  • Page 1 Manual Diaz Huka makes your world easier www.huka.nl...

  • Page 2: Your Notes

    Your notes EXTEND YOUR STANDARD WARRANTY TO 10 YEARS WWW.HUKA.CO.UK/WARRANTY...
  • Page 3 Congratulations on your new Diaz Ride carefree and experience the freedom, independence and stability as you used to? With your Diaz we like to make your world easier. Probably you would rather go cycling than read the manual. Therefore we have put together a manual where the most important topics are covered.

  • Page 4: Table Of Contents

    General..................... 7 Indication & intended use ................7 Warranty ......................8 EU Declaration of Conformity ..............10 First bike ride on the Diaz ................ 11 Safe on the road ..................11 Boarding and cycling ..................13 Brakes ......................14 Cycling with pedal assistance ..............14 Display ......................
  • Page 5 Saddle depth adjustment ................25 Setting the saddle angle ................26 Handlebar height adjustment ..............26 Handlebar stem with quick release ............. 27 Dear Maintenance Diaz ................28 Cleaning ....................... 28 Tire pressure & tread ................... 29 Tire Paste ..................... 30 Wheels ......................
  • Page 6 Lighting ......................33 Moving and carrying the bike ..............34 Specifications ..................35 Other information ................... 37 Contact details Huka ..................37 Changes ......................37 Disposal product ..................38 Recycling the battery ................... 38 Sale of the Diaz .................... 39...

  • Page 7: General

    • The Diaz complies with all laws and regulations applicable to public road use. Use of the Diaz as a racing or cross country bike is beyond the normal use and responsibility of Huka. • It is your responsibility to act according to the specific safety requirements of the country where you are cycling.

  • Page 8: Warranty

    WARRANTY Huka offers a 5-year warranty on the frame of the Diaz and a 2 year warranty on the battery and other parts. All warranty’s are carried out by your Huka dealer. • The warranty does not apply to damage or defects to the Diaz caused by improper or injudicious use.
  • Page 9 TIP FROM MURAT Write down the frame number of your Diaz below. The number is important for warranties, repairs or in case your wheelchair bike is stolen for reporting to your insurance. The number can be found just above the bottom bracket on the back of the seat post on the frame tube.

  • Page 10: Eu Declaration Of Conformity

    Risk Class: Class 1 Huka uses the following procedures for the CE marking of their products according to Regulation MDR 2017/745: Class 1: according to (EU) 2017/745 Annex VIII. This declaration of conformity is provided under the exclusive responsibility of Huka. We hereby declare that medical device(s) specified above comply with the provision of Regulation (EU) MDR 2017/745 for medical devices.

  • Page 11: First Bike Ride On The Diaz

    First bike ride on the Diaz The time has come. The first experience on your own Diaz! Which bike ride you take, your safety comes first! Should you be riding a Huka wheelchair bike for the first time, it may take some getting used to. The most important tip we can give you is that you should relax as much as possible while cycling.
  • Page 12 The passenger must wear the seat belt while cycling. • Wear an appropriate bicycle helmet. • The Diaz is largely made of steel which is considered non-flammable. The other materials used such as plastic, rubber and the like are not fireproof. •...

  • Page 13: Boarding And Cycling

    BOARDING AND CYCLING Always use the parking brake when mounting or dismounting. The parking brake prevents the bicycle from rolling away which can lead to dangerous situations. • When getting on as a rider, lift your foot to the other side so that your feet are on either side of the wheelchair bike.

  • Page 14: Brakes

    CYCLING WITH PEDAL ASSISTANCE Your Diaz is equipped with pedal assistance and the electric motor is turned on as soon as the system is on and you start pedaling. The pedaling becomes lighter.

  • Page 15: Display

    DISPLAY Your Diaz is equipped with a display that shows status of the battery. The display also shows the speed, trip distance (Trip) and total distance (ODO). With the plus and minus button you can choose the level of support.

  • Page 16: Headrest Adjustment

    HEADREST ADJUSTMENT The headrest can be adjusted in height, depth and angle. • If you want to adjust the height of the headrest, you can slightly loosen the star knob on the backrest, slide the headrest to the desired height and tighten star knob again.

  • Page 17: Product Description

    Product Description The Diaz consists of several parts. We describe the most important parts in this section. BIKE FRAME The frame of the Diaz consists of tubular metal construction supplemented by aluminum and stainless steel components. Most metal parts are phosphated and then provided with an impact-resistant powder coating.

  • Page 18: Chain Guard & Chain

    With proper chain tension, the Diaz pedals lightly and you hardly hear the chain. If you notice that a chain is too slack, have it adjusted by your Huka dealer.

  • Page 19: Bottom Bracket, Crankset And Pedals

    Various (custom) pedals are optionally available. GEARS Your Diaz is standard equipped with 5-speed or 8-speed gears with back pedal brake, Upon delivery your Huka dealer has checked and adjusted the gears correctly. The explanation of the gear hub can be found in the manual of Shimano.

  • Page 20: Handlebar

    The luggage carrier is made of aluminum. There are several possibilities to carry luggage. Ask your Huka dealer the right materials are used and the whole is safely mounted. On a Diaz the battery pack is mounted under this carrier.

  • Page 21: Electric Pedal Assistance

    ELECTRIC PEDAL ASSISTANCE The Diaz is equipped with electric pedal assistance, by means of a middle motor in the frame and a battery pack under the luggage carrier. A display with controls is mounted under the handlebars.

