Omcan AURORA DA-CN-0353 Instruction Manual page 11

Allow 24 hours before switching on the cabinet. During this time we recommend that you leave the door open
to clear any residual odors.
BEFORE LOADING & PLUGGING IN THE CABINET
RECOMMENDATIONS:
Cabinet should be install at suitable ambient temperature. If the temperature is higher or lower the ambient
temperature range, it will affect temperature fluctuation and can't reach cooling performance.
INSTALLING YOUR CABINET
Unpack and remove all of the protection and adhesive strips from the packaging around and inside the cabinet.
The cabinet must be positioned such that the plug is accessible. Release the power cord. Move your cabinet to
its final location. The cabinet should be installed in a suitable place where the compressor will not be subject
to physical contact.
LEVELING YOUR CABINET:
Cabinet must be leveled BEFORE loading your cabinet.
Your cabinet is equipped with 4 adjustable feet to facilitate easy leveling. We recommend that you tighten the
back feet to the maximum and adjust the front feet to level the cabinet.
INSTALLATION INSTRUCTIONS FOR BUILT IN CABINET: FRONT VENTING CABINET ONLY.
INSTALLATION GUIDE
1. "Built in" cabinet are front venting but are not designed to be fully integrated behind a joinery door.
2. Please follow the installation diagram when installing built-in cabinet. No less than the minimum
installation dimension.
3. Built-in cabinet draw air from right of ventilation frame and expel through left of ventilation frame under the
front door.
4. "Built-in" cabinet have a power switch located on the control panel so power point location is not critical.
5. The cabinet requires a standard 240 volt/10 amp power point (or according to different countries
specifications).
6. The power cord is 2.0m in length and is fixed on the right side at the back when looking from front of
cabinet.
7. As with most appliances of today, the cabinet has sensitive electronic components which are susceptible
to damage through lightning and electricity supply faults. It is therefore advised to use a power surge
protector to avoid problems of this nature.
8. Air vent on door must be provided for built-in cabinet when a wood door installed.
In hot climate zone, an air vent or grid, with a minimum ventilation size of 200mm x 40mm MUST be cut out
at the rear top of the back partitioning or at the top of either side of the partitioning, allowing cool fresh air full
access to flow into the 30mm gap located at the rear of the cabinet.
