SMART-AVI SPS-4000 Quick Start Manual

TECHNICAL SPECIFICATION
VIDEO
Host Interface (4) HDMI 19-pin (female
User Console
(2) HDMI 19-pin (female)
Interface
CONTROL
Front Panel Buttons (SELECT audio/video source)
RS232 Via Control @ 115200 bps
Web GUI Via LAN
OTHER
External 100-240 VAC/12VDC3A @
Power
24W
Dimensions 12.57" W x 1.76" H x 6.69" D
Weight 4.2 lbs
Approvals UL, CE. ROHS Complaint
Operating Temp. +32 to +104°F (0 to +40°C)
Storage Temp. -4 to 140°F (-20 to +60°C)
Humidity 5 to 90% (No Condensation)
WHAT'S IN THE BOX
PART NO. Q-TY DESCRIPTION
4K60 HDMI Presentation
SPS-4000 1 Switcher with 4 Inputs and
2 Outputs
Power Supply 1 PS12VDC3A
Quick Start Guide 1
NOTICE
The information contained in this document is
subject to change without notice. SmartAVI makes
no warranty of any kind with regard to this material,
including but not limited to, implied warranties of
merchantability and fitness for particular purpose.
SmartAVI will not be liable for errors contained
herein or for incidental or consequential damages in
connection with the furnishing, performance or use of
this material.
No part of this document may be photocopied,
reproduced, or translated into another language
without prior written consent from SmartAVI
Technologies, Inc.
888.994.7427, 702.800.0005
2917 E Alexander Rd.
North Las Vegas, NV 89030
SmartAVI.com
SPS-4000
4K60 HDMI
Presentation Switcher with
4 Inputs and 2 Outputs
EXPERIENCE SEAMLESS
CONTROL WITH
OUR 4-PORT SINGLE HEAD
HDMI PRESENTATION SWITCHER,
OFFERING VIRTUALLY ZERO
VIDEO DELAY DURING CHANNEL
SWITCHING AND UHD 4K@60
VIDEO RESOLUTION
Quick Start Guide
