- Page 1 MANUAL MANUAL Tricycle Tricycle Cortes Cortes Huka makes your world easier www.huka.nl/en version 04/21...
- Page 2 Your notes Extend your standard GUARANTEE to 10 YEARS VIA WWW.HUKA.NL/ en/warrantly...
- Page 3 Cortes. Please read this manual thoroughly before using the Cortes and always follow the instructions given in the manual. To get the most out of your tricycle I will sometimes give you a few advices to keep cycling safe and enjoyable.
-
Page 4: Table Of Contents
Contents General Indication & application Warranty EU Declaration of conformity First bike ride on the Cortes Safe on the road Boarding and cycling Brakes Cycling with pedal assistance Battery indication Moving and carrying the bike Product description Bicycle frame Drive... - Page 5 Setting the seat angle & height Setting the steering angle Setting the handlebar height Multi-adjustable stem height setting Handlebar stem Angle adjustment Setting the switch stem Wheels Tyre pressure Best maintenance Cortes Cleaning Tyre pressure & tread Bonding Spokes Chain Brakes Lighting Charging the battery...
-
Page 6: Indication & Application
• The Cortes is designed to be used on normal public roads and cycle paths. • The Cortes complies with all laws and regulations applicable to the use of. - Page 7 ADVICE FROM RICHARD Please write down the frame and key number of your Cortes below. The number is important for guarantees, repairs or in case your bike is stolen for reporting to your insurance company. You will find the number on the frame tube just above the bottom bracket, on the back of the seat post.
-
Page 8: Eu Declaration Of Conformity
And equipped with the CE mark that can be identified by the: labels on the tricycle's main frame and illustrated in the Warranty section of this manual. Signed on behalf of Huka, R. Lotgerink, Managing Director Date: 15 April 2021... - Page 9 www.huka.nl/en...
-
Page 10: First Bike Ride On The Cortes
The time has come. Your first experience on your own Cortes! Whatever bike ride you do, your safety comes first! If it is your first time cycling on a Huka tricycle, you might have to get used to it. The most important tip we can give you is that you have to relax as much as possible while cycling. -
Page 11: Boarding And Cycling
Avoid sudden and violent steering movements. In this way you can avoid accidents and damage. Adjust your speed before turning so that all wheels stay on the ground. Leaning in helps with this. www.huka.nl/en... -
Page 12: Brakes
Brakes The Cortes is equipped with hand brakes. Braking is done by squeezing both brake levers on the handlebars. The left hand brake operates the front wheel brake. -
Page 13: Battery Indication
To move or carry the bike, you can grab it by the frame tube at the back and by the head tube at the front. We recommend that at least two people should be used to lift the bike. When lifting, also hold the handlebars to prevent the front wheel and handlebars from turning and possibly causing injury. www.huka.nl/en... -
Page 14: Product Description
Product description Your Cortes consists of several parts. The most important parts are described in this chapter. Bicycle frame The frame of the Cortes consists of a tubular metal construction complemented by aluminium and stainless steel components. Most of the metal parts are phosphated and then provided with an impact-resistant powder coating. -
Page 15: Spokes
Brakes The basic model of the Cortes is equipped with a V-brake as a front brake. Next to that the hydraulic disc brakes control the rear wheels. Your Huka is also provided with a parking brake that you use when getting on and off the bike. -
Page 16: Bottom Bracket, Crankset & Pedals
Bottom bracket, crankset and pedals • The bottom bracket bearings that Huka uses are completely maintenance-free and cannot be adjusted. If the bearing does get loose, go to your Huka dealer immediately. If there is play between the crank and the bottom bracket, take off the dust cap and tighten the underlying bolt with a socket spanner 14. -
Page 17: Lighting
Lighting The Cortes is equipped with lighting that is connected to the battery. Therefore, the Cortes is not equipped with batteries. Seat system The seating system provides comfort and stability while cycling and is adjustable in depth and angle. It is very important to adjust the seating system correctly in order to cycle efficiently, comfortably and safely. -
Page 18: Electric Pedal Assistance
Electric pedal assistance The Cortes is equipped with electric pedal assistance. The bike is equipped with a mid-motor which is mounted to the frame in a specially designed adaption. The battery pack and electronics box are mounted to the rear frame. -
Page 19: Accessories
Li-ion battery that is mounted via a special adapter at the back of the basic frame. Accessories Your Cortes can be expanded with various accessories. Think of a footrest, another handlebar, cable lock, etc. More information can be found on the price list on our website or contact your Huka dealer. -