  • Page 22: Wheelchair Parking Brake

    WHEELCHAIR PARKING BRAKE When getting on or of the wheelchair, always put the wheelchair's parking brake on. To do this, squeeze the right brake lever, push the pin down and release the brake lever again (see photo). Pen press Squeeze the brake lever DISCONNECTING WHEELCHAIR You disconnect the wheelchair bike by completing the following steps: •...

  • Page 23: Attaching Wheelchair

    Tilt the wheelchair Lift the frame out of Putting frame on stand forward the lock ATTACHING WHEELCHAIR You connect the wheelchair bike by completing the following steps: • Put the wheelchair on the parking brake. • Link the bicycle part to the wheelchair by hanging the hook in the receiving part of the wheelchair.

  • Page 24: Accessories

    ACCESSORIES The Diaz can be expanded with various accessories. Think of a headrest, foot fixation, mirrors, spoke cover, or for example other belts besides the standard lap belt. More information about accessories can be found at the Huka dealer who supplied the Diaz.

  • Page 25: Optimal Use

    Optimal use Upon delivery of your new Huka, the components should be properly adjusted to your body and to your needs. To make sure you sit comfortably, there are options to adjust the saddle and handlebars to your wish. SADDLE HEIGHT ADJUSTMENT 1.

  • Page 26: Setting The Saddle Angle

    SETTING THE SADDLE ANGLE 1. Using a socket wrench 13, loosen the saddle bolt slightly to allow the saddle to rotate. 2. Tilt the saddle to the desired angle. Tighten the saddle bolt securely Saddle height with quick tensioner Setting the saddle angle Saddles and handlebars should be securely fastened.

  • Page 27: Handlebar Stem With Quick Release

    HANDLEBAR STEM WITH QUICK RELEASE 1. Slide the locking tab up 2. Pull up the lever 3. Place handlebars in desired position 4. Push the lever closed again until the locking tab clicks into place The lever must close with a resistance of 120-150N. Otherwise, the handlebar may come loose during cycling which can lead to serious injuries.

  • Page 28: Dear Maintenance Diaz

    Optimal riding comfort is created by keeping the wheelchair bike properly maintained. In this chapter we will show you how to do this. We also advise you to do the annual maintenance by your Huka dealer. They check the Diaz for functionality, safety and possible wear.

  • Page 29: Tire Pressure & Tread

    Check tire pressure and tread regularly for optimal grip on the road. This will prevent unnecessary wear and tear on the tires of your Diaz. It also makes cycling more pleasant and allows you to react better to braking and steering movements.

  • Page 30: Tire Paste

    TIRE PASTE Did you find out that a tire on the Diaz is flat? Your Huka dealer can, of course, patch the tire. But should you want to do it yourself, here are instructions. Required: a repair kit (with tire levers, glue, stickers and sandpaper, trestle or jack, scissors, bicycle pump and a bucket of water).

  • Page 31: Wheels

    The front brake is easily adjusted slightly tighter with the adjustment bolt on the inside of the right brake handle. Are the brakes not adjustable or does the Diaz still not brake properly? Then have it checked and adjusted by your Huka...

  • Page 32: Battery Charging

    REPLACEMENT OF PARTS Is your Diaz defective or need parts replaced? We advise you to have this done by your Huka dealer. Partly this prevents you from voiding the factory warranty.

  • Page 33: Lighting

    LIGHTING The Diaz features battery-powered LED lighting front with low power consumption and long life. Eventually the batteries will need to be replaced. These are available at various stores. You replace the headlight batteries by unscrewing the screw at the bottom with a screwdriver.

  • Page 34: Moving And Carrying The Bike

    MOVING AND CARRYING THE BIKE To move or carry the bike, it is best to disconnect the bike part first from the wheelchair. The bike part is best grasped at the back by the rack and at the front by the head tube. The wheelchair is best grasped at the back by the steering tube and at the front by the frame tubes.

  • Page 35: Specifications

    Specifications Standard version Frame material anti-corrosion treated steel Finish exterior grade epoxy powder coating Wheels aluminum rim with stainless steel spokes Tires Tires with anti-puncture Lighting Battery lighting front and rear via battery Bicycle bell sporty- and light-operated bell Fenders impact and shape resistant plastic Chain guard impact-resistant closed plastic chain guard...
  • Page 36 Bike Part Wheelchair part Length total in mm (H) 2350 Width overall in mm (M) Weight in kg Maximum load total in kg Maximum load in kg Crank length in mm Inside leg length in mm (F) (D) 780-930 100-550 Saddle height to ground in mm 910-1060 Entry depth in mm...

  • Page 37: Other Information

    7575 ED Oldenzaal 0541-572472 info@huka.nl www.huka.nl For questions about the maintenance of your Diaz, we refer you to your Huka dealer. CHANGES Huka follows the philosophy of continuous product development and improvement. As a result, the product delivered may differ from the images shown.

  • Page 38: Disposal Product

    DISPOSAL PRODUCT Are you no longer using the Diaz? Then contact your Huka dealer. They can guide you with a possible sale or trade-in of it. If you want to dispose of your Diaz, you can also contact your local waste disposal company. They will dispose of the bike according to the regulations and laws in force in your hometown.

  • Page 39: Sale Of The Diaz

    SALE OF THE DIAZ If you want to sell your Diaz to another user, it is important that you hand over all the necessary technical documentation so that the new owner can safely use the wheelchair bike. Have the wheelchair bike inspected by your Huka dealer before sale to ensure that the Diaz is sold in good condition.
  • Page 40 To best meet the needs of individual riders, we believe good service is essential! Huka is known for its good service and far-reaching commitment. Do you own a Huka bike and would like to have periodic maintenance done? Our dealers are happy to perform all maintenance...
