5.1.9

Noise generator

Low Pass Input
High Pass Input
Low Pass Frequency
Low Pass input
Low Pass Output
Low Pass Frequency
High Pass Output
High Pass Input
White Noise
Pink Noise
The noise generator allows the simultaneous management of a white and pink noise. It also pos-
sesses a low-pass and a high-pass of the first order (6 dB/octave) in which the cut-off frequency can
be statically set with the "frequency" potentiometers.
86
Noise generator
: Sets the low-pass filter cut-off frequency
: Low Pass filter input connection jack
: Low Pass filter output connection jack
: Sets the Low Pass filter cut-off frequency
: High Pass filter output connection jack
: High Pass filter input connection jack
: White noise output connection jack
: Pink noise output connection jack
White noise spectrum
ARTURIA – MOOG MODULAR V – USER'S MANUAL
Low Pass Frequency
Low Pass Output
High Pass Frequency
High Pass Output
White Noise
Pink Noise