Page 20: Optimal Use
Optimal use Upon delivery of your new Huka, the parts have been adjusted to your body and to your wishes. To make sure you are comfortable, there are adjustment possibilities for the seat system and handlebars. Setting the seat depth 1. -
Page 21: Setting The Steering Angle
2. Pull or push the handlebar to the desired height. Make sure that 3. Make sure that the stem remains in the frame enough, so that the safety 4. the safety marking ''MIN'' is not visible. 5. Tighten the stem bolt again securely according to the specified torque on page 19. www.huka.nl/en... -
Page 22: Handlebar Stem
Handlebar stem angle adjustment 1. Use a size 6 Allen key to loosen the angle adjustment bolt slightly so that the handlebars can turn. 2. Turn the handlebar to the desired angle. 3. Tighten the angle adjustment bolt again securely according to the described tightening torque on page 17. -
Page 23: Wheels
Always inflate the tyres properly. This will prevent wear and tear on the tyres of your Cortes. It is also a more pleasant ride and you will be able to react better to braking and steering movements. The right pressure is reached when you can press the tyre with your thumb. -
Page 24: Best Maintenance Cortes
Optimum riding comfort is created by maintaining the bike properly. In this chapter we show you how to do this. Besides, we advise you to have your Huka dealer do the yearly maintenance. They will check the Cortes for functionality, safety and possible wear and tear. -
Page 25: Bonding
Bonding Did you find out that a tyre of the Cortes is flat? Your Huka dealer can of course fix it. But if you want to do it yourself, here are the instructions: Necessary: a repair kit (with tire levers, glue, stickers and sandpaper), a jack, scissors, a bicycle pump and a bucket of water. -
Page 26: Spokes
Are the brakes not adjustable or does the Cortes still not brake well? Then have them checked and adjusted by your Huka dealer. The rear wheels are braked with a hydraulic disc brake. This is a closed system filled with brake oil that does not require adjustment. -
Page 27: Lighting
Charging the battery The Cortes is always equipped with pedal assistance. Check before you start cycling that the battery is still sufficiently charged. Depending on the capacity, charging takes between 3 and 6 hours. Always use the supplied original battery charger. - Page 28 Bafang 1. Attach the adapter to the charging plug. 2. Plug the charging plug into the mains socket. 3. Connect the adapter to the battery's charging port. Shimano StepS Step 2 Step 3 Step 1 Accu replace 1. Place the battery pack on the back of the rail on the battery holder. Slide the battery pack forward and then push it in firmly.
-
Page 29: Replacing Components
Replacement of parts Is your Cortes broken or do parts need to be replaced? We advise you to have this done by your Huka dealer. This way you prevent the factory warranty from expiring. Always have original Huka parts mounted on your bicycle. Your Huka dealer can take care of that for you. -
Page 30: Specifications
Specificati o ns Standard versi i on Material frame anti-corrosion treated steel Coating outdoor quality epoxy powder coating Color matt black (RAL9005) or matt grey (RAL7040) Wheels double-butted rim and hub with stainless steel spokes Tyres Schwalbe Big Ben Plus (anti-puncture) freewheel with differential in rear axle Drive Speed hub... - Page 31 Height adjustment seating system in mm (F) Seating system width in mm Maximum load in kg Front tyre size in ETRTO 55-507 Front tyre size in inches 24 x 1,75 Tyre size rear in ETRTO 55-406 Tyre size rear in inches 20 x 1,75 www.huka.nl/en...
-
Page 32: Contact Details Huka
For the most recent version of the manual go to www.huka.nl/en/manual Removal of product Do you no longer use the Cortes? Please contact your Huka dealer. They can guide you with a possible sale or trade-in. If you want to dispose of your tricycle, you can also contact your local waste disposal company. -
Page 33: Selling The Cortes
We advise you to have the bicycle checked by your Huka dealer before selling it, so you can be sure that the Cortes is sold in good condition. Do you want to buy a used Huka-bike? Then we advise you to have it checked by your Huka dealer. They can check if the bicycle is subject to wear and tear, and/or if there are any hidden defects. - Page 34 Your notes...
- Page 35 Extend your standard GUARANTEE to 10 YEARS VIA WWW.HUKA.NL/ en/warrantly www.huka.nl/en...
- Page 36 Our bikes can be used by anyone. Unlimited. If you like it and it offers you the functionality you're looking for, then a Huka will suit you. Our team works together with visible pleasure on (new) solutions. That is what we go for every day. Unlimited.
