: Heavy / Commercial Maximum user weight: 400 lbs. / 181 kg Ceiling height minimum: 9 ft. / 2.7 m Usable step surface area: 205 sq. in. (520.7 cm) Power requirements: 100 - 240 volts, 50/60Hz, 3 Amps... - Page 31 Fit Tests / Fit Test, CPAT Test, WFI SubMax Evaluate *LFconnect on-console features are compatible with the Elevation Series Discover SI when connected to the Internet. Internet connectivity is recommended for optimal facility owner and exerciser experience. Life Fitness Patents Pending...
