- Page 1 SM-KMN-08 8-Port KM Switch with AUDIO AND USB 2.0 USER MANUAL Designed and Manufactured in the USA 1-888-994-7427 www.smartavi.com...
-
Page 2: Table Of Contents
OVERVIEW TECHNICAL SPECIFICATIONS_________________________________________________________________ WHAT’S IN THE BOX?_________________________________________________________________________ FRONT AND BACK___________________________________________________________________________ INSTALLATION_______________________________________________________________________________ INITIAL SETUP________________________________________________________________________________ SCROLL WHEEL KM SWITCHING______________________________________________________________ HOTKEY COMMANDS________________________________________________________________________ DISPLAY TOPOLOGY CONFIGURATION_______________________________________________________ LIMIT INPUT PORTS CONFIGURATION________________________________________________________ SYSTEM OPERATION_________________________________________________________________________ FRONT PANEL CONTROL_____________________________________________________________________ HOTKEY AND RS232 SERIAL CONTROL_______________________________________________________ CUSTOM HOTKEY TRIGGERS_________________________________________________________________ LED’S BEHAVIOR______________________________________________________________________________ TROUBLESHOOTING_________________________________________________________________________ TECHNICAL SUPPORT________________________________________________________________________ LIMITED WARRANTY STATEMENT____________________________________________________________... -
Page 3: Technical Specifications
Technical Specifications Signal Type USB 2.0, 1.1, and 1.0 w/ internal hub Input Interface (8) USB Type B (2) USB 1.1 Type A for KM Devices; Output Interface (2) USB 2.0 Type A Transparent AUDIO Input Interface (8) 3.5 mm Stereo Audio Output Interface (1) 3.5 mm Stereo Audio CONTROL... -
Page 4: What's In The Box
PART NO. Q-TY DESCRIPTION SM-KMN-08 8-Port KM Switch with Audio and USB 2.0 PS12VDC2A 12VDC 2A (minimum) power adapter with center-pin positive polarity. User Manual FRONT AND BACK SM-KMN-08 Back SM-KMN-08 Front 8-Port KM Switch with USB 2.0 Support and Audio... -
Page 5: Installation
INSTALLATION 1. Ensure that power is turned off or disconnected from the unit and the computers. 2. Use a USB cable (Type-A to Type-B) to connect a USB port on each computer to the respective USB ports of the unit. 3. -
Page 6: Initial Setup
INITIAL SETUP After connecting all devices to the SM-KMN-08, a display topology configuration and display mode must be chosen. By default, SM-KMN-08 is configured to a topology with 8 screens arranged horizontally starting with port 1 on the most left-hand side. -
Page 7: Hotkey Commands
The Hotkey command is a keyboard sequence used to trigger an action on the SM-KMN-08 through the use of the keyboard connected on the USB port of the SM-KMN-08. To activate the hotkey sequence, press the CTRL key twice and then enter the desired hotkey commands. -
Page 8: Display Topology Configuration
DISPLAY TOPOLOGY CONFIGURATION The SM-KMN-08 has a configurable display topology configuration that can be easily activated through keyboard hotkeys. No software or drivers are required to configure the display topology. Note: Hotkey CTRL+CTRL command allows for multiple rows. (1) Hotkey Command: “CTRL + CTRL + H + 4 + ENTER”... -
Page 9: Limit Input Ports Configuration
LIMIT INPUT PORTS CONFIGURATION Hotkey Commands: CTRL, CTRL W(X) commands (allows one row only): CTRL + CTRL + W + 8 + ENTER CTRL + CTRL + W + 7 + ENTER Note: Port 8 N/A CTRL + CTRL + W + 6 + ENTER Note: Port 7, 8 N/A CTRL + CTRL + W + 5 + ENTER Note: Port 6-8 N/A... -
Page 10: System Operation
LED of that port will turn on. hotkey and rs232 serial control The SM-KMN-08 may also be controlled via RS-232 commands. To use these commands, you must use HyperTerminal or an alternate terminal application. The settings for the connection are as follows: Baudrate 115200;... -
Page 11: Custom Hotkey Triggers
Custom hotkey triggers Users are able to customize the keys that trigger Hotkeys. The default trigger for hot key function on the keyboard is Ctrl + Ctrl. The trigger function can be used to change to the following keys: Ctrl (Left / Right), Alt, Shift (Left / Right), Caps Lock, Scroll Lock, F1-F12 TO VIEW HOTKEY TRIGGER SETTING Use the RS-232 command: / + / + ? + ? + Enter to view the current HotKey Trigger To reset the Hotkey Trigger use the “Factory Defaults”... -
Page 12: Troubleshooting
Troubleshooting No Power • Make sure that the power adapter is securely connected to the power connector of the unit. • Check the output voltage of the power supply and make sure that the voltage value is around 12VDC. • Replace the power supply. No Video •... -
Page 13: Limited Warranty Statement
Limited warranty statement A. Extent of limited warranty SmartAVI, Inc. warrants to the end-user customers that the SmartAVI product specified above will be free from defects in materials and workmanship for the duration of 1 year, which duration begins on the date of purchase by the customer. Customer is responsible for maintaining proof of date of purchase. - Page 14 NOTICE The information contained in this document is subject to change without notice. SmartAVI makes no warranty of any kind with regard to this material, including but not limited to, implied warranties of merchantability and fitness for particular purpose. SmartAVI will not be liable for errors contained herein or for incidental or consequential damages in connection with the furnishing, performance or use of this material.
