For this example, we recommend that you start over with the patch n°2 base.
► Successively connect the outputs of the waveforms of oscillators 3 and 4 to the VCA inputs 3
and 4 of the mixer.
► Set the "Range" of oscillator 3 to 16. It will play 1 octave upper than the 3 others
► Connect the white noise output to the third filter and choose the third type of filter on this (the
Filter Coupler). It will be very useful in creating a resonance particular to white noise. For this set it
to Band Pass mode.
► Connect the audio output of this filter to the audio input of the fifth mixer VCA.
► Connect envelope1 to one of the filter3 modulation inputs and set the modulation level to your
liking.
► Increase the attack time of the envelope to 14h in order to make the sound progressively appear
in the global sound.
► Now lets make another modulation appear given by the of LFO2 which will be provoked by
the after touch. For this, connect the "Tri" output of this LFO to the sixth audio input of the mixer.
► Connect the "After Touch" output to the "Mod" input of this same slice, and direct its output to
the second "Mod" input of filters1 & 2, without forgetting to increase the 2 modulation levels.
The white noise module connected to the band pass filter
► Set the third filter output towards the fifth slice of the mixer and link slices 3, 4 and 5 to direct
them towards the first and second filters.
